Frigidaire GLRT18TD Factory Parts Catalog

Top-mount refrigerator.
Hide thumbs

Advertisement

Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet
Installation Instructions 240568300
N05L00003.eps N05DCDBCA1.eps N05BAAABA1.eps N05SAAAFI14.eps
N05CABBAB9.eps
240398801.eps 240398601.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
GLRT183TDQ4 GLRT183TDQ6 GLRT183TDQ8 GLRT183TDW2 GLRT183TDW4 GLRT183TDW6 GLRT183TDW8
R134a
R134a
R134a
bisque
bisque
bisque
115
115
115
240398801
240398801
240398801
240400111
240400111
240400112
North America
North America
North America
240598659
240598659
240598659
240379015
240379015
240379015
240568300
240568300
Publication No.
5995421350
04/11/06
(EN/SERVICE/DCS)
R134a
R134a
white
white
115
115
240398801
240398801
240400111
240400111
North America
North America
240598659
240598659
240379015
240379015
240568300
240568300
TOP-MOUNT
REFRIGERATOR
Model No.
GLRT18TD
390
©
Copyright
2004 Electrolux Home Products, Inc.
All rights reserved.
R134a
R134a
white
white
115
115
240398801
240398801
240400111
240400112
North America
North America
240598659
240598659
240379015
240379015
240568300
240568300

Advertisement

Table of Contents

   Related Manuals for Frigidaire GLRT18TD

   Summary of Contents for Frigidaire GLRT18TD

  • Page 1 240568300 240568300 REFRIGERATOR Publication No. 5995421350 04/11/06 (EN/SERVICE/DCS) Copyright R134a R134a white white 240398801 240398801 240400111 240400112 North America North America 240598659 240598659 240379015 240379015 240568300 240568300 TOP-MOUNT Model No. GLRT18TD © 2004 Electrolux Home Products, Inc. All rights reserved.
  • Page 2 Publication No: 5995421350 11/04 GLRT18TD DOOR N05DCDBCA1...
  • Page 3 240339206 240383401 218252200 240527101 240338101 240337901 240338001 240495804 # Functional Parts * Non-Illustrated Parts GLRT18TD DOOR A GLRT183TD (GLRT183TDQ4) B GLRT183TD (GLRT183TDQ6) C GLRT183TD (GLRT183TDQ8) D GLRT183TD (GLRT183TDW2) E GLRT183TD (GLRT183TDW4) F GLRT183TD (GLRT183TDW6) G GLRT183TD (GLRT183TDW8) DESCRIPTION A B C D E F G...
  • Page 4 Publication No: 5995421350 11/04 GLRT18TD CABINET N05BAAABA1...
  • Page 5 240578901 240335003 240516501 5303001343 240442701 240368206 240368205 240354301 # Functional Parts * Non-Illustrated Parts GLRT18TD CABINET A GLRT183TD (GLRT183TDQ4) B GLRT183TD (GLRT183TDQ6) C GLRT183TD (GLRT183TDQ8) D GLRT183TD (GLRT183TDW2) E GLRT183TD (GLRT183TDW4) F GLRT183TD (GLRT183TDW6) G GLRT183TD (GLRT183TDW8) DESCRIPTION A B C D E F G...
  • Page 6 Publication No: 5995421350 11/04 GLRT18TD CABINET N05BAAABA1...
  • Page 7 241574607 241500302 5303001479 114# 241554901 240479601 5304414035 5303305324 # Functional Parts * Non-Illustrated Parts GLRT18TD CABINET A GLRT183TD (GLRT183TDQ4) B GLRT183TD (GLRT183TDQ6) C GLRT183TD (GLRT183TDQ8) D GLRT183TD (GLRT183TDW2) E GLRT183TD (GLRT183TDW4) F GLRT183TD (GLRT183TDW6) G GLRT183TD (GLRT183TDW8) DESCRIPTION A B C D E F G Screw, hex washer head, 8-15A x 0.625, low profile...
  • Page 8 Publication No: 5995421350 GLRT18TD SHELVES 11/04...
  • Page 9 240364714 240361201 240361301 240337107 240530810 240350650 5308016566 240598659 # Functional Parts * Non-Illustrated Parts GLRT18TD SHELVES A GLRT183TD (GLRT183TDQ4) B GLRT183TD (GLRT183TDQ6) C GLRT183TD (GLRT183TDQ8) D GLRT183TD (GLRT183TDW2) E GLRT183TD (GLRT183TDW4) F GLRT183TD (GLRT183TDW6) G GLRT183TD (GLRT183TDW8) DESCRIPTION A B C D E F G...
  • Page 10 Publication No: 5995421350 GLRT18TD SYSTEM N05CABBAB9 11/04...
  • Page 11 5304418225 5303316859 240500801 240493101 240346201 240553501 5303918222 5303918263 # Functional Parts * Non-Illustrated Parts GLRT18TD SYSTEM A GLRT183TD (GLRT183TDQ4) B GLRT183TD (GLRT183TDQ6) C GLRT183TD (GLRT183TDQ8) D GLRT183TD (GLRT183TDW2) E GLRT183TD (GLRT183TDW4) F GLRT183TD (GLRT183TDW6) G GLRT183TD (GLRT183TDW8) DESCRIPTION A B C D E F G...
  • Page 12 Publication No: 5995421350 GLRT18TD WIRING SCHEMATIC 11/04...
  • Page 13 GLRT18TD Publication No: 5995421350 WIRING DIAGRAM 11/04 # Functional Parts * Non-Illustrated Parts...
