Service Data Sheet 240389626
N58L00001.eps N58FCFEFA3.eps N58RCFAAA0.eps N58BAAAAB2.eps
N58SKDLBD1.eps N58TCAAAB4.eps N58CAAAAA5.eps N58XEAAAA0.eps
N58YDAAAC0.eps N58I115T.eps W241677901.eps S241677901.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
GLHS38EGQ0 GLHS38EGW0 GLHS38EGPB0 GLHS38EGPW0 GLHS38EGSB0
R134a
R134a
R134a
bisque
white
black (smooth) white (smooth)
115
115
115
241677900
241677900
241677900
241695101
241695101
241695101
North America North America North America
241649284
241649284
241649284
240389626
240389626
Publication No.
5995465001
06/04/12
(EN/SERVICE/KHB)
137
R134a
R134a
stainless
115
115
241677900
241677900
241695101
241695101
North America
North America
241649284
241649284
240389626
240389626
SIDE-BY-SIDE
REFRIGERATOR
Model No.
GLHS38EG
©
Copyright
2006 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire GLHS38EG
Summary of Contents for Frigidaire GLHS38EG
- Page 1 241677900 241677900 241695101 241695101 241695101 North America 241649284 241649284 241649284 240389626 240389626 240389626 SIDE-BY-SIDE REFRIGERATOR Model No. GLHS38EG Publication No. 5995465001 06/04/12 (EN/SERVICE/KHB) © Copyright 2006 Electrolux Home Products, Inc. All rights reserved. R134a stainless 241677900 241695101 North America 241649284...
-
Page 2: Freezer Door
Publication No: 5995465001 Stainless Handle Stainless Handle Stainless Handle 04/06 GLHS38EG FREEZER DOOR N58FCFEFA3... - Page 3 218755503 240352102 240552102 5303918256 # Functional Parts * Non-Illustrated Parts GLHS38EG FREEZER DOOR A GLHS38EG (GLHS38EGQ0) B GLHS38EG (GLHS38EGW0) C GLHS38EG (GLHS38EGPB0) D GLHS38EG (GLHS38EGPW0) E GLHS38EG (GLHS38EGSB0) DESCRIPTION A B - D - Gasket-frzr door, white, magnetic - - C - E...
-
Page 4: Refrigerator Door
Publication No: 5995465001 04/06 GLHS38EG REFRIGERATOR DOOR Stainless Handle N58RCFAAA0... - Page 5 218396700 215503200 218755402 218755503 # Functional Parts * Non-Illustrated Parts GLHS38EG REFRIGERATOR DOOR A GLHS38EG (GLHS38EGQ0) B GLHS38EG (GLHS38EGW0) C GLHS38EG (GLHS38EGPB0) D GLHS38EG (GLHS38EGPW0) E GLHS38EG (GLHS38EGSB0) DESCRIPTION A B - D - Gasket-refr door, white, magnetic - - C - E...
- Page 6 Publication No: 5995465001 04/06 GLHS38EG CABINET N58BAAAAB2...
- Page 7 240479601 5304414035 5303321319 5303321321 # Functional Parts * Non-Illustrated Parts GLHS38EG CABINET A GLHS38EG (GLHS38EGQ0) B GLHS38EG (GLHS38EGW0) C GLHS38EG (GLHS38EGPB0) D GLHS38EG (GLHS38EGPW0) E GLHS38EG (GLHS38EGSB0) DESCRIPTION A B C D E Cover-air duct A B C D E...
- Page 8 Publication No: 5995465001 04/06 GLHS38EG SHELVES 140A N58SKDLBD12...
- Page 9 240430501 140A 240430503 240585403 240582701 # Functional Parts * Non-Illustrated Parts GLHS38EG SHELVES A GLHS38EG (GLHS38EGQ0) B GLHS38EG (GLHS38EGW0) C GLHS38EG (GLHS38EGPB0) D GLHS38EG (GLHS38EGPW0) E GLHS38EG (GLHS38EGSB0) DESCRIPTION A B C D E Trim-basket A B C D E...
- Page 10 Publication No: 5995465001 GLHS38EG CONTROLS N58TCAAAB4 04/06...
- Page 11 199* 240398401 240397601 3205266 # Functional Parts * Non-Illustrated Parts GLHS38EG CONTROLS A GLHS38EG (GLHS38EGQ0) B GLHS38EG (GLHS38EGW0) C GLHS38EG (GLHS38EGPB0) D GLHS38EG (GLHS38EGPW0) E GLHS38EG (GLHS38EGSB0) DESCRIPTION A B C D E Fan Blade, red, evaporator fan A B C D E Washer, "slinger", nylon, evap fan shaft...
- Page 12 Publication No: 5995465001 04/06 GLHS38EG SYSTEM N58CAAAAA5...
- Page 13 5303316859 5304421068 240346201 5303918328 5303918222 # Functional Parts * Non-Illustrated Parts GLHS38EG SYSTEM A GLHS38EG (GLHS38EGQ0) B GLHS38EG (GLHS38EGW0) C GLHS38EG (GLHS38EGPB0) D GLHS38EG (GLHS38EGPW0) E GLHS38EG (GLHS38EGSB0) DESCRIPTION A B C D E Condenser A B C D E...
-
Page 14: Ice And Water Dispenser
Publication No: 5995465001 GLHS38EG ICE & WATER DISPENSER 04/06... - Page 15 5304421831 5304421850 5304426535 5303918256 # Functional Parts * Non-Illustrated Parts GLHS38EG ICE & WATER DISPENSER A GLHS38EG (GLHS38EGQ0) B GLHS38EG (GLHS38EGW0) C GLHS38EG (GLHS38EGPB0) D GLHS38EG (GLHS38EGPW0) E GLHS38EG (GLHS38EGSB0) DESCRIPTION A B C D E Tube-water-DOOR A B C D E...
-
Page 16: Ice Container
Publication No: 5995465001 04/06 GLHS38EG ICE CONTAINER 37A 34 34 33 N58YDAAAC0... - Page 17 215005100 241551601 240562101 241561601 # Functional Parts * Non-Illustrated Parts GLHS38EG ICE CONTAINER A GLHS38EG (GLHS38EGQ0) B GLHS38EG (GLHS38EGW0) C GLHS38EG (GLHS38EGPB0) D GLHS38EG (GLHS38EGPW0) E GLHS38EG (GLHS38EGSB0) DESCRIPTION A B C D E Auger-ice A B C D E...
-
Page 18: Ice Maker
Publication No: 5995465001 GLHS38EG ICE MAKER 04/06... - Page 19 55 # 240531101 218709100 240363601 # Functional Parts * Non-Illustrated Parts GLHS38EG ICE MAKER A GLHS38EG (GLHS38EGQ0) B GLHS38EG (GLHS38EGW0) C GLHS38EG (GLHS38EGPB0) D GLHS38EG (GLHS38EGPW0) E GLHS38EG (GLHS38EGSB0) DESCRIPTION A B C D E Tube-water-DOOR A B C D E...
- Page 20 Publication No: 5995465001 GLHS38EG ICE MAKER 04/06...
- Page 21 5304436612 218888001 241583301 241696501 # Functional Parts * Non-Illustrated Parts GLHS38EG ICE MAKER A GLHS38EG (GLHS38EGQ0) B GLHS38EG (GLHS38EGW0) C GLHS38EG (GLHS38EGPB0) D GLHS38EG (GLHS38EGPW0) E GLHS38EG (GLHS38EGSB0) DESCRIPTION A B C D E Cap-water valve A B C D E Screw, hex washer head, 8-18AB x 1.250, spacer, (2)
-
Page 22: Wiring Schematic
Publication No: 5995465001 GLHS38EG WIRING SCHEMATIC 04/06... -
Page 23: Wiring Diagram
GLHS38EG Publication No: 5995465001 WIRING DIAGRAM 04/06 # Functional Parts * Non-Illustrated Parts...
