Frigidaire FRU17G4J Factory Parts Catalog

Frigidaire FRU17G4J Factory Parts Catalog

R134a series
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRU17G4JW0
FRU17G4J
MARKET
USA
WIRING DIAGRAM - # 216758400
OWNER'S GUIDE - # 216781800
SERVICE DATA SHEET - #216758400
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O.Box 212378, Augusta, GA 30917
FACTORY PARTS CATALOG
SERIES
R134a
.
Publication No.
5995353389
010507
-EN/SERVICE /DJH
365
REFRIGERATOR
COLOR
white
REFRIGERATOR
Model No.
FRU17G4J
©2001 White Consolidated Industries, Inc.
All rights reserved

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRU17G4J and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRU17G4J

Summary of Contents for Frigidaire FRU17G4J

  • Page 1 PRODUCT NO. BASE MODEL NO. FRU17G4JW0 FRU17G4J MARKET WIRING DIAGRAM - # 216758400 OWNER’S GUIDE - # 216781800 SERVICE DATA SHEET - #216758400 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O.Box 212378, Augusta, GA 30917 FACTORY PARTS CATALOG REFRIGERATOR SERIES COLOR R134a white Publication No.
  • Page 2 Publication No. FRU17G4J 5995353389 DOOR 05/01...
  • Page 3 * = Non-Illustrated Parts FRU17BG4J DOOR PART NO DESCRIPTION 216522309 Gasket-door,white 216527815 Panel-inner door,white 216526518 Panel-outer door,white 316095402 Label-nameplate,Frigidaire ,white 216373000 Frame-nameplate 08016354 Door Stop 5303313518 Washer,sealing 218762701 Handle-door,white 08005520 Screw-door stop mtg,flat hd metric ,4.0 x 0.7-19.7 218252200 Screw,#8 truss hd ,10-32CA x 0.500...
  • Page 4 Publication No. FRU17G4J 5995353389 CABINET 05/01...
  • Page 5 POS. NO 10 # 13 # 14 # 15 # 16 # 137A 138A # = Fast-moving Parts * = Non-Illustrated Parts FRU17BG4J CABINET PART NO DESCRIPTION 216503100 Screen-drain 216325600 Fan Blade 216604200 Breaker Kit w/corners 216603300 Breaker Kit w/corners,32" ,top or bottom 216768500 Heater-Drain Pan Assy 216710400...
  • Page 6 Publication No. FRU17G4J 5995353389 SYSTEM 05/01...
  • Page 7 POS. NO 14A# 15 # 29 # # = Fast-moving Parts * = Non-Illustrated Parts FRU17BG4J SYSTEM PART NO DESCRIPTION 5300083897 Condenser 5308000110 Strap-evap/heater,aluminum ,(2) 216634500 Drier-filter 216722200 Harness-main 216695300 Relay 216703900 Thermostat-heater 216730700 Heater-defrost 216730500 Heater-internal 216737300 Evaporator 216751100 Heat Exchanger 216727600 Insulator-evap,styrofoam...
