RS PRO CC908WHB-3 Assembly, Installation And Operation Instructions

CC908WHB-3 is a programmable thermostat designed for water boiler. This thermostat
can be used for hot water radiant heating.
Power source ........................
Relay contact ..............................250VAC 8(3)A
Room temperature setting range.........5℃ to 35℃ (41℉ to 95℉)
Accuracy.................................. ±1℉ or ±0.5℃
Dimensions..............................
Color...................................... White
l Large LCD display
l The screen displays the set temperature and the room temperature also time simultaneously
l Permanent user setting and program setting retention during power loss,
l Optional temperature display of Celsius or Fahrenheit scale
l Both Vacation mold and hold duration mode available for comfort and energy saving
l Separate 5-day (weekday) and 1-day/1-day (Saturday/Sunday programming with four separate
time/temperature periods per day.
l Display temperature recalibrates
l Anti-freezing protection
l Pump protection available
l Always turn off power at the main power source by unscrewing fuse or switching circuit
breaker to the off position before installing, removing, cleaning, or servicing this thermostat.
l Read all of the information in this manual before installing this thermostat.
l Only a professional contractor should install this thermostat.
l All wiring must conform to local and national building and electrical codes and ordinances.
l This thermostat has a removable fuse to protect the system from damage. If system is not
operating properly, check wiring and replace fuse if necessary.
l Use this thermostat only as described in this manual.
PDF 文件使用 "pdfFactory Pro" 试用版本创建
CC908WHB-3 Thermostat for Radiant heating
SPECIFICATION:
2 AA battery
115mm×90mm×28mm
IMPORTANT SAFETY INFORMATION:
Installation and operation instructions
FEATURE:
1
