- Page 1 AIOT-ILRA01 LoRa® Certified Intel® Based Gateway and Network Server User Manual 2 DISTRIBUTED BY TEXIM EUROPE Last Updated: December 18, 2017 Last Updated: December 18, 2017...
- Page 2 Copyright Notice This document is copyrighted, 2017. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of the original manufacturer.
- Page 3 Acknowledgement All other products’ name or trademarks are properties of their respective owners. Microsoft Windows is a registered trademark of Microsoft Corp. Intel, Pentium, Celeron, and Xeon are registered trademarks of Intel Corporation Core, Atom are trademarks of Intel Corporation ...
- Page 4 Packing List Before setting up your product, please make sure the following items have been shipped: Item Quantity AIOT-ILRA01 LoRa® Antenna If any of these items are missing or damaged, please contact your distributor or sales representative immediately. DISTRIBUTED BY TEXIM EUROPE Preface...
- Page 5 About this Document This User’s Manual contains all the essential information, such as detailed descriptions and explanations on the product’s hardware and software features (if any), its specifications, dimensions, jumper/connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the AAEON.com for the latest version of this document.
- Page 6 Safety Precautions Please read the following safety instructions carefully. It is advised that you keep this manual for future references All cautions and warnings on the device should be noted. Make sure the power source matches the power rating of the device. Position the power cord so that people cannot step on it.
- Page 7 If any of the following situations arises, please the contact our service personnel: Damaged power cord or plug Liquid intrusion to the device iii. Exposure to moisture Device is not working as expected or in a manner as described in this manual The device is dropped or damaged Any obvious signs of damage displayed on the device...
- Page 8 FCC Statement This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation.
- Page 9 China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 AAEON Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 汞 镉 六价铬 多溴联苯 多溴二苯醚 铅 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 ○ ○ ○ ○ ○ ○ 及其电子组件 外部信号 ○ ○ ○ ○ ○ ○ 连接器及线材...
- Page 10 China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products AAEON Main Board/ Daughter Board/ Backplane Poisonous or Hazardous Substances or Elements Hexavalent Polybrominated Polybrominated Component Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB &...
-
Page 11: Table Of Contents
Table of Contents Chapter 1 - Product Specifications..................1 Specifications ......................2 Chapter 2 – Hardware Information ..................4 Dimensions ....................... 5 2.1.1 I/O Location ....................6 Jumpers and Connectors for the UP-CHT01 ............. 7 List of Switches and Connectors for the UP-CHT01 ......... 8 2.3.1 Power Button (SW1) .................. - Page 12 DISTRIBUTED BY TEXIM EUROPE Preface...
-
Page 13: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications DISTRIBUTED BY TEXIM EUROPE... -
Page 14: Specifications
Specifications System Intel® Atom™ x5-z8350 SoC Processor integrated Chipset Onboard 4GB DDR3L-1600 memory System Memory Power Requirement 5V DC Only Storage 64 GB eMMC on board x 1 Audio HDMI Audio x 1 Power Supply Type DC-In ... - Page 15 Range up to 15 km (Line of Sight) Display Graphics Intel® HD, up to 500MHz Support DX*11.1/12, Open GL*4.2, Open CL*1.2 ES3.0, H.264, HEVC (decode), VP8 HDMI x 1 HDMI USB2.0 x 4 USB 3.0 OTG x 1 RJ45 Connector x 1 Expansion Slot (Optional) ...
-
Page 16: Chapter 2 - Hardware Information
Chapter 2 Hardware Information – Chapter 2 DISTRIBUTED BY TEXIM EUROPE... -
Page 17: Dimensions
Dimensions DISTRIBUTED BY TEXIM EUROPE Chapter 2 – Hardware Information... -
Page 18: 2.1.1 I/O Location
2.1.1 I/O Location DISTRIBUTED BY TEXIM EUROPE Chapter 2 – Hardware Information... -
Page 19: Jumpers And Connectors For The Up-Cht01
Jumpers and Connectors for the UP-CHT01 DISTRIBUTED BY TEXIM EUROPE Chapter 2 – Hardware Information... -
Page 20: List Of Switches And Connectors For The Up-Cht01
List of Switches and Connectors for the UP-CHT01 Please refer to the table below for all of the board’s jumpers that you can configure for your application. Label Function Power Button RTC Battery Wafer USB 3.0 Micro Connector USB 2.0 1x10P Wafer USB Type A Connector 1 USB Type A Connector 2 CN10... - Page 21 Label Connector Type (TF) Push Button Switch.HCH.PTS-099 (TF) WAFER BOX 2P .180D.1.25mm.CATCH.1201-700-02S (TF) Micro USB 3.0 Conn.10P .90D.B-type.ATTEND.209E-BE01 (TF)Wafer Box.10P .90D.1.0mm.CATCH.1204-700-10RM (TF)USB CONNECTOR DUAL PORT.8P .TechBest.KS-002D-ANB(2.0)-L (TF)USB CONNECTOR DUAL PORT.8P .TechBest.KS-002D-ANB(2.0)-L CN10 (TF) RJ45.14P .90D.W/TF & LED.UDE.RB1-1A5BAK1A CN11 (TF)HDMI CONN.19P .90D(F).A TYPE.FOXCONN.QJ51191-LFB4-7F CN12 (TF) PIN HEADER.2*20P .180D.(M).2.54mm.DIP CN14...
-
Page 22: Power Button (Sw1)
2.3.1 Power Button (SW1) Position Function SW1 1 (default) SW1 0 Power on 2.3.2 RTC Battery Wafer (CN1) Signal +V_COIN_BAT 2.3.3 USB 3.0 Micro Connector (CN6) Signal Signal USB_VCC USB2_D- CROSSBAR_TX1_N USB2_D+ CROSSBAR_TX1_P USB2_ID DISTRIBUTED BY TEXIM EUROPE Chapter 2 – Hardware Information... -
Page 23: Usb 2.0 X 10P Wafer (Cn7)
CROSSBAR_RX1_N CROSSBAR_RX1_P 2.3.4 USB 2.0 x 10P Wafer (CN7) Signal Signal USB_VCC USB_HSIC_P4_D+ USB_HSIC_P3_D- USB_HSIC_P3_D+ UART0_RXD UART0_TXD USB_VCC USB_HSIC_P4_D- 2.3.5 Dual USB Type A Connector 1 (CN8) Signal Signal USB_VCC USB_VCC DISTRIBUTED BY TEXIM EUROPE Chapter 2 – Hardware Information... -
Page 24: Dual Usb Type A Connector 2 (Cn9)
USB2_P1_D- USB2_P2_D- USB2_P1_D+ USB2_P2_D+ 2.3.6 Dual USB Type A Connector 2 (CN9) Signal Signal USB_VCC USB_VCC USB2_P3_D- USB_HSIC_P2_D- USB2_P3_D+ USB_HSIC_P2_D+ 2.3.7 RJ-45 LAN Connector (CN10) Signal Signal LAN1_MDI0+ LAN1_MDI2- LAN1_MDI0- LAN1_MDI3+ DISTRIBUTED BY TEXIM EUROPE Chapter 2 – Hardware Information... -
Page 25: Hdmi Connector (Cn11)
LAN1_MDI1+ LAN1_MDI3- LAN1_MDI1- LAN_ACTLEDP LAN1_MDI2+ LAN_ACTLEDN LAN1_MDI2- LAN_LINK100# LAN1_MDI2+ LAN_LINK1000# 2.3.8 HDMI Connector (CN11) Signal Signal DDI2_TX0_HDMI_DP+ DDI2_CLK_HDMI_DN- DDI2_TX0_HDMI_DN- HDMI_CEC_D DDI2_TX1_HDMI_DP+ DDI2_DDC_CLK DDI2_TX1_HDMI_DN- DDI2_DDC_DAT DDI2_TX2_HDMI_DP+ +5V_HDMI DDI2_TX2_HDMI_DN- DDI2_TYPE_C_HPD DDI2_CLK_HDMI_DP+ 2.3.9 HAT 40 GPIO Connector (CN12) DISTRIBUTED BY TEXIM EUROPE Chapter 2 – Hardware Information... -
Page 26: Reset Pin Header (Cn14)
Signal Signal +3.3V I2C1_SDA I2C1_SCL ISH_GPIO0 UART_TX UART_RX SD2_CMD I2S2_CLK SD2_CLK SD2_SD0 SD2_SD1 +3.3V SD2_SD2 SPI2_MOSI SPI2_MISO SD2_SD3 SPI2_CLK ISH_SPI2_CS0 ISH_SPI2_CS1 I2C0_SDA I2C0_SCL ISH_GPIO2 ISH_GPIO3 PWM0 PWM1 I2S2_FRM GPIO27 GPIO13 I2S2_RX I2S2_TX 2.3.10 Reset Pin Header (CN14) Signal PMU_RSTBTN_N DISTRIBUTED BY TEXIM EUROPE Chapter 2 –... -
Page 27: Dc Jack (Cn30)
2.3.11 DC Jack (CN30) Signal 2.3.12 MIPI DSI Connector (CN31) Signal Signal Signal MDSI_A_DATA1_DN DDI0_TX0_DP DDI0_HPD_CONN MDSI_A_DATA1_DP DDI0_TX0_DN DDI0_BKLT_R_CTRL DDI0_VDD_EN MDSI_A_CLK_DN DDI0_TX1_DP DDI0_BKLT_EN MDSI_A_CLK_DP DDI0_TX1_DN MDSI_A_DATA0_DN DDI0_TX2_DP +3.3V MDSI_A_DATA0_DP DDI0_TX2_DN +3.3V +3.3V I2C2_3P3_SCL DDI0_TX3_DP +3.3V DISTRIBUTED BY TEXIM EUROPE Chapter 2 – Hardware Information... -
Page 28: Mipi Csi Connector (Cn32)
I2C2_3P3_SDA DDI0_TX3_DN +3.3V DDI1_DDC_C_CLK DDI0_AUX_DP DDI1_DDC_C_DAT DDI0_AUX_DN 2.3.13 MIPI CSI Connector (CN32) Signal Signal MCSI_1_DATA1_DN CAM_MCLK MCSI_1_DATA1_DP I2C2_SOC_SCL MCSI_1_CLK_DN I2C2_SOC_SDA MCSI_1_CLK_DP CAM_RST_N FLASH_RESET_N MCSI_1_DATA0_DN +2.8V MCSI_1_DATA0_DP GND_CAM +1.2V +1.8V DISTRIBUTED BY TEXIM EUROPE Chapter 2 – Hardware Information... -
Page 29: Power Button Wafer (Cn33)
2.3.14 Power Button Wafer (CN33) Signal PWR_SW#_CTL_R 2.3.15 Update CPLD Header (CN34) Signal Signal CHT_GPIO_TMS CPLD_TMS CHT_GPIO_TDI CPLD_TDI CHT_GPIO_TCK CPLD_TCK CHT_GPIO_TDO CPLD_TDO FAN_PWM +1.8V DISTRIBUTED BY TEXIM EUROPE Chapter 2 – Hardware Information... -
Page 30: Lora® Module
LoRa® Module Has been outsourced. DISTRIBUTED BY TEXIM EUROPE Chapter 2 – Hardware Information... -
Page 31: Chapter 3 -Drivers And Testing Installation
Chapter 3 Chapter 3 –Drivers and Testing Installation DISTRIBUTED BY TEXIM EUROPE... -
Page 32: Driver Download And Installation
Driver Download and Installation * Please access the https://up-community.org and go to the Downloads section>UP to find the relevant driver. Installation and Testing Modify the Vanilla HAL Software: Step 1. Decompress the HAL software $ unzip ~/unzip lora_gateway-master.zip $ unzip ~/packet_forwarder-master.zip Step 2. - Page 33 $ vim reset_lgw.sh Replace IOT_SK_SX1301_RESET_PIN=7 with IOT_SK_SX1301_RESET_PIN=5 Step 4. Build the HAL software $ cd ~/lora_gateway-master/ $ make clean && make Testing Test 1. Basic low level SPI test $ cd ~/lora_gateway-master/ $ sudo ./reset_lgw.sh start $ cd util_spi_stress/ $ ./util_spi_stress DISTRIBUTED BY TEXIM EUROPE Chapter 3 –...
- Page 34 Test 2. Simple TX test $ cd ~/lora_gateway-master/ $ sudo ./reset_lgw.sh start $ cd util_tx_test/ $ ./util_tx_test -r1257 -f868.1 -s7 -p0 -t100 -x10 Test 3. Simple RX test DISTRIBUTED BY TEXIM EUROPE Chapter 3 – Drivers and Testing Installation...
- Page 35 $ cd ~/lora_gateway-master/ $ sudo ./reset_lgw.sh start $ cd util_pkt_logger/ $ ./util_pkt_logger Test 4. Testing the forwarder $ cd ~/packet_forwarder-master/ $ vim Makefile Replace LGW_PATH ?= ../../lora_gateway/libloragw with DISTRIBUTED BY TEXIM EUROPE Chapter 3 – Drivers and Testing Installation...
- Page 36 LGW_PATH ?= /home/USERNAME/lora_gateway-master/libloragw $ make clean && make Open two terminal Terminal 1 (virtual server): $ cd ~/lora_gateway-master/ $ sudo ./reset_lgw.sh start $ cd ~/packet_forwarder-master/util_sink/ $ ./util_sink 1680 Terminal 2: $ cd ~/packet_forwarder-master/lora_pkt_fwd/ $ ./lora_pkt_fwd Test 5. Test with Mote II DISTRIBUTED BY TEXIM EUROPE Chapter 3 –...
- Page 37 Step 1. Power up Mote II Step 2. Start the packet forwarder $ cd ~/lora_gateway-master/ $ sudo ./reset_lgw.sh start $ cd ~/packet_forwarder-master/lora_pkt_fwd/ $ ./lora_pkt_fwd DISTRIBUTED BY TEXIM EUROPE Chapter 3 – Drivers and Testing Installation...
- Page 38 Step 3. You can get pkt from Mote II on terminal Mote II: DISTRIBUTED BY TEXIM EUROPE Chapter 3 – Drivers and Testing Installation...
