Pyle PPHP82SM User Manual page 2

WARNING
1. DO NOT place objects on top of the device, as objects may
scratch the device.
2. DO NOT expose the device to dirty or dusty environments.
3. DO NOT insert any foreign objects into the device.
4. DO NOT expose the device to strong magnetic or electrical eld.
5. DO NOT use the device in the rain
6. Please check with your Local Authority or retailer for proper
disposaI of electronic products.
7. DO NOT disassemble the device. Only a certi ed service
technician should perform repair.
8. The device has apertures to disperse heat. DO NOT block the
device ventilation, the device may become hot and malfunction
as a result.
Illegal operation may cause personal injury, which could be fatal and may cause
damage to property.
2
www.PyleUSA.com
CONTROL BOARD FUNCTIONS
1. USB Control board
2. USB and MICRO SD Memory Card input jack
3. Master volume control knob
4. 3.5MM AUX input jack
5. Short press to choose input signal, press and hold to turn ON/OFF light
6. Turn the knob to the end to power OFF, turn the knob to the right to power ON.
7. Echo volume control knob
8. Microphone volume control knob
9. Charge LED indicator, red color for charging mode and blue color for fully charged.
10. DC 5V input jack
11. 6.5MM microphone input jack
