INSTRUCTION MANUAL 20V Max LI-ION CORDLESS DRILL/DRIVER KIT TDCD03P Operation /Safety Instruction TDCD03P 20V Max Drill /Driver Kit TECCPO is committed to providing the best After-sale Service,we strive for your FIVE STAR satisfaction! support@teccpo.net / support@teccpotools.com...
Page 3
Original Instructions Description of Symbols The rating plate on your tool may show symbols.These represent important information about the product or instructions on its use. Wear hearing protection Wear eye protection Wear breathing protection Wear head protection Wear hand protection Read instruction manual DO NOT incinerate batteries! Caution!
Environmental Protection Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your local authority or retailer for recycling advice. Li -Ion Conforms to relevant legislation and safety standards. Li-ion battery cells are recyclable and should not be disposed of with household waste.
Product Features TDCD03P 20V Max Drill /Driver Kit 1. Chuck 2. Torque Selector 3. Gear Switch 4. Motor Vents 5. Forward/Reverse Switch ACCESSORY 6. Trigger Switch 2.0Ahr Li-ion Battery Pack 2pcs 7. Soft Grip Handle Fast Charger 8. Working Light...
Page 6
hands below a normal comfortable temperature, as vibration will have a greater effect. Use the figures provided in the specification relating to vibration to calculate the duration and frequency of operating the tool. Sound and vibration levels in the specification are determined according to EN60745 or similar international standards.
Page 7
3) Personal safety a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
Page 8
5) Battery tool use and care a) Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack b) Use power tools only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire.
Page 9
l) If you are interrupted when operating the drill, complete the process and switch off before looking up m) Where possible, use clamps or a vice to hold your work n) Examine the chuck regularly for signs of wear or damage. Have damaged parts repaired by a qualified service centrer) ALWAYS wait until the drill has com o) ALWAYS wait until the drill has come to a complete stop before putting it down p) Periodically check all nuts, bolts and other fixings and tighten where necessary...
Page 10
TD HD 01 Remove the Battery from the tool by pressing the Battery Release, then slide the Battery out of the ive r Kit er Dri ll /Dr 18V Ha mm Battery Slot. WARNING: DO NOT try to remove the Battery without pressing the Battery Release button. The tool or Battery could be damaged.
Page 11
Battery and the Battery Charger slot are clean and undamaged and that the contacts are not bent. 2. Once charging commences, the Red LED will on. 3. When the Battery is fully charged, the Red LED will off and Green LED will on. Battery Charge Level: The Battery has a built-in Battery Charge Indicator Pressing on the button to the right will indicate the charge level.
3. Tighten the Chuck Jaws by rotating the Chuck Collar clockwise 4. When the drill bit or accessory is securely fastened, carefully run the Machine to test that it is running centrally, smoothly and evenly. If the bit is 'wobbling' or not running centrally, release the chuck, check the accessory for damage, correct its position, retighten and test again.
Page 13
Note: ALWAYS read the documentation provided with drill bits and accessories for the recommended or maximum speed setting and use the most appropriate gear. See ‘Specification’ for the maximum no load speed of each gear. Switching on/off WARNING: ALWAYS wear adequate personal protection equipment when setting up and operating this machine.
Page 14
- Use a countersink bit to remove sharp burrs from the hole, preventing cuts and other kinds of injury WARNING: If the power tool gets excessively hot in use, stop using the tool immediately and allow to cool before continuing work. The cooling period can be reduced by operating the drill at maximum speed with no load.
Page 15
Disposal Always adhere to national regulations when disposing of power tools that are no longer functional and are not viable for repair. - Do not dispose of power tools, or other waste electrical and electronic equipment (WEEE), with household waste - Contact your local waste disposal authority for information on the correct way to dispose of power tools...
Page 20
Shenzhen Allsight E-business Co., Ltd Web:www.teccpotools.com Facebook:www.facebook.com/Teccpo.US E-mail:support@teccpotools.com ADD:Room 104, Building P09, south China City Electronic trading Center, Longgang District, Shen Zhen, CHINA Made in China...
