- Page 1 CEILING DETECTOR/ALARM WITH REMOTE CONTROL Cat No. TG123SK...
- Page 2 Ceiling Detector/Alarm with Remote Control – TG123SK Please read the instructions before using the product and retain for future use. Tough impact 105dB alarm resistant case detection lens Low battery warning LED Remote control LED Infra Red Sensor Remote control unit...
- Page 3 Introduction The TG123SK detects intruders (moving heat sources) within a 5 to 7m diameter circle centred directly underneath it. It has a 105dB alarm which sounds on detection and can be armed and disarmed using a key fob remote control. Entry and exit delays along with low battery voltage warning are built into the unit.
-
Page 4: Remote Control
Battery Installation/Change Main Unit Push the catch in the direction of the arrow on the battery cover until it releases from the case, then push it upwards away from the case to release the cover (see fig 2). If necessary remove the connector from the battery and connect a new alkaline PP3 battery, taking care to get the polarity correct. - Page 5 Main unit – rear view Fig 2 Four keyhole fixings Case Lugs Battery Battery compartment compartment cover Catch Fig 3 Remote control – rear view Case slides Press down Catch here Battery compartment cover Slide out...
-
Page 6: Installation
Installation The TG123SK is ceiling mounted and gives an approx. 5m diameter coverage at a ceiling height of 2.4m. At 3m ceiling height the floor level coverage is approx. 7m diameter. Choose a ceiling position where an intruder would be most likely to pass under. -
Page 7: Points To Note
Fig 4 Fixing Template 30.5mm Actual Size 36.0mm Points to Note • For indoor use only. • Keep away from direct sunlight. • Loud alarm – keep away from ears. • Do not locate near radiators or heaters. • Do not locate near fans. -
Page 8: Operation
Operation When any key on the remote is pressed the LED on the remote flashes rapidly to show that it is operating correctly. Remote control LED DISARM button ARM button Red PANIC button Key chain Fig 5... - Page 9 20 second delay the alarm sounds for 2 periods of 30 seconds separated by 30 seconds of silence. Disarming Press the DISARM button on the remote control (this also stops the TG123SK if it is already sounding the alarm).
-
Page 10: Panic Button
Panic Button If you need help in an emergency press the PANIC button which will sound the alarm for a 30 second period and then stop. To silence the alarm before the 30 seconds is up press the DISARM button. Battery Warning When the main unit battery is reaching the end of its life a bleep will sound, followed... -
Page 11: Specifications
Specifications IR detection: 5 – 7m diameter circle at floor level Alarm: 105dB Batteries: PP3 Alkaline (main unit) 3 x SR44 or similar* (remote) *357, SR44W, RW42, SG13, SR1154, V303, A THREE YEAR GUARANTEE 3 Year Guarantee In the unlikely event of this product becoming faulty due to defective material or manufacture within 3 years of the date of purchase, please return it to your... - Page 12 HELPLINE 020-8450-0515 For a product brochure please contact: Timeguard Ltd. Victory Park, 400 Edgware Road, London NW2 6ND 020-8452-1112 or email csc@timeguard.com...
