Zonda ESKY005437 User Manual

ESKY005437 Transimtter User Manual
1. Transimtter
LED Indicator
Throttle & Rudder
Stick (Mode2)
Throttle Trim
Lever (Mode 2)
Rudder Trim
Lever (Mode 2)
2.Binding
1) Switch on the helicopter power supply (switch toward to the helicopter tail), the status indicator on
helicopter flashes rapidly.
2) Press and hold the right button of the rudder trim lever, and switch on the transimtter simultaneously.
3) When the status indicator is off on the helicopter, release the right button of the rudder trim lever.
Then the status indicator is solid light on the helicopter again which indicates the binding successfully.
3.How to charge Esky150
1) Place four AA batteries inside the transmitter correctly.
2) For safety, switch off the helicopter and transmitter.
3) Plug the charging cable into the charging port under the helicopter battery and plug the other end
into the charging slot behind the transmitter. Then, there is a solid green light on the transmitter's LED
indicator.
4) When the LiPo battery inside the helicopter is fully charged, the green light will go out.
Diagram for the charging process
Antenna
Elevator & Aileron
Stick (Mode2)
Power Switch
Elevator Trim
Lever (Mode 2)
Aileron Trim
Lever (Mode 2)
Charging Slot for
Esky150 LiPo
Battery
