CMP-WNPCI10
Wireless LAN PCI 54 Mbps
Manual
ENGLISH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CMP-WNPCI10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Konig CMP-WNPCI10

Summary of Contents for Konig CMP-WNPCI10

  • Page 1 CMP-WNPCI10 Wireless LAN PCI 54 Mbps Manual ENGLISH...

  • Page 2: Package Contents

    Package Contents The following contents should be found in your box: One 54 Wireless Adapter  One Resource CD including:  Wireless Client Utility (WCU) and Drivers • User Guide • Network cable • Note: If any of the listed contents are damaged or missing, please contact the retailer from whom you purchased the Wireless Adapter for assistance.
  • Page 3 1.3 LED Status 1.3.1 54M Wireless PCI Adapter LED Indications LED Indications Status Working Status The adapter is in an electricity saving status or the Status Green Intermittently adapter is already connected but is not transmitting or receiving data. Status Green Light up The adapter is on wake up status.

  • Page 4: Chapter 2: Installation Guide

    Chapter 2: Installation Guide 2.1 Hardware Installation 2.1.1 54M Wireless PCI Adapter Hardware Installation To install the adapter, follow these steps listed below: Turn off your desktop PC and disconnect the power. Open your PC case and locate an available PCI slot on the motherboard. Remove the metal slot cover on the back of the PC.
  • Page 5 Figure 2-2 Wireless Client Utility Installation Program The Setup Wizard will ask you to choose a Setup type in figure 2-3. It is recommended that you select Install Client Utilities and Driver. Select Install Driver Only to install driver only, select Make Driver Installation Diskette(s) to make the diskette(s) as the installation driver.
  • Page 6 Figure 2-5 Choose Destination Location The Setup Wizard will ask you to create a new folder name or select one from the Existing Folders list shown in figure 2-6. It is recommended that you keep the default value. Click Next to continue the Installation. Click Back to return to the previous page, or click Cancel to end the Installation.
  • Page 7 Figure 2-8 Widows 2000 Warning Box Note: In Windows XP, the warning box is similar to that shown figure 2-8a. Please select Continue Anyway to continue installation. Figure 2-8a Windows XP Warning Box 10. After the files have been successfully copied, the screen in figure 2-9 will appear. Click Finish to reboot the system.

  • Page 8: Chapter 3: Configuration

    Chapter 3: Configuration The Wireless Adapter can be configured by Wireless Client Utility (WCU). This chapter describes how to configure your Wireless Adapter for wireless connectivity on your Wireless Local Area Network (WLAN) and use the data security encryption features. After Installing the Adapter, the Adapter’s tray icon will appear in your system tray.
  • Page 9 Ad Hoc • Configure the network type on the Advanced tab of Profile Management. IP Address - Displays the computer’s IP address.  Current Channel - Shows the currently connected channel.  Data Encryption - Displays the encryption type the driver is using. Configure the ...
  • Page 10 Figure 3-3 General Tab of Profile Management Edit the Security tab Edit the fields in the Security tab of Profile Management to configure the profile. To define the security mode, select the radio button of the desired security mode. WPA - Wi-Fi Protected Access ...
  • Page 11 Edit the Advanced tab Transmit Power Level - Selects the transmit power level for 802.11b/g in mW. Actual  transmit power may be limited by regulatory domain or hardware limitations. Power Save Mode -  Maximum - Selects maximum mode to let the access point buffer incoming •...
  • Page 12 Click Activate. 3.2.4 Import a Profile From the Profile Management tab, click Import…. The Import Profile will then appear. Browse to the directory where the profile is located. Highlight the profile name. Click Open, the imported profile will then appear in the Profiles List. 3.2.5 Export a Profile From the Profile Management tab, highlight the profile to export.

  • Page 13: Declaration Of Confirmity

    DECLARATION OF CONFIRMITY We declare under our responsibility that the product; Brand name: KÖNIG Model: CMP-WNPCI10 Description: Wireless PCI adapter Is in conformity with the following standards; EN 300 328 V.1.4.1 (2003) EN 301 489-1 V.1.4.1 (2002) / EN 301 489-17 V.1.2.1 (2002) EN 60950-1: 2001 Following the provisions of the 1999/5/EC R&TTE Directive.
  • Page 14 www.konigcomputer.com...
