Power Edger
The engine exhaust from this product contains chemicals
known to the State of California to cause cancer, birth defects,
or other reproductive harm.
Read and understand all provided literature before use.
Failure to do so could result in serious injury.
X7732272902
© 09/19 ECHO Incorporated
Operator's
Manual
LE235

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LE235 and is the answer not in the manual?

Questions and answers

Related Manuals for Shindaiwa LE235

Summary of Contents for Shindaiwa LE235

  • Page 1 Operator’s Manual LE235 Power Edger The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. Read and understand all provided literature before use. Failure to do so could result in serious injury.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS LE235 TABLE OF CONTENTS Introduction ....................3 Servicing Information .................. 3 Parts/Serial Number................3 Service ....................4 Consumer Product Support ..............4 Product Registration ................4 Additional Literature ................4 Safety ......................4 Manual Safety Symbols and Important Information ......4 International Symbols ................

  • Page 3: Introduction

    SERVICING INFORMATION Parts/Serial Number Genuine SHINDAIWA Parts and Assemblies for your SHINDAIWA products are available only from an Authorized SHINDAIWA Dealer. When you do need to buy parts always have the Model Number and Serial Number of the unit with you.

  • Page 4: Service

    Service Service of this product during the warranty period must be performed by an Authorized SHINDAIWA Service Dealer. For the name and address of the Authorized SHINDAIWA Service Dealer nearest you, ask your retailer or call: 1-877-986-7783. Dealer information is also available on WWW.SHINDAIWA-USA.COM.

  • Page 5: International Symbols

    LE235 SAFETY The safety alert symbol accompanied by the word “WARNING” calls attention to an act or condition which CAN lead to serious personal injury or death if not avoided. The safety alert symbol accompanied by the word “CAUTION” calls attention to an act or condition which may lead to minor or moderate personal injury if not avoided.
  • Page 6 SAFETY LE235 Symbol Description Symbol Description Hot Surface Fuel and Oil Mixture DO NOT Allow Flames Ignition or Sparks Near Fuel ON / OFF DO NOT Smoke Near Primer Bulb Fuel Choke Control “COLD Choke Control “RUN” START” Position Position (Choke Open)

  • Page 7: Personal Condition And Safety Equipment

    LE235 SAFETY Personal Condition and Safety Equipment Cancer and Reproductive Harm www.P65Warnings.ca.gov The muffler or catalytic muffler and surrounding cover may become extremely hot. Always keep clear of exhaust and muffler area, otherwise serious personal injury may occur. Users of this product risk injury to themselves and others if the unit is used improperly and/or safety precautions are not followed.
  • Page 8 SAFETY LE235 Hand Protection Wear sturdy, no-slip, rubber work gloves to improve your grip on the handles. Gloves also provide protection against cuts and scratches, cold environments, and reduce the transmission of machine vibration to your hands. Hearing/Ear Protection ECHO recommends wearing personal protection whenever unit is used.
  • Page 9 LE235 SAFETY The components of this machine generate an electromagnetic field during operation, which may interfere with some pacemakers. To reduce the risk of serious or fatal injury, persons with pacemakers should consult with their physician and the pacemaker manufacturer before operating this machine.
  • Page 10 SAFETY LE235 Repetitive Stress Injuries (RSI) It is believed that overusing the muscles and tendons of the fingers, hands, arms, and shoulders may cause soreness, swelling, numbness, weakness, and extreme pain in those areas. Certain repetitive hand activities may put you at a high risk for developing a Repetitive Stress Injury (RSI).
  • Page 11 LE235 SAFETY Do not operate this product indoors or in inadequately ventilated areas. Engine exhaust contains poisonous emissions and can cause serious injury or death. Read Manuals • Provide all users of this equipment with literature for instructions on safe operation.

  • Page 12: Equipment

    SAFETY LE235 Equipment Use only Shindaiwa attachments. Serious injury may result from the use of a non-approved attachment combination. ECHO, INC. will not be responsible for the failure of cutting devices, attachments or accessories which have not been tested and approved by ECHO.

  • Page 13: Emission Control (Exhaust & Evaporative)

    LE235 EMISSION CONTROL EMISSION CONTROL (EXHAUST & EVAPORATIVE) CARB And EPA Emissions Control Information The emission control system for the engine is EM (engine modification) and, if the second to last character of the Engine Family on the Emission Control Information label (sample below) is “B”, “C”, “K”, or “T”, the emission...

  • Page 14: Description

    DESCRIPTION LE235 DESCRIPTION Locate the safety decal(s) on your unit. Make sure the decal(s) is legible and that you understand and follow the instructions on it. If a decal cannot be read, a new one can be ordered from your dealer. Safety label is for example only.

  • Page 15: Contents

    Due to packaging restrictions, some assembly may be necessary. After opening the carton, check for damage. Immediately notify your retailer or Shindaiwa Dealer of damaged or missing parts. Use the contents list to check for missing parts. Power Head / Drive Shaft Assembly Operator’s Manual...

  • Page 16: Assembly

    ASSEMBLY LE235 ASSEMBLY Support Handle If necessary, position support handle for comfortable operation and securely tighten screw. Note: Label shows minimum spacing for support handle location. OPERATION Starting Cold Engine The attachment will operate immediately when the engine starts, and could result in possible serious injury. Keep...
  • Page 17 LE235 OPERATION Stop Switch Move stop switch (A) forward, away from the STOP position. Choke Move choke (B) to COLD START ( ) (CLOSED) position. Purge Bulb Pump purge bulb (C) until fuel is visible and flows freely in the clear fuel tank return line.

  • Page 18: Starting Warm Engine

    OPERATION LE235 Choke After engine fires (or 5 pulls), move choke (B) to the RUN ( ) (OPEN) position. Firmly grasp throttle handle and throttle trigger lockout with left hand and fully depress throttle trigger to wide open position. Pull starter handle/rope until engine starts and runs.

  • Page 19: Stopping Engine

    LE235 OPERATION Purge Bulb Pump purge bulb (C) until fuel is visible and flows freely in the clear fuel tank return line. Pump bulb an additional 4 or 5 times. Recoil Starter Lay the unit on a flat area and keep movable attachment parts clear of all obstacles.

  • Page 20: Edger Operation Techniques

    OPERATION LE235 If engine does not stop when stop switch is moved to STOP position, close choke - COLD START position - to stall engine. Have your dealer repair stop switch before using unit again. Edger Operation Techniques Engine exhaust IS HOT, and contains Carbon Monoxide (CO), a poison gas.
  • Page 21 LE235 OPERATION Loosen adjustment knob and adjust the blade's depth of cut to produce a fine cut between sidewalk and grass using a minimum blade depth, usually with about 13 mm (1/2 in.) of the blade into the ground. Tighten adjustment knob.

  • Page 22: Maintenance

    MAINTENANCE LE235 MAINTENANCE Moving parts can amputate fingers or cause severe injuries. Keep hands, clothing and loose objects away from all openings. Always stop engine, disconnect spark plug, and make sure all moving parts have come to a complete stop before removing obstructions, clearing debris, or servicing unit.

  • Page 23: Maintenance Intervals

    LE235 MAINTENANCE Maintenance Intervals REQ’D MAINTENANCE COMPONENT/SYSTEM SKILL PROCEDURE LEVEL Daily or Before Use Air Filter Inspect/Clean * Choke Shutter Inspect/Clean * Fuel System Inspect Cooling System Inspect/Clean Recoil Starter Rope Inspect/Clean * Screws/Nuts/Bolts Inspect/Tighten/Replace * Every Refuel Fuel System...

  • Page 24: Air Filter

    MAINTENANCE LE235 Air Filter Level 1. Parts Required: Tune-Up Kit Close choke (COLD START [ ] position). This prevents dirt from entering the carburetor throat when the air filter is removed. Brush accumulated dirt from air cleaner area. Remove air filter cover. Brush dirt from inside cover.

  • Page 25: Fuel Filter

    LE235 MAINTENANCE Fuel Filter Level 1. Parts Required: TUNE UP KIT. Fuel is VERY flammable. Use extreme care when mixing, storing or handling, or serious personal injury may result. Use a clean rag to remove loose dirt from around fuel cap and empty fuel tank.

  • Page 26: Spark Plug

    MAINTENANCE LE235 Spark Plug Level 2. Parts Required: Tune-Up Kit Use only NGK BPM8Y spark plug (BPMR8Y in Canada) otherwise severe engine damage may occur. Remove spark plug and check for fouling, worn and rounded center electrode. Clean the plug or replace with a new one.

  • Page 27: Cooling System

    LE235 MAINTENANCE Cooling System Level 2. To maintain proper engine operating temperatures, cooling air must pass freely through the cylinder fin area. This flow of air carries combustion heat away from the engine. Overheating and engine seizure can occur when: •...
  • Page 28 MAINTENANCE LE235 DO NOT use a metal scraper to remove dirt from the cylinder fins. Use a brush to remove dirt from the cylinder fins. Remove ignition wires from clip for cleaning. Remove grass and leaves from the grid between the recoil starter and fuel tank.

  • Page 29: Exhaust System

    LE235 MAINTENANCE Exhaust System Spark Arrestor Screen Level 2. Parts Required: Spark Arrestor Screen, Gasket Remove spark plug lead and engine cover. Place piston at Top Dead Center (TDC) to prevent carbon/dirt from entering cylinder. Remove spark arrestor screen cover (C), gaskets (D), (E), and screen (F), from muffler body.

  • Page 30: Carburetor Adjustment

    MAINTENANCE LE235 Use a wood or plastic scraping tool to clean deposits from cylinder exhaust port (C). Never use a metal tool to scrape carbon from the exhaust port. Do not scratch the cylinder or piston when cleaning the exhaust port. Do not allow carbon particles to enter the cylinder.

  • Page 31: Lubrication

    LE235 MAINTENANCE If the engine is adjusted for operation above 330 m (1100 ft.) ASL, the carburetor must be re-adjusted when operating the engine below 330 m (1,100 ft.) ASL, otherwise severe engine damage may result. Note: Every unit is run at the factory and the carburetor is set in compliance with emission regulations.

  • Page 32: Edger Blade Replacement

    MAINTENANCE LE235 Clean all loose debris from gear case. Remove plug (A) and check level of grease. Add grease if necessary. DO NOT over-fill. Drive Shaft Loosen screw (B) and remove center locating screw (C). Pull gear box and shield from drive shaft housing.

  • Page 33: Troubleshooting

    LE235 TROUBLESHOOTING Install and center blade (F) on inner blade adapter (B). Install outer adapter (E) and nut (D). Tighten nut (D) firmly, turning counterclockwise. Note: Never reuse old split pin. Install new split pin (A) to secure nut, and bend both legs of pin counterclockwise around PTO shaft (C).
  • Page 34 TROUBLESHOOTING LE235 ENGINE PROBLEM TROUBLESHOOTING CHART Problem Check Status Cause Remedy Air filter Air filter Normal wear Clean or replace dirty Contaminants Fuel filter Replace filter or Fuel filter or residue in dirty replace fuel fuel Engine runs, but Fuel vent...

  • Page 35: Storage

    LE235 STORAGE STORAGE During operation the muffler or catalytic muffler and surrounding cover become hot. Always keep exhaust area clear of flammable debris during transportation or when storing, otherwise serious property damage or personal injury may result. Long Term Storage (Over 30 Days)

  • Page 36: Specifications

    SPECIFICATIONS LE235 SPECIFICATIONS MODEL LE-235 Length 1733 mm (68.2 in.) Width 330mm (13.0 in.) Height 362 mm (14.3 in.) Weight (dry) w/o 5.4 kg (11.9 lb.) Cutter Head Air cooled, two-stroke, single cylinder gasoline Engine Type engine Bore 32.2 mm (1.27 in.) Stroke 26.0 mm (1.02 in.)
  • Page 37 LE235 SPECIFICATIONS MODEL LE-235 Blade Thickness Standard 2.3 mm (0.090 in.), Premium 4.6 mm (0.181 in.) Handle Front D-loop, Rear - Grip Idle Speed 3,000 RPM Clutch Engagement 4,200 RPM Speed Wide Open Throttle 10,900 RPM Speed (W.O.T.) X7732272902 © 09/19 ECHO Incorporated...

  • Page 38: Product Registration

    PRODUCT REGISTRATION Thank you for choosing Shindaiwa Power Equipment Please go to http://www.shindaiwa-usa.com to register your new product on- line. It's FAST and EASY! NOTE: your information will never be sold or misused by ECHO, Inc. Registering your purchase enables us to contact you in the unlikely event of a service update or product recall, and verifies your ownership for warranty consideration.
  • Page 39 LE235 PRODUCT REGISTRATION X7732272902 © 09/19 ECHO Incorporated...
  • Page 40 T86914001001 - T89614999999 U34814001001 - U34814999999 ECHO INCORPORATED 400 Oakwood Road Lake Zurich, IL 60047 -usa www.shindaiwa .com...
