- Page 1 Argos 3D - P32X Quick Start Guide Version 4...
- Page 2 This document is protected by copyright. All rights reserved. No part of this document may be reproduced or transmitted for any purpose in any form or by any means, electronically or mechanically, without expressly written permission by Bluetechnix GmbH. Windows is a registered trademark of Microsoft. © BECOM Bluetechnix 2017...
-
Page 3: Table Of Contents
Version Information ............Error! Bookmark not defined. 5.1.2 Anomalies ................Error! Bookmark not defined. Argos3D-P321 ................Error! Bookmark not defined. 5.2.1 Version Information ............Error! Bookmark not defined. 5.2.2 Anomalies ................Error! Bookmark not defined. Document Revision History ....................13 © BECOM Bluetechnix 2017... - Page 4 More information is found in the General Terms and Conditions (AGB). Information For further information on technology, delivery terms and conditions and prices please contact Bluetechnix (http://www.bluetechnix.com). Warning Due to technical requirements components may contain dangerous substances. © BECOM Bluetechnix 2017...
-
Page 5: Unboxing
Quick Start Guide - Argos 3D - P32X Last change: 20 February 2017 Version 4 Unboxing In the box Argos3D–P32X CAT5/7 Ethernet Cable Quick Start Guide Power Supply * * Note The power supply’s operating temperature is specified from 0 to +40°C. This represents not the effective working temperature of the Argos3D–P32X sensor! Opening your Argos3D–P32X To access the connector compartment unscrew the two screws on the Argos3D-P32X front and take... -
Page 6: Connecting Your Argos3D-P32X
Quick Start Guide - Argos 3D - P32X Last change: 20 February 2017 Version 4 Connecting your Argos3D–P32X Connector Overview a. Power Connector g. RS232 / RS485 b. Ethernet h. DIP-Switch c. General purpose input 1 & 2 Reset-Button d. General purpose output 1 & 2 Debug-UART e. -
Page 7: Connecting The Power Supply
Quick Start Guide - Argos 3D - P32X Last change: 20 February 2017 Version 4 1.4.1 Connecting the power supply To ensure, that your Argos3D–P32X works correctly, connect the ‘Argos3D’ to a 12-30V DC power supply using connector (a) and wait for approximately 20 seconds until the camera boots up. Pin assignment on the power connector (a): Pin #1: +12V to +30V, Pin#2: GND Note The power supply connector is protected against wrong polarity but the ‘Argos3D’... -
Page 8: Downloading The Evaluation Software
Quick Start Guide - Argos 3D - P32X Last change: 20 February 2017 Version 4 Downloading the Evaluation Software Please log in to our support website at https://support.bluetechnix.com/ and download the Argos-P32X customer software package. This package also includes the Bluetechnix ToF-Suite. Support website Select ‚free access‘... -
Page 9: Start-Up Screen
Quick Start Guide - Argos 3D - P32X Last change: 20 February 2017 Version 4 Start-up screen Figure 2-2: Start-up screen Please select your product: Argos 3D – P32X Please follow the instructions on the WEB-Site © Bluetechnix 2017 Page 9 | 13... -
Page 10: Prepare Your Network Interface Card (Nic)
Quick Start Guide - Argos 3D - P32X Last change: 20 February 2017 Version 4 Prepare your Network Interface Card (NIC) Once you have connected your Argos3D–P32X to a Network Interface Card (NIC) of your PC give this NIC the IP-Address 192.168.0.1 with a subnet mask of 255.255.255.0. No driver must be installed on your PC! The Argos3D–P32X uses IP-Address 192.168.0.10 with subnet mask 255.255.255.0. -
Page 11: Start Using Your Argos3D-P32X With 'Blttofsuite
Quick Start Guide - Argos 3D - P32X Last change: 20 February 2017 Version 4 Start using your Argos3D–P32X with ‘BltTofSuite’ Browse to the directory where you previously saved the BltTofSuite software zip file. Unzip the software. Using this software you can simply display the depth image and the amplitude image of the Argos3D–P32X. For a detailed introduction to the software, please read the ‘Bluetechnix ToF Suite - Quick Start Guide’... -
Page 12: System Requirements & Support
Quick Start Guide - Argos 3D - P32X Last change: 20 February 2017 Version 4 System Requirements & Support An Argos3D–P32X enabled application is required in order to use this ‘Argos3D’ device. Connect to a system with: Operating System: Microsoft Windows XP/7/Vista ... -
Page 13: Document Revision History
Quick Start Guide - Argos 3D - P32X Last change: 20 February 2017 Version 4 Document Revision History Version Date Document Revision 20151012 First draft 20160210 Removed BltTofSuite section 20160610 Support for Argos3D-P321 added 20170203 Renamed to P32X Product changes removed. Please refer to HUM for product changes. Table 5.1: Revision history ©...
