Door & window alarm

Advertisement

DOOR & WINDOW
ALARM
Cat No. TG232W

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TG232W and is the answer not in the manual?

Questions and answers

Summary of Contents for Time Guard TG232W

  • Page 1 DOOR & WINDOW ALARM Cat No. TG232W...
  • Page 2 TG232W Door & Window Alarm Please read the instructions before using the product and retain for future use. PP3 battery (not supplied) Alarm/chime Battery connector Chime off/alarm slide switch Battery cover Fig 1...
  • Page 3 Introduction The TG232W uses a magnetically operated sensor to detect doors and windows being opened. It has two selectable sounder modes – alarm and chime. The high output alarm (105dB) is useful when you wish to deter intruder entry and the chime mode can be used when you wish to be informed of movements at entry points or within the building.
  • Page 4 Installation Alarm unit Fig 2 Door/window frame Door/window Arrow facing arrow Magnet Switch Alarm unit Keyhole fixings Fig 3 (rear view)
  • Page 5 Installation Decide on a position for the alarm unit and magnet/sensor ensuring that the twin flex is sufficiently long to connect the sensor to the alarm unit and that there is good access to the slide switch and battery compartment on the alarm unit.
  • Page 6: Specifications

    Checking Operation Move the slide switch to chime and open the door or window. A two tone chime will occur immediately and will only repeat if the door/window is closed and opened again. Slide the switch to alarm and repeat the above test. The alarm will sound for around 30 seconds then stop unless the slide switch is moved to off.
  • Page 7 3 Year Guarantee In the unlikely event of this product becoming faulty due to defective material or manufacture within 3 years of the date of purchase, please return it to your supplier in the first year with proof of purchase and it will be replaced free of charge.
  • Page 8 HELPLINE 020-8450-0515 For a product brochure please contact: Timeguard Ltd. Victory Park, 400 Edgware Road, London NW2 6ND 020-8452-1112 or email csc@timeguard.com...
