User Manual
WNFF60JGR
Safety information.......................................2
Safety instructions...................................... 3
Product description.....................................7
Before first use........................................... 9
Hob - Daily use......................................... 10
Hob - Hints and tips.................................. 12
Hob - Care and cleaning...........................13
CONTENTS
www.white-westinghouse-intl.com
Oven - Daily use ...................................... 14
Oven - Clock functions............................. 15
Oven - Using the accessories...................16
Oven - Hints and tips................................ 18
Oven - Care and cleaning.........................22
Troubleshooting........................................25
Installation................................................ 27
Advertisement
Table of Contents
Related Manuals for White-Westinghouse WNFF60JGR
Summary of Contents for White-Westinghouse WNFF60JGR
-
Page 1: Table Of Contents
User Manual WNFF60JGR CONTENTS Safety information........2 Oven - Daily use ........14 Safety instructions........3 Oven - Clock functions......15 Product description........7 Oven - Using the accessories....16 Before first use........... 9 Oven - Hints and tips........ 18 Hob - Daily use......... 10 Oven - Care and cleaning......22... - Page 2 SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with the appliance for future reference. Children and vulnerable people safety WARNING! Risk of suffocation, injury or permanent disability.
-
Page 3: Safety Information
SAFETY INFORMATION Metallic objects such as knives, forks, spoons and lids • should not be placed on the hob surface since they can get hot. Remove any spillage from the lid before opening. Let the hob • surface cool down before closing the lid. Internally the appliance becomes hot when in operation. -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS • Make sure that the electrical information This appliance is suitable for the following on the rating plate agrees with the power markets: BH KW OM QA AE supply. If not, contact an electrician. Installation • Always use a correctly installed shockproof socket. - Page 5 SAFETY INSTRUCTIONS • The information about the gas supply is • Do not let sparks or open flames to on the rating plate. come in contact with the appliance when • This appliance is not connected to a you open the door. device, which evacuates the products of •...
- Page 6 SAFETY INSTRUCTIONS • Use only stable cookware with the correct shape and diameter larger than • Do not change the specification of the the dimensions of the burners. lid. • Make sure the flame does not go out • Clean the lid regularly. when you quickly turn the knob from the •...
- Page 7 SAFETY INSTRUCTIONS • Remove the door catch to prevent children and pets to get closed in the appliance. • Flat the external gas pipes. Service • To repair the appliance contact an Authorised Service Centre. • Use original spare parts only.
-
Page 8: Product Description
PRODUCT DESCRIPTION Cooker specification Check the table to see your appliance's detailed specification. MODEL DENOMINATION AND PNC NUMBER Natural gas Initial gas settings Additional gas injectors Hob integrated ignition on the control knob Hob ignition on the spark generator button Oven integrated ignition on the control knob Oven ignition on the spark generator button Hob thermocouple... - Page 9 PRODUCT DESCRIPTION General overview Button for the spark generator Knob for the Minute Minder Knob for the temperature Knob for the oven functions Knobs for the hob Heating element Lamp Turnspit hole Shelf positions Cooking surface layout Auxiliary burner Semi-rapid burner Semi-rapid burner Triple Crown burner The storage compartment is below the...
-
Page 10: Before First Use
BEFORE FIRST USE WARNING! Refer to Safety chapters. Initial Cleaning Remove all accessories from the appliance. Refer to "Care and cleaning" chapter. Clean the appliance before first use. Put the accessories back to their initial position. Preheating Preheat the empty appliance to burn off the remaining grease. -
Page 11: Hob - Daily Use
HOB - DAILY USE Adjust the flame after it is regular. WARNING! WARNING! Refer to Safety chapters. Do not keep the knob pushed for more Ignition of the hob burner than 15 seconds. If the burner does not light after 15 seconds, release the knob, turn it into the off position and try to light the burner again after minimum Always light the burner before you put... - Page 12 HOB - DAILY USE A) Burner cap B) Burner crown C) Ignition candle (if applicable) D) Thermocouple (if applicable) Turning the burner off To put the flame out, turn the knob to the off position WARNING! Always turn the flame down or switch it off before you remove the pans from the burner.
-
Page 13: Hob - Hints And Tips
HOB - HINTS AND TIPS WARNING! Refer to Safety chapters. Cookware WARNING! Do not put the same pan on two burners. WARNING! Do not put unstable or damaged pots on the burners to prevent from spill and injury. CAUTION! Make sure that pot handles are not above the front edge of the cooktop. -
Page 14: Hob - Care And Cleaning
HOB - CARE AND CLEANING WARNING! Be very careful when you replace Refer to Safety chapters. the pan supports to prevent the hob top from damage. General information 2. The enamel coating occasionally can • Clean the hob after each use. have rough edges, so be careful when •... -
Page 15: Oven - Daily Use
OVEN - DAILY USE 1. Turn the knob for the oven functions to WARNING! select an oven function. 2. Turn the knob for the temperature to Refer to Safety chapters. select a temperature. 3. To deactivate the appliance turn the Activating and deactivating the knobs for the oven functions and appliance... -
Page 16: Oven - Clock Functions
OVEN - CLOCK FUNCTIONS Minute Minder This function has no effect on the operation of the appliance. 1. Set an oven function and the temperature. 2. Turn the knob for the timer as far as it goes, then turn it to necessary time period. -
Page 17: Oven - Using The Accessories
OVEN - USING THE ACCESSORIES Using the turnspit WARNING! WARNING! Refer to Safety chapters. Be careful when you use the turnspit. Inserting the accessories The forks and the spit are sharp. There is a risk of injury. Wire shelf: WARNING! Use oven gloves when you remove the turnspit. - Page 18 OVEN - USING THE ACCESSORIES 5. Install the first fork on the spit, then put the meat on the turnspit and install the second fork. Make sure that the meat is in the middle of the spit. 6. Use the screws to tighten the forks. 7.
-
Page 19: Oven - Hints And Tips
OVEN - HINTS AND TIPS • You can extend baking times by 10 – 15 WARNING! minutes if you bake cakes on more than one shelf position. Refer to Safety chapters. • Cakes and pastries at different heights do not always brown equally at first. If this occurs, do not change the temperature setting. - Page 20 OVEN - HINTS AND TIPS Cooking tables The time does not include preheating. Casseroles TEMPER- QUANTITY TIME SHELF FOOD OVEN FUNCTION ATURE (KG) (MIN) POSITION (°C) 1.5 - 2.5 True Fan Cooking 50 - 55 Lasagna Cannelloni 1.5 - 2.5 True Fan Cooking 50 - 55 Potato gra-...
- Page 21 OVEN - HINTS AND TIPS Fish TEMPER- QUANTITY TIME SHELF FOOD OVEN FUNCTION ATURE (KG) (MIN) POSITION (°C) Pike 0.8 - 1.5 True Fan Cooking 60 - 80 Dorade 0.4 - 0.7 True Fan Cooking 40 - 60 Trout 0.5 - 1.0 True Fan Cooking 25 - 30 Pizza...
- Page 22 OVEN - HINTS AND TIPS TEMPER- SHELF QUANTITY TIME FOOD OVEN FUNCTION ATURE POSI- (KG) (MIN) (°C) TION Yeast cake 1.0 - 1.5 True Fan Cooking 45 - 50 1) Preheat the oven for 10 minutes. Grilling QUANTITY SHELF POSI- FOOD OVEN FUNCTION TIME (MIN)
-
Page 23: Oven - Care And Cleaning
OVEN - CARE AND CLEANING WARNING! Refer to Safety chapters. Spots or discolouration of the catalytic surface have no effect on catalytic Notes on cleaning properties. • Clean the front of the appliance with a WARNING! soft cloth with warm water and a cleaning agent. - Page 24 OVEN - CARE AND CLEANING Do not lose the screws. 1. Open the door fully and hold the two door hinges. 4. Put the door on a soft cloth on a stable surface. 5. Use a screwdriver to remove 2 screws from bottom edge of door.
- Page 25 OVEN - CARE AND CLEANING WARNING! Danger of electrocution! Disconnect the fuse before you replace the lamp. The lamp and the lamp glass cover can be hot. 1. Deactivate the appliance. 2. Remove the fuses from the fuse box or deactivate the circuit breaker.
-
Page 26: Troubleshooting
TROUBLESHOOTING WARNING! Refer to Safety chapters. What to do if... PROBLEM POSSIBLE CAUSE REMEDY There is no spark when you The hob is not connected to Check if the hob is correctly try to activate the spark an electrical supply or it is connected to the electrical generator. - Page 27 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE REMEDY It takes too long to cook the The temperature is too low Adjust the temperature if dishes or they cook too or too high. necessary. Follow the advice quickly. in the user manual. The necessary data for the service centre Service data is on the rating plate.
-
Page 28: Installation
INSTALLATION Minimum distances WARNING! DIMENSION Refer to Safety chapters. Location of the appliance You can install your freestanding appliance with cabinets on one or two sides and in the corner. Technical data DIMENSION Keep a distance of about 1 cm between the appliance and the back Height 850 - 870... - Page 29 INSTALLATION Gas burners for NATURAL GAS G20 20 mbar NORMAL POWER INJECTOR MARK BURNER REDUCED POWER KW 1/100 MM Triple Crown 1.80 Semi-rapid 0.45 Auxiliary 0.35 Gas burners for LPG G30 28-30 mbar NORMAL POWER INJECTOR MARK BURNER REDUCED POWER KW 1/100 MM Triple Crown 1.80...
- Page 30 INSTALLATION • it can not get hotter than room temperature, higher than 30 °C, • it is not longer than 1500 mm, If the appliance is set for liquid gas you • it has no narrowing anywhere, can change it to natural gas, with the •...
- Page 31 INSTALLATION The model determines the position of Hob injectors replacement the bypass screw A. Replace the injectors when you change the gas type. 1. Remove the pan supports. 2. Remove the caps and crowns of the burner. 3. Remove the injectors with a socket spanner 7.
- Page 32 INSTALLATION To install all the accessories, do the first step in an opposite sequence. Anti-tilt protection Set the correct height and area for the 2. Put the appliance on the sidewall on a appliance before you attach the anti-tilt clean and smooth surface. Place each protection.
- Page 33 INSTALLATION appliance, you must adjust the side measurement to centre the appliance. If you changed the dimensions of the cooker, you must align the non-tip device correctly. CAUTION! If the space between the bench cupboards is larger than the width of the appliance, you must adjust the side measurement to the centre of the appliance.
- Page 34 ENVIRONMENT CONCERNS dispose appliances marked with the symbol Recycle the materials with the symbol with the household waste. Return the Put the packaging in applicable containers product to your local recycling facility or to recycle it. Help protect the environment contact your municipal office.
