Instar IN-6014 HD User Manual

Integrated passive infrared motion detector
Hide thumbs Also See for INSTAR IN-6014 HD:
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
IN-6014
HD
/ Integrated Passive Infrared Motion Detector
/ Wide Dynamic Range 720p CMOS Sensor for adverse lighting conditions
/ Automatic alarm by email and FTP video upload
/ Video recording on SDHC card (up to 32 GB)
/ Easy camera configuration via the integrated WebUI
/ Multi-level user managment and access control
/ Accessible over the internet via preinstalled DDNS address
/ Full smartphone integration (iOS & Android App)
/ Scheduled motion detection via image analysis
Chromium
Firefox
Internet Explorer
Safari

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INSTAR IN-6014 HD and is the answer not in the manual?

Questions and answers

Related Manuals for Instar INSTAR IN-6014 HD

Summary of Contents for Instar INSTAR IN-6014 HD

  • Page 1 User Manual IN-6014 / Integrated Passive Infrared Motion Detector / Wide Dynamic Range 720p CMOS Sensor for adverse lighting conditions / Automatic alarm by email and FTP video upload / Video recording on SDHC card (up to 32 GB) / Easy camera configuration via the integrated WebUI / Multi-level user managment and access control / Accessible over the internet via preinstalled DDNS address / Full smartphone integration (iOS &...
  • Page 3 Wide-Dynamic Range CMOS Sensor The OmniVision® WDR Sensor raises the bar in security imaging with a single-chip SOC sensor that combines 720p high-definition video with WDR in a 1/3-inch optical format. The sensor is build on a 4.3 micron OmniPixel3-HS™ pixel enabling 720p HD at unparalleled low-light sensitivity and a dynamic range in colour of 115dB - compared to the 60 dB of a regular VGA IP camera.

  • Page 4: Table Of Contents

    INSTAR INSTAR HD IP Camera – Quick Installation IN-6014 HD and IN-6014 HD PoE The following topics will be shortly explained in this Quick Installation Guide: SAFETY WARNINGS................3 PRODUCT FEATURES................4 INSTALLATION ..................5 START UP....................8 THE WEB USER INTERFACE ...............11...
  • Page 5 AVAILABLE ACCESSORIES ..............34 More information (German/English) can be found www.instar.com This manual is for the IP camera models IN-6014 HD and the IN- 6014 HD PoE. Unless otherwise noted, operations are identical for both models. All photos and illustrations show the model IN-6014...

  • Page 6: Safety Warnings

    Never install the device near explosive or flammable substances. » Don’t use the camera for any other purpose that it isn’t made for. INSTAR does not give any warranty if you use any third party firmware or WebUI. » CE-Conformity This device suites the basic requirements of the European regulations for electromagnetic compliance (2004/108/EC) and the low voltage regulations (2006/95/EC ).

  • Page 7: Product Features

    2 PRODUCT FEATURES Hardware » » Wide Dynamic Range Megapixel CMOS sensor and ARM media processor » » 12 Infrared-LEDs for nightvision 5 - 8 m » » Resolution: 720p (1280 x 720), 640 x 352 and 320 x 176 »...

  • Page 8: Installation

    3 INSTALLATION Fig. 1 Front Fig. 2 Rear Fig. 3 Bottom Photosensor Twilight-Switch for IR LEDs Lense Wideangle-lense (focal length: 4.3mm / field of view: 90.º hor.) Infrared-LEDs 12 IR LEDs (nightvision @ 850nm) PIR Detector Integrated passive Infrared Motion Detector Loudspeaker Integrated Loudspeaker (s.
  • Page 9 LAN port of your network router. For a direct connection to your Windows PC or Mac, please refer to our online FAQ section on www.faq.instar.de. But we recommend to connect the camera to your network router for the initial installation.
  • Page 10 Simply plug one IN-LAN adapter into a power socket next to your broadband router and connect the adapter to your router via an Ethernet cable. Plug the second IN-LAN unit into an outlet close to your INSTAR camera and connect the camera to the IN-LAN adapter using the camera’s Ethernet cable.

  • Page 11: Start Up

    4.1 NETWORK INSTALLATION Please start the setup wizard from the CD and install the INSTAR Camera Tool linked on the CD for Windows, LINUX or MacOS. (You can find documentations for the use of other IP scanners on www.faq.instar.de) Please start the INSTAR Camera Tool.
  • Page 12 Troubleshooting: In case the INSTAR Camera Tool doesn’t find your INSTAR IP camera please make sure that both status LEDs on the LAN connector are active - the orange LED should be continuously on indicating a hardware link and the green LED should flash irregularly showing network communication.(see page 7).
  • Page 13 IP camera. You can set the camera IP by using the INSTAR Camera Tool. As for Gateway and DNS server please fill in the computer IP. After submitting the settings to the camera please wait a moment until the camera has restarted.
  • Page 14 When accessing the webUI for the first time after installation, please allow the installa- tion of the ActiveX control element (only Internet Explorer): For alternative browsers (Firefox, Chrome, Safari,...) please install the QuickTime Pl- ugin. In case the plugin is installed already please confirm its permission (see below). If the Video doesn’t start, please refer to chapter 13 FAQ.

  • Page 15: The Web User Interface Software

    5.1.4 SOFTWARE/UPDATE You can download regular software updates for your cam- era from www.download.instar.com. Please use the browse button to set the file path once you downloaded and un- zipped the update BIN and click “Submit” to upload the file to your camera.

  • Page 16: Network

    - in case you didn’t assign a static IP address to your camera yet (s. 5.2.1). You might have to use the INSTAR Camera Tool again to rediscover your camera (s. 4). Your camera is now connected via WiFi!

  • Page 17: Ddns

    5.2.3 NETWORK/DDNS Your camera comes with a personal DDNS address - e.g. http://xxxx77.ddns-instar.de. Everything you need for a remote access to your camera is a port forward- ing rule (s. next page) in your router. You can access your camera afterwards through the internet using this http address.

  • Page 18: Point-To-Point (P2P)

    5.2.4 NETWORK/Point-to-Point (P2P) Activate the p2p function to access your camera from the internet without the need for a port forwarding in your router (s. 5.2.3). Simply add the camera as a p2p camera in our InstarVision app (s. 8), scan the QR code on the Network/P2P overlay in the WebUI or from the sticker on the camera and add the camera administrator login (s.

  • Page 19: System

    5.3 SYSTEM 5.3.1 SYSTEM/DATE & TIME You can set up the internal clock of the camera to be either synchronised with your PC clock or with one of several NTP servers. As long as your camera has ac- cess to the internet it is recommended to use an NTP server synchronisation to achieve a higher accuracy for alarm trigger events.

  • Page 20: Onvif

    ONVIF is a global standard for the interface of IP-based security products. The ONVIF specification will ensure interoperability between products regardless of manu- facturer, allowing you to integrate your INSTAR cam- era as a generic ONVIF camera into existing security systems.

  • Page 21: Image

    The MJPEG mode of the camera allows you to access the videostream with your browser without the need of additional browser-plugins! You can use the MJPEG mode when you are accessing the camera from a system that doesn’t allow you to install the ActiveX control element or the QuickTime plugin for Firefox, Chrome or Safari.

  • Page 22: Actions

    Plug & Play - PIR Motion Detector Motion IN-Motion 300 - the passive infrared detector especially designed for INSTAR camera models without an integrated sensor. The simplest way to avoid false alerts by changes in light conditions. All components needed for the installation are al-...

  • Page 23: Schedule

    SMTP server data (s.5.5.4), though some email provider let you choose this field freely. If you want to send the email to more than one address, simply separate the addresses with a semicolon ‘;’ . E.g. max.mustermann@instar.de;franz.fingerhut@instar.de...

  • Page 24: Ftp

    You can define an upload directory for your camera under FTP Folder. The root folder of the FTP server can be reached by “./”. The separator for the folders is the forward slash. A subfolder (e.g. INSTAR) can be reached by “./INSTAR”. An ending forward slash is not obligatory, but can be used.

  • Page 25: Sd Card

    5.5.8 ALARM/SD CARD Please check the corresponding box and click submit to either format or unmount your SD card. A click on the link above the submit button will lead you to the SD card directory where all your snapshots and videos will be stored.

  • Page 26: Menu Bar

    5.7.4 MENU BAR/PLAYER (only Internet Explorer) By clicking on Player you can start a simple video player to play your recorded video files. 5.7.5 MENU BAR/HELP Clicking on Help will bring you to our constantly expand- ing online FAQ section on www.instar.de.

  • Page 27: Mjpeg (H.264)

    (only Internet Explorer) Here you can set the record path for your videos and snap- shots. The set path is used by all your INSTAR Megapixel Cameras! Your camera will automatically create subdirecto- ries with the current date and its IP address when you start recording or take a snapshot.

  • Page 28: Web Userinterface Update

    Simply select your camera model, scroll to the bottom part of the website and choose the newest Software/Firmware for your IP camera. The firmware or webUI file can be uploaded to your camera via the web userinterface (s.5.1.4) or by using the INSTAR camera tool.

  • Page 29: Pan&Tilt Control

    5.9 PAN & TILT CONTROL 5.9.2 PAN&TILT CONTROL/CONTROL PAD You can use the control pad to pan and tilt your camera´s head. You can also start a horizontal (hscan) or vertical (vscan) patrol or stop the cameras movement (stop). The camera will move in both patrols into the according terminal positions and then go back to the initial position.

  • Page 30: Lense Adjustment

    To integrate your IP camera in the Android/iPhone/WinPhone8 App “InstarVision” we recommend to first download the newest version in the App Store. To find the newest version just type “instar” for the search. (Fig. 1) After installing the newest version please start the App to open the following interface (s.
  • Page 31 The password with which you log in to your camera. As default the password is “instar”. Model: Please choose your INSTAR camera model. Now please choose “Add Camera” to save the settings and to return to the home screen (Fig.3).

  • Page 32: Windows Software

    InstarVision® is a 16/32 Channel Video Surveillance Software for Windows (the number of available channels depends on your license!) The Software can record the live stream of any Webcam, TV Cards, Video-Recording Cards (DVR), INSTAR IP Camera or other devices with up to 30 fps.

  • Page 33: Rtsp Streaming

    Access via internet: Please use your DDNS address to remote access your cameras RTSP stream: rtsp://<user>:<password>@xxx.ddns-instar.de:<RTSP Port>/11 xxx = please check your personal DDNS address under network/DDNS (s. 5.2.3) Tip: Your camera offers you 3 RTSP streams with different bitrates. Please choose stream 2 or 3 if your available bandwidth is limited or you are using a computer with limited processing power (e.g.

  • Page 34: Technical Data

    11 TECHNICAL DATA Image Sensor Sensor ”Megapixel WDR CMOS Resolution max. 1280x720 Pixel (1.0 Megapixel) Lense f = 4.3 mm; F/1.2 (IR Lense) Angle of View 90 ° diagonal Min. Illumination 0.5 Lux @ F/1.2 Video Properties Video Encoding h.264/MPEG-4 AVC (Level3) Alternative Encoding MJPEG (no plugins needed) Video Framerate...

  • Page 35: Warranty & Disposal

    12 WARRANTY & DISPOSAL Warranty INSTAR offers a 2-year warranty on its products. During this period you can send in your camera for a free repair. This excludes cameras installed with custom-made or 3rd party Firmware and WebUIs which have not been approved by INSTAR. The warranty is only for hardware parts of the camera.

  • Page 36: Faq Questions & Answers

    13 FAQ Questions & Answers 1) The video doesn’t start in Internet Explorer? Please make sure that you installed the Active Control Element (s. page 10). You can always install the element manually from the software CD in case the automatic instal- lation doesn’t work.

  • Page 37: Available Accessories

    It can take up to 12 hours before you can reach your camera via the ddns-instar address - usually it takes about 30 minutes. Please note that you first have to set up a port forwarding rule in your router (s. 5.2.3). In case you can still not access your camera, please try to change the HTTP (LAN) port of your camera (standard 80) - for example to port 8081 (s.
  • Page 38 PERSONAL NOTES...
