RESORT EXTRUSIONS BIG SKY TOWER 60D Manual

BIG SKY TOWER 60D - 6FT X 16FT (BACKLIT)
RESORT EXTRUSIONS
PRODUCT CODE: BIGSKYT60D6X16-LLFRM On frame On graphic

PRODUCT DESCRIPTION

The Big Sky Tower is part of the Resort Extrusion family—aluminum
frames for Silicone-Edge Graphics (SEG). Custom-made on the
premises, Big Sky Tower comes in varied sizes. Big Sky Tower
accepts four individual custom fabric graphics, excluding top and
bottom. Insert graphics after frame is constructed by tilting it on its
side. Transversely, push corners of graphic into the frame's recessed
groove. Then, starting midway on the frame going toward the corners,
continue pushing in the straight edges of the graphic. Repeat three
times. Backlit option is available.
DISPLAY DIMENSION 6" L x 6" W x 16" H
GRAPHIC DIMENSIONS 72" W x 192" H
GRAPHIC MATERIAL
UV Backlit Fabric
GRAPHIC FINISHING
Silicone beading is sewn around the perimeter of the fabric
graphic. Silicone beading is hidden from view once installed.
DISPLAY CONSTRUCTION
Aluminum Extrusion Frame
LADDER LIGHTS SPECIFICATION
EACH LIGHT BEAD .068-.43W
ANGLE 120°
OPERATING VOLTAGE 12V
TOTAL WATTAGE 350-600W MAX
TOTAL AMPERAGE 29A MAX
TRANSFORMER SPECIFICATION
OUTPUT 12V/29A
INPUT 100-120VAC/7.0A
200-240VAC/4.0A
50/60Hz
SHIPPING WEIGHTS & DIMENSIONS
Shipping Weight 124 lbs (frame only)
132 lbs (with graphics)
48" H x 18" W x 11.5" D
Shipping Dimensions
GRAPHIC TURN AROUND TIME
2 business days after proof approval
AVAILABILITY
Top View
CA
