Service Data Sheet 240389620
N58L00001.eps N58FCFEFA2.eps N58RCCBBB7.eps N58BAAAAB2.eps
N58SKDKBD1.eps N58TCAAAB0.eps N58CAAAAA5.eps N58XEAAAA0.eps
N58YDAAAC0.eps N58I115T.eps W241622001.eps S241622001.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
GLHS38EEQ0 GLHS38EEW0 GLHS38EEPB0 GLHS38EEPW0 GLHS38EESB0
R134a
R134a
R134a
bisque
white
black (smooth) black (smooth) stain/blk
115
115
115
241622001
241622001
241622001
241622402
241622402
241622402
North America North America North America
241607551
241607551
241607553
240389620
240389620
Publication No.
5995434197
05/04/13
(EN/SERVICE/KHB)
357
R134a
R134a
115
115
241622001
241622001
241622402
241622402
North America
North America
241607553
241607568
240389620
240389620
SIDE-BY-SIDE
REFRIGERATOR
Model No.
GLHS38EE
©
Copyright
2005 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire GLHS38EE
Summary of Contents for Frigidaire GLHS38EE
- Page 1 241622001 241622001 241622402 241622402 241622402 North America 241607551 241607553 241607553 240389620 240389620 240389620 SIDE-BY-SIDE REFRIGERATOR Model No. GLHS38EE Publication No. 5995434197 05/04/13 (EN/SERVICE/KHB) © Copyright 2005 Electrolux Home Products, Inc. All rights reserved. R134a 241622001 241622402 North America 241607568 240389620...
-
Page 2: Freezer Door
Publication No: 5995434197 04/05 GLHS38EE FREEZER DOOR N58FCFEFA2... - Page 3 215503200 240352102 240552102 5303918256 # Functional Parts * Non-Illustrated Parts GLHS38EE FREEZER DOOR A GLHS38EE (GLHS38EEQ0) B GLHS38EE (GLHS38EEW0) C GLHS38EEP (GLHS38EEPB0) D GLHS38EEP (GLHS38EEPW0) E GLHS38EES (GLHS38EESB0) DESCRIPTION A B - D - Gasket-frzr door, white - - C - E...
-
Page 4: Refrigerator Door
Publication No: 5995434197 GLHS38EE REFRIGERATOR DOOR 04/05... - Page 5 240430310 240421701 218396700 215503200 # Functional Parts * Non-Illustrated Parts GLHS38EE REFRIGERATOR DOOR A GLHS38EE (GLHS38EEQ0) B GLHS38EE (GLHS38EEW0) C GLHS38EEP (GLHS38EEPB0) D GLHS38EEP (GLHS38EEPW0) E GLHS38EES (GLHS38EESB0) DESCRIPTION A B - D - Gasket-refr door, white, magnetic - - C - E...
- Page 6 Publication No: 5995434197 04/05 GLHS38EE CABINET N58BAAAAB2...
- Page 7 5304414035 5303305324 5303305345 5303001343 # Functional Parts * Non-Illustrated Parts GLHS38EE CABINET A GLHS38EE (GLHS38EEQ0) B GLHS38EE (GLHS38EEW0) C GLHS38EEP (GLHS38EEPB0) D GLHS38EEP (GLHS38EEPW0) E GLHS38EES (GLHS38EESB0) DESCRIPTION A B C D E Cover-air duct A B C D E...
- Page 8 Publication No: 5995434197 GLHS38EE SHELVES N58SKDKBD1 04/05...
- Page 9 240430501 140A 240430503 240585403 240582701 # Functional Parts * Non-Illustrated Parts GLHS38EE SHELVES A GLHS38EE (GLHS38EEQ0) B GLHS38EE (GLHS38EEW0) C GLHS38EEP (GLHS38EEPB0) D GLHS38EEP (GLHS38EEPW0) E GLHS38EES (GLHS38EESB0) DESCRIPTION A B C D E Trim-basket A B C D E...
- Page 10 Publication No: 5995434197 04/05 GLHS38EE CONTROLS N58TCAAAB0...
- Page 11 199* 240398401 240397601 3205266 # Functional Parts * Non-Illustrated Parts GLHS38EE CONTROLS A GLHS38EE (GLHS38EEQ0) B GLHS38EE (GLHS38EEW0) C GLHS38EEP (GLHS38EEPB0) D GLHS38EEP (GLHS38EEPW0) E GLHS38EES (GLHS38EESB0) DESCRIPTION A B C D E Fan Blade, red, evaporator fan A B C D E Washer, "slinger", nylon, evap fan shaft...
- Page 12 Publication No: 5995434197 04/05 GLHS38EE SYSTEM N58CAAAAA5...
- Page 13 5303316859 5304421068 240346201 5303918213 5303918222 # Functional Parts * Non-Illustrated Parts GLHS38EE SYSTEM A GLHS38EE (GLHS38EEQ0) B GLHS38EE (GLHS38EEW0) C GLHS38EEP (GLHS38EEPB0) D GLHS38EEP (GLHS38EEPW0) E GLHS38EES (GLHS38EESB0) DESCRIPTION A B C D E Condenser A B C D E...
-
Page 14: Ice And Water Dispenser
Publication No: 5995434197 GLHS38EE ICE & WATER DISPENSER 04/05... - Page 15 5304421621 5304421831 5304421850 5303918256 # Functional Parts * Non-Illustrated Parts GLHS38EE ICE & WATER DISPENSER A GLHS38EE (GLHS38EEQ0) B GLHS38EE (GLHS38EEW0) C GLHS38EEP (GLHS38EEPB0) D GLHS38EEP (GLHS38EEPW0) E GLHS38EES (GLHS38EESB0) DESCRIPTION A B C D E Tube-water-DOOR A B C D E...
-
Page 16: Ice Container
Publication No: 5995434197 04/05 GLHS38EE ICE CONTAINER 37A 34 34 33 N58YDAAAC0... - Page 17 215005100 241551601 240562101 241561601 # Functional Parts * Non-Illustrated Parts GLHS38EE ICE CONTAINER A GLHS38EE (GLHS38EEQ0) B GLHS38EE (GLHS38EEW0) C GLHS38EEP (GLHS38EEPB0) D GLHS38EEP (GLHS38EEPW0) E GLHS38EES (GLHS38EESB0) DESCRIPTION A B C D E Auger-ice A B C D E...
-
Page 18: Ice Maker
Publication No: 5995434197 04/05 GLHS38EE ICE MAKER INSTALLATION PARTS N58I115T... - Page 19 5303001343 5303001193 5308000133 241523503 # Functional Parts * Non-Illustrated Parts GLHS38EE ICE MAKER A GLHS38EE (GLHS38EEQ0) B GLHS38EE (GLHS38EEW0) C GLHS38EEP (GLHS38EEPB0) D GLHS38EEP (GLHS38EEPW0) E GLHS38EES (GLHS38EESB0) DESCRIPTION A B C D E Tube-water-DOOR A B C D E...
- Page 20 Publication No: 5995434197 04/05 GLHS38EE ICE MAKER INSTALLATION PARTS N58I115T...
- Page 21 218888001 240599901 241583301 241627701 # Functional Parts * Non-Illustrated Parts GLHS38EE ICE MAKER A GLHS38EE (GLHS38EEQ0) B GLHS38EE (GLHS38EEW0) C GLHS38EEP (GLHS38EEPB0) D GLHS38EEP (GLHS38EEPW0) E GLHS38EES (GLHS38EESB0) DESCRIPTION A B C D E Valve-water, triple solenoid A B C D E Screw, hex head, 10-32 x 0.500...
-
Page 22: Wiring Schematic
F R E E Z E R L I G H T / S A F E T Y S W I TC H 04/05 GLHS38EE WIRING SCHEMATIC ( L I N E ) ( N E U T R A L ) E VA P. -
Page 23: Wiring Diagram
J 1 0 N TC F F P2 AIR FILTER FAN 2 4 1 6 2 2 0 0 1 # Functional Parts * Non-Illustrated Parts GLHS38EE WIRING DIAGRAM D I O D E D I O D E P O W E R...
