- Page 1 TEACHING RESOURCES SCHEMES OF WORK DEVELOPING A SPECIFICATION COMPONENT FACTSHEETS HOW TO SOLDER GUIDE ADD A TUNE TO YOUR PRODUCT WITH THIS PROGRAMMABLE MUSIC BOX KIT Version 2.0...
- Page 2 Programmable Music Box Teaching Resources www.kitronik.co.uk/2122 Index of Sheets TEACHING RESOURCES Index of Sheets Introduction Schemes of Work Answers The Design Process The Design Brief Investigation / Research Developing a Specification Design Design Review (group task) Soldering in Ten Steps...
- Page 3 Please feel free to print any pages of this booklet to use as student handouts in conjunction with Kitronik project kits.
- Page 4 Programmable Music Box Teaching Resources www.kitronik.co.uk/2122 Schemes of Work Two schemes of work are included in this pack; the first is a complete project including the design & manufacture of an enclosure for the kit (below). The second is a much shorter focused practical task covering just the assembly of the kit (next page).
- Page 5 Programmable Music Box Teaching Resources www.kitronik.co.uk/2122 Electronics only Hour 1 Introduction to the kit demonstrating a built unit. Using the Soldering in Ten Steps sheet, practice soldering. Hour 2 Build the kit using the Build Instructions . Hour 3 Check the completed PCB and fault find if required using Checking Your Music Box PCB and fault finding flow chart.
-
Page 6: The Design Process
Programmable Music Box Teaching Resources www.kitronik.co.uk/2122 The Design Process The design process can be short or long, but will always consist of a number of Design Brief steps that are the same on every project. By splitting a project into these clearly defined steps, it becomes more structured and manageable. - Page 7 Programmable Music Box Teaching Resources www.kitronik.co.uk/2122 The Design Brief A manufacturer of childrens toys has designed a circuit that plays a tune when a switch is opened or closed. The manufacturer can think of many great applications for this circuit.
- Page 8 Programmable Music Box Teaching Resources www.kitronik.co.uk/2122 Investigation / Research Using a number of different search methods, find examples of similar products that are already on the market. Use additional pages if required. Name Class...
- Page 9 Programmable Music Box Teaching Resources www.kitronik.co.uk/2122 Developing a Specification Using your research into the target market for the product, identify the key requirements for the product and explain why each of these is important. Name Class Requirement Reason Example: The box should have some Example: So that the sound can be heard.
- Page 10 Programmable Music Box Teaching Resources www.kitronik.co.uk/2122 Design Develop your ideas to produce a design that meets the requirements listed in the specification. Name Class...
- Page 11 Programmable Music Box Teaching Resources www.kitronik.co.uk/2122 Design Review (group task) Split into groups of three or four. Take it in turns to review each person s design against the requirements of their specification. Also look to see if you can spot any additional aspects of each design that may cause problems with the final product.
- Page 12 Programmable Music Box Teaching Resources www.kitronik.co.uk/2122 Soldering in Ten Steps 1. Start with the smallest components working up to the taller components, soldering any interconnecting wires last. 2. Place the component into the board, making sure that it goes in the right way around and the part sits flush against the board.
-
Page 13: Resistor Values
Programmable Music Box Teaching Resources www.kitronik.co.uk/2122 Resistor Values A resistor is a device that opposes the flow of electrical current. The bigger the value of a resistor, the more it opposes the current flow. The value of a resistor is given in (ohms) and is often referred to as its ‘resistance’. - Page 14 Programmable Music Box Teaching Resources www.kitronik.co.uk/2122 Calculating resistor markings Calculate what the colour bands would be for the following resistor values. 1st Band 2nd Band Multiplier x alue 3,900 47,000 (47K) 1,000,000 (1M) What does tolerance mean? Resistors always have a tolerance but what does this mean? It refers to the accuracy to which it has been manufactured.
- Page 15 Programmable Music Box Teaching Resources www.kitronik.co.uk/2122 Why Use a PIC Micro-controller? There are a number of advantages to using a micro-controller, some of these are outlined below: Complex functionality can be produced at very low cost. Circuit size can be very small and still provide complex functionality.
- Page 16 Programmable Music Box Teaching Resources www.kitronik.co.uk/2122 Instruction Manual Your music box is going to be supplied with some instructions. Identify four points that must be included in the instructions and give a reason why. Point to include: Point to include:...
- Page 17 Programmable Music Box Teaching Resources www.kitronik.co.uk/2122 Evaluation It is always important to evaluate your design once it is complete. This will ensure that it has met all of the requirements defined in the specification. In turn, this should ensure that the design fulfils the design brief.
- Page 18 Programmable Music Box Teaching Resources www.kitronik.co.uk/2122 Packaging Design If your product was to be sold in a high street electrical retailer, what requirements would the packaging have? List these giving the reason for the requirement. Requirement Reason Develop a packaging design for your product that meets these requirements. Use additional pages if required.
- Page 19 ESSENTIAL INFORMATION BUILD INSTRUCTIONS CHECKING YOUR PCB & FAULT-FINDING MECHANICAL DETAILS HOW THE KIT WORKS ADD A TUNE TO YOUR PRODUCT WITH THIS PROGRAMMABLE MUSIC BOX KIT Version 2.0...
-
Page 20: Build Instructions
Programmable Music Box Essentials www.kitronik.co.uk/2122 Build Instructions Before you start, take a look at the Printed Circuit Board (PCB). The components go in the side with the writing on and the solder goes on the side with the tracks and silver pads. - Page 21 Programmable Music Box Essentials www.kitronik.co.uk/2122 Checking Your Music Box PCB Check the following before you insert the batteries: Check the bottom of the board to ensure that: All the pads with wires in them are properly soldered. Pins next to each other are not soldered together.
-
Page 22: Fault Finding
Programmable Music Box Essentials www.kitronik.co.uk/2122 Fault Finding Start Start Power the board and wait Power the board and wait for 10 seconds for 10 seconds Eventually the Eventually the buzzer worked buzzer worked Did the buzzer Did the buzzer There is a dry... - Page 23 Programmable Music Box Essentials www.kitronik.co.uk/2122 Designing the Enclosure When you design the enclosure, you will need to consider: The size of the PCB (below left). Where the micro-switch will be mounted (bottom right). Where the sounder will be mounted (right).
- Page 24 The test program referenced in the ‘Testing the PCB’ section can be downloaded from the resource section of the Kitronik website at the web address listed at the bottom of this page. We would suggest that you program a chip with this test software.
- Page 25 Programmable Music Box Essentials www.kitronik.co.uk/2122 How the Music Box Hardware Works The music box is based around an eight pin PIC micro-controller device. A PIC is, in effect, a small computer that behaves in a way determined by the software that it’s programmed with. This software is generated by the user / student.
-
Page 26: Online Information
/ omissions in the notes. Kitronik Ltd - Any unauthorised copying / duplication of this booklet or part thereof for purposes except for use with Kitronik project kits is not allowed without Kitronik’s prior consent.
