PRODUCT NO.
BASE MODEL NO.
GLRT183SBQ1
GLRT183SB
GLRT183SBW1
GLRT183SB
MARKET
North America
WIRING DIAGRAM - # 240379009
OWNER'S GUIDE - # 240400105
SERVICE DATA SHEET -# 240379009
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
white
Publication No.
5995370532
020419
-EN/SERVICE/DCS
357
FACTORY
PARTS CATALO
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
GLRT183SB
©2002 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire GLRT183SB
Summary of Contents for Frigidaire GLRT183SB
- Page 1 PRODUCT NO. BASE MODEL NO. GLRT183SBQ1 GLRT183SB GLRT183SBW1 GLRT183SB MARKET North America WIRING DIAGRAM - # 240379009 OWNER’S GUIDE - # 240400105 SERVICE DATA SHEET -# 240379009 ELECTROLUX HOME PRODUCTS, INC. P.O. Box 212378, Augusta, GA 30917 SERIES COLOR R134a...
- Page 2 Publication No. GLRT183SB 5995370532 DOOR 04/02...
- Page 3 A = GLRT183SB (GLRT183SBQ1) B = GLRT183SB (GLRT183SBW1) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts GLRT183SB DOOR PART NO DESCRIPTION 240514605 Gasket-frzr door,white ,magnetic 240514608 Gasket-refr door,white ,magnetic 240337703 Door-dairy,w/o graphics ,clear 240381302 Plug-button,bisque ,hinge brg hole ,(2)
- Page 4 Publication No. GLRT183SB 5995370532 CABINET 04/02...
- Page 5 A = GLRT183SB (GLRT183SBQ1) B = GLRT183SB (GLRT183SBW1) POS. NO 10*# 13 # # = Fast-moving Parts * = Non-Illustrated Parts GLRT183SB CABINET PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan...
- Page 6 Publication No. GLRT183SB 5995370532 SHELVES 04/02...
- Page 7 A = GLRT183SB (GLRT183SBQ1) B = GLRT183SB (GLRT183SBW1) POS. NO 17*# 21 # 23 # # = Fast-moving Parts * = Non-Illustrated Parts GLRT183SB SHELVES PART NO DESCRIPTION 240358002 Shelf-freezer,full width 5303299664 Spacer,shelf 240362502 Diffuser,air ,top 240362601 Diffuser,air ,bottom 240505801...
- Page 8 Publication No. GLRT183SB 5995370532 SYSTEM 04/02...
- Page 9 A = GLRT183SB (GLRT183SBQ1) B = GLRT183SB (GLRT183SBW1) POS. NO 6* # 6* # 14 # 15 # 21 # 29 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts GLRT183SB SYSTEM...
-
Page 10: Ice Maker
Publication No. 5995370532 04/02 GLRT183SB ICE MAKER... - Page 11 A = GLRT183SB (GLRT183SBQ1) B = GLRT183SB (GLRT183SBW1) POS. NO 11 # 12 # 13 # 15 # 17 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts GLRT183SB PART NO DESCRIPTION 218976901 Tube-water inlet,inlet valve to ice maker...
-
Page 12: Wiring Schematic
Publication No. GLRT183SB 5995370532 WIRING SCHEMATIC 04/02... -
Page 13: Wiring Diagram
GLRT183SB Publication No. 5995370532 WIRING DIAGRAM # = Fast-moving Parts 04/02 * = Non-Illustrated Parts...
