Frigidaire ATF6000ES Factory Parts Catalog

Front-load washing machine
Hide thumbs

Advertisement

P12L0054.eps P12C0358.eps P12V0086.eps P12T0088.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
ATF6000ES1
Series
Frigidaire
Market
North America
Color
white
Volts
115
Wiring Diagram
134604100
Owner's Guide
134609000
Energy Guide
134604200
Installation Instructions 134602900
Operating Instructions 134604400
134604100.eps
Publication No.
5995464004
06/03/23
(EN/SERVICE/KC)
361
Copyright
FRONT-LOAD
WASHING MACHINE
Model No.
ATF6000E
©
2006 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

  Related Manuals for Frigidaire ATF6000ES

  Summary of Contents for Frigidaire ATF6000ES

  • Page 1 P12L0054.eps P12C0358.eps P12V0086.eps P12T0088.eps Electrolux Major Appliances North & Latin America P.O. BOX 212378 AUGUSTA, GA 30917 Product No. ATF6000ES1 Series Frigidaire Market North America Color white Volts Wiring Diagram 134604100 Owner's Guide 134609000 Energy Guide 134604200 Installation Instructions 134602900...
  • Page 2: Control Panel

    Publication No: 5995464004 ATF6000ES1 CONTROL PANEL 03/06...
  • Page 3 POS. NO PART NO. 134523106 134364800 134551200 134553100 134556500 134347700 134555600 134555500 134553400 134555400 134595600 134553300 134557500 134557400 134552800 134600000 17 # 134407800 131302800 134402900 134452600 134407900 22 # 134602100 23 # 134436600 23*# 134543100 131205100 134593300 131205300 134371700 131306216 134446300 134371800 36 #...
  • Page 4: Cabinet/Top Parts Diagram

    Publication No: 5995464004 ATF6000ES1 CABINET/TOP 03/06...
  • Page 5 134591500 # Functional Parts * Non-Illustrated Parts ATF6000ES1 CABINET/TOP DESCRIPTION Hose, water inlet, 4 ft., hose & washer Screw, pan head, 8-18B x 0.31 Control Board, motor Wiring Harness, motor control Bracket, angle, motor control Screw, 8-18AB x 0.455 Door Lock/Switch Assy Wiring Harness, door switch Screw, pan head, 10-16AB x 0.500, locking...
  • Page 6 Publication No: 5995464004 ATF6000ES1 MOTOR/TUB 03/06...
  • Page 7 Bolt, carriage, 1/4-20 x 2.60 Counterweight, front, one piece Spring, bellows clamp, retainer Bellows Kit, boot, no light hole Nut, hex, 1/4-20 UNC-2B, (2) Washer, Bellville, spring steel Plate, counterweight Shell, tub, front Spring Assy, suspension Screw, hex head, 6.5 x 51 mm...
  • Page 8: Wiring Diagram

    Publication No: 5995464004 ATF6000ES1 WIRING DIAGRAM 03/06...

This manual is also suitable for:

Atf6000es1Atf6000e
