- Page 1 Global-Tek (Singapore) Pte Ltd Double-Tank Conveyor Type Dish Washing Machine Model - GT-CR2 Instruction & Installation Manual Page 1...
-
Page 2: Table Of Contents
Global-Tek (Singapore) Pte Ltd CONTENTS GENERAL……………………………..…………….. Technical Data..…………………….………….…….. Standard Equipment……..………………..………… INSTALLATION……………………..………………. Unpacking…………………………………………….. Assembly………..……………………………….…… Plumbing Connections……………..…………….…. Drain Connections………………………..…….…… Fill Connection……………………………..…..…….. ELECTRICAL CONNECTIONS…………..……..… 9-10 OPERATION………….……………………………… Preparation………………………………..…………. Operating The Machine………..…………………… 11-12 CLEANING..………….………………………………. MAINTIANANCE……..….………………………….. TROUBLESHOOTING.……………………………... 15-17 CIRCUIT DIAGRAMS………………………………. 18-20 Page 2... -
Page 3: General
Global-Tek (Singapore) Pte Ltd Model : GT-CR-2 GENERAL GT-CR2 Dishwasher is a fully automatic, rack-type double-tank conveyor machine. It have two stainless tanks and chambers with welded stainless steel angle frame, stainless steel legs, and stainless steel adjustable feet. Front inspection doors provide ready access to the interior of the wash chambers. -
Page 4: Standard Equipment
Global-Tek (Singapore) Pte Ltd STANDARD EQUIPMENT The control panel and booster are mounted on the top of the chamber. There are three operational control switches housed in the control panel : POWER -OFF MOTOR (START -STOP );and TIMER (MANUAL -AUTO Mechanical thermostat for wash &... - Page 5 Global-Tek (Singapore) Pte Ltd An over-heat protector is also provided for electric heater. If overheating occurred, the heat supply will be turned off . Turn the POWER switch OFF and contact your authorized service office. Booster Protection The booster water temperature is regulated by two thermostats to keep the rinse water temperature between 82-95℃.
- Page 6 Global-Tek (Singapore) Pte Ltd Wash/Rinse Arms Wash and rinse arms are removable for daily cleaning purpose. Auto Fill Close all doors and push the POWER switch to ON. The machine fills automatically from two different areas, final rinse & fill valve. Water is pre-heated in booster, and flows into wash &...
-
Page 7: Installation
Global-Tek (Singapore) Pte Ltd INSTALLATION UNPACKING Immediately after unpacking the dishwasher, check it for possible shipping damage. If this machine is found to be damaged after unpacking, save the packaging material and contact the carrier within 3 days from date of delivery. -
Page 8: Drain Connections
Global-Tek (Singapore) Pte Ltd DRAIN CONNECTION Connect the drain through a trap to the sewer pipe. FILL CONNECTION Use pipe for the connecting line. The flowing pressure is preset 1.4kg/cm . Water flows into booster and is heated, then into wash tank. After the tank is filled, the float-controlled high-water switch closes the solenoid valve. -
Page 9: Operation
Global-Tek (Singapore) Pte Ltd WARNING: DISCONNECT ELECTRICAL POWER SUPPLY AND PLACE A TAG AT THE DISCONNECT SWITCH TO INDICATE THAT YOU ARE WORKING ON THE CIRCUIT. Some machines may have more than one electrical power supply. All supplies must be disconnected. -
Page 10: Operating The Machine
Global-Tek (Singapore) Pte Ltd Close the drain valve at the bottom of the machine and close the door. Turn POWER switch ON. The pump should be left OFF until the machine has completely filled. Temperature requirement for machine are :... -
Page 11: Cleaning
Global-Tek (Singapore) Pte Ltd CLEANING 1. Turn MOTOR and POWER switches OFF. 2. Open the door. Standard door interlock switches prevent machine operation with inspection door open. 3. Open drain by turning drain valve. 4. Check the upper and lower final rinse nozzles, or auxiliary rinse nozzles (if so equipped) to make sure they are free of lime and solids. - Page 12 Global-Tek (Singapore) Pte Ltd MAINTENANCE WARNING: DISCONNECT ELECTRICAL SUPPLY AND PLACE A TAG AT THE DISCONNECT SWITCH TO INDICATE THAT YOU ARE WORKING ON THE CIRCUIT BEFORE BEGINNING ANY MAINTENANCE PROCEDURE. Some machines may have more than one electrical power supply. All supplies MUST be disconnected.
-
Page 13: Troubleshooting
Global-Tek (Singapore) Pte Ltd TROUBLESHOOTING NOTE: if symptom persists after possible causes have been checked, contact your authorized service office. SYMPTOM POSSIBLE CAUSES No Machine Operation 1. Blow fuse or tripped circuit breaker at power supply. 2. Conveyor may be jammed. - Page 14 Global-Tek (Singapore) Pte Ltd Inadequate Rinse 1. Dirty line strainer causing reduced water flow. Turn off water supply, remove strainer cap, withdraw and clean screen. Reassemble. 2. Low supply pipeline line pressure. 3. Clogged rinse nozzle(s). Spotting of Silverware, 1. Improperly loaded racks.
- Page 15 Global-Tek (Singapore) Pte Ltd No or Slow Fill 1. Dirty line strainer causing reduced water flow. Turn off water supply, remove strainer cap, withdraw and clean screen. Reassemble. 2. Make sure doors are closed. 3. Check interlock switch. 4. Check both upper and lower fill floats for debris and free movement.
- Page 16 Global-Tek (Singapore) Pte Ltd Page 16...
- Page 17 Global-Tek (Singapore) Pte Ltd Page 17...
- Page 18 Global-Tek (Singapore) Pte Ltd Page 18...
