Profimess SW-06 Operating Instructions Manual

Varible area flowswitch
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Profimess GmbH
Twischlehe 5
D-27580 Bremerhaven
Operating instructions
SW-06
Varible Area Flowswitch
Status: February 2015
Technical modifications reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SW-06 and is the answer not in the manual?

Questions and answers

Related Manuals for Profimess SW-06

Summary of Contents for Profimess SW-06

  • Page 1 Profimess GmbH Twischlehe 5 D-27580 Bremerhaven Operating instructions SW-06 Varible Area Flowswitch Status: February 2015 Technical modifications reserved...
  • Page 2 Profimess GmbH Twischlehe 5 27570 Bremerhaven Germany Telephone: +49 471 98 24 - 151 Fax: +49 471 98 24 - 152 email: info@profimess.de Internet: www.profimess.com 23.02.2015...
  • Page 3 – even in part – as well as dissemina- tion and/or communication of their con- tent is forbidden without prior written authorization from PROFIMESS Limitations of liability ("manufacturer"). Violations All details and instructions in this...

  • Page 4: Table Of Contents

    Table of contents Table of contents Overview...................... 7 1.1 Short description.................. 7 1.2 Warranty and guarantee provisions............. 7 1.3 Customer service................. 7 Safety......................8 2.1 Explanation of symbols................ 8 2.2 Correct use in accordance with these instructions......10 2.3 Special precautions................11 2.3.1 Hazards from electrical current............
  • Page 5 Table of contents 5.2 Requirements at the place of installation........... 25 5.3 Preparatory work................26 5.4 Installation in the pipe system............29 5.5 Initial startup..................33 5.6 Electrical connection................34 5.6.1 Connector DIN 43650..............35 5.6.2 Plug connector M12x1..............36 5.6.3 Cable....................
  • Page 6 Table of contents 9.3 Return Materials................. 65 9.3.1 Return Materials Authorization............65 9.4 Disposal..................... 66 Technical data................... 67 10.1 Device data plate................67 10.2 Switch contact data plate..............67 10.3 Dimension sheet................68 10.4 General specifications..............71 10.5 Electrical specifications..............74 10.6 Measuring ranges................

  • Page 7: Overview

    Fig. 1: SW-06 flow monitor Switch point adjustment scale Switch contact with female socket or sealed-in cable The flow monitor SW-06 monitors the continuous flow of liquids. It is designed for installation in pipe sys- tems. A float inside the device is moved by the medium flowing through it.

  • Page 8: Safety

    Safety Explanation of symbols Safety 2.1 Explanation of sym- This chapter provides an overview of important safety aspects required for bols optimum protection of personnel as Safety instructions well as for safe installation and safe operation of the device. Safety instructions in this manual are marked by symbols.
  • Page 9 Safety Explanation of symbols Designates step-by-step han- dling instructions CAUTION! ð Designates a state or an This combination of symbol and automatic sequence as a signal word indicates a possibly result of a specific operating dangerous situation that might step result in minor or slight injuries if it is not avoided.

  • Page 10: Correct Use In Accordance With These Instructions

    The intended use in explosion-hazard zones is described in the Operating – Only use the flow monitor with Instructions for "SW-06 Module ATEX". media previously approved by the manufacturer Intended use in explosion-hazard – Do not use the flow monitor as...

  • Page 11: Special Precautions

    Operating Instructions for “SW-06 Module ATEX" including – Before commencing work on all hazard statements and warn- live parts of the electrical sys- ings, therein.

  • Page 12: Mechanical Hazards

    Safety Special precautions > Mechanical hazards 2.3.2 Mechanical hazards – Never bridge fuses or put them out of operation. Always observe the correct current WARNING! ratings when replacing fuses – Keep moisture away from live Risk of injury due to fractured parts.

  • Page 13: Hazards From High Or Low Temperatures

    Safety Special precautions > Radiation hazards 2.3.3 Hazards from high 2.3.4 Radiation hazards or low temperatures Strong magnetic fields Hot or cold surfaces WARNING! WARNING! Danger to life from strong mag- netic fields! Risk of injury from hot or cold surfaces! Strong magnetic fields may cause severe injuries or even be fatal, as...

  • Page 14: Hazards Caused By Media

    Safety Personnel requirements 2.4 Personnel require- – Do not place any electronic ments storage media, credit cards, etc. within the vicinity of the magnetic source. Data could WARNING! be deleted Risk of injury due to use of insufficiently trained and quali- fied personnel! 2.3.5 Hazards caused by If unqualified personnel work on...

  • Page 15: Personal Safety Equipment

    Safety Personal safety equipment The following lists the personnel quali- When performing the various tasks at, fications for the various areas of and with the device, personnel must activity: wear personal safety equipment. Spe- cial reference is made of this in the Qualified electrician individual chapters within these Oper- Due to specialized training, knowledge...

  • Page 16: Protective Systems

    Safety Spare parts 2.6 Protective systems Protective gloves protect the hands from friction, burns, grazing, abrasion, Integration within an emergency- surface cuts or deeper injuries, as well stop concept is required as from direct contact with hot or cold surfaces. The device is designed for use as a part of a machine or system.

  • Page 17: Environmental Protection

    Safety Responsibility of the owner Always purchase spare parts from an Cleaning fluids authorized dealer or directly from the Solvent-based cleaning fluids contain manufacturer (For contact details, see toxic substances. They must never be Page 2). released into the environment and The spare parts list is in the annex.
  • Page 18 Safety Responsibility of the owner In addition to the safety instructions The owner must clearly regulate contained in these Operating Instruc- and determine responsibilities for tions, the safety, accident prevention installation, operation, trouble- and environmental protection regula- shooting, maintenance and tions applicable to the field of applica- cleaning.
  • Page 19 Safety Responsibility of the owner The owner must ensure that the maintenance intervals described in these Operating Instructions are adhered to at all times. The owner must ensure that the device is completely free of any residual media before disposal. Remains of corrosive or toxic materials must be neutralized.

  • Page 20: Design And Function

    Switch point adjustment scale Process connection (inlet) 3.2 Device description SW-06 flow monitors work according to the functional principle of the variable area flow meter. The flow monitor is installed into a pipe system and meas- ures the flow rate of the medium flowing through the pipe system.

  • Page 21: Component Description

    Component description 3.3 Component descrip- Switch point adjustment scale tion Switch contact Fig. 4: SW-06 switch point adjustment scale A scale is applied to the device body, Fig. 3: Switch contact and female to which the desired switch point can socket be adjusted.

  • Page 22: Transport, Packaging And Storage

    Transport, packaging and storage Packaging Transport, packaging and storage 4.1 Safety instructions 4.2 Transport inspec- for transport tion On delivery, make an immediate check for completeness and check for trans- port damages. Improper transport If there are any visible external trans- port damages then proceed as follows: NOTICE! Do not accept the delivery...

  • Page 23: Symbols On The Shipping Box

    Transport, packaging and storage Storage Handling packaging materials Fragile Dispose of packaging material in accordance with the valid legal regula- tions and local ordinances. NOTICE! Designates packages with breakable Danger to the environment due or damageable contents. to incorrect disposal! Handle the package carefully and do Packaging is made of valuable raw not allow it to fall or be subjected to jar-...
  • Page 24 Transport, packaging and storage Storage Storage instructions in addition to the instructions listed here may be listed on the packages. Follow these instructions also. 23.02.2015...

  • Page 25: Installation And Initial Startup

    Installation and initial startup Requirements at the place of installation Installation and initial startup 5.1 Safety Safeguard against restart Incorrect installation and initial startup WARNING! Danger to life due to unauthor- ized restart! WARNING! There is a risk of severe or even Risk of injury due to incorrect fatal injuries from unauthorized installation and initial startup!

  • Page 26: Preparatory Work

    Installation and initial startup Preparatory work The flow monitor must be installed in such a way as to preclude WARNING! damage by outside force. It must be ensured that the flow monitor Danger due to incorrect installa- cannot be damaged. If necessary, tion! install an appropriate impact pro- If the criteria listed above are not...
  • Page 27 Installation and initial startup Preparatory work Only install the flow monitor in one of Unimpeded flow sections the positions displayed in the drawing. The medium must flow in the direction of the arrow (from a low to a high scale NOTICE! value).
  • Page 28 Installation and initial startup Preparatory work Unimpeded outlet Fig. 7: Unimpeded outlet If the pipe system ends at an unim- peded outlet, the flow monitor must not be installed directly in front of the opening. The device must always be completely filled with media to ensure measuring accuracy.

  • Page 29: Installation In The Pipe System

    Installation and initial startup Installation in the pipe system Strainer Prepare the device NOTICE! Risk of damage to property due to contamination! Contamination and deposits may impair the free movement of the float, thereby damaging the device. – Ensure that there are no for- eign particles in the device –...
  • Page 30 Installation and initial startup Installation in the pipe system WARNING! WARNING! Risk of injury from pressurized Risk of injury from media in the pipes! pipe system! If the pipe system is under pres- If the pipe system contains haz- sure when installing the device, ardous media, severe injuries may severe injuries may result.
  • Page 31 Installation and initial startup Installation in the pipe system Sealing the pipe connections Personnel: Qualified personnel A suitable sealant must be selected depending on the condi- Nap the thread. tion/composition of the pipe lines, the medium and the operating and environmental conditions.
  • Page 32 Installation and initial startup Installation in the pipe system Apply sealing thread (Fig. 9/1) to Install device in pipe system the napped thread in the Personnel: threaded direction. Observe the Qualified personnel quantity recommended by the sealant manufacturer. Protective equipment: Protective gloves Tool: Fixed spanner...

  • Page 33: Initial Startup

    Installation and initial startup Initial startup 5.5 Initial startup The following steps must be carried out before initial startup and any subse- quent startup (e.g. after removal and installation during maintenance). WARNING! Make sure that the plant is operating vibration-free. Vibrations could destroy the Fig.

  • Page 34: Electrical Connection

    Installation and initial startup Electrical connection 5.6 Electrical connec- tion NOTICE! The electrical connection of the flow Vent the pipe line. If there monitor is accomplished through the are air bubbles in the line connector plug or the cast on power during the measurement cable leading from the switch housing.

  • Page 35: Connector Din 43650

    Installation and initial startup Electrical connection > Connector DIN 43650 5.6.1 Connector DIN – Secure against switching 43650 back on – Check for absence of Wiring diagram of the supplied voltage socket (DIN 43650, Form A) (Front view). – Ground and short –...

  • Page 36: Plug Connector M12X1

    Installation and initial startup Electrical connection > Plug connector M12x1 5.6.2 Plug connector M12x1 Wiring diagram, socket (M12x1) Fig. 15: Switch position under no-flow condition Fig. 17: Pin-assignment, socket M12x1 Form 30x70) Fig. 16: Pin assignment, plug socket, change-over contact. The ground-pin is Wiring diagram not used.

  • Page 37: Cable

    Installation and initial startup Plug connection 5.6.4 Degree of protection (IP-Code) The specified degree of protection (IP) is only ensured if approved connection material is used (see following table). Fig. 19: Switch position under no-flow Device Specifi- Degree of condition connec- cation protection...
  • Page 38 Installation and initial startup Plug connection Personnel: Qualified electrician Tool: Flat-bladed screwdriver Fig. 20: Detach socket Release the fixing screw Fig. 22: Loosen inner section (Fig. 20) from the socket Remove the inner section from the socket by inserting a flat- bladed screwdriver into the slot (Fig.
  • Page 39 Installation and initial startup Plug connection Place the female socket onto the connecting plug and tighten the fixing screw (Fig. 20/1) Fig. 23: Loosen the screw connection Unscrew the screw connection Fig. 24: Pin assignment, plug socket, (Fig. 23/1) by turning in the Normally Open Contact (Form 30x70) direction of the arrow Guide the connecting cable...

  • Page 40: Contact Protection Measures

    Installation and initial startup Contact protection measures Inductive load There is danger of voltage peaks from inductive loads when switching off (up to 10 times the rated voltage). Induc- tive loads are caused by, e.g.: Contactors, relays Solenoid valves Electric motors Examples of protective measures: Fig.
  • Page 41 Installation and initial startup Contact protection measures Protection against ohmic loads can be achieved through installation of a resistor in the circuit, or by heating the glow filament. For connection to high- impedance consumers (ex. PLC), a protective circuit is not needed. Fig.

  • Page 42: Operation

    Operation Switch point adjustment Operation 6.1 Switch point adjust- Fig. 31: Loosen set screws ment Loosen the set screws of the switch contact (Fig. 31/1) using Setting the switch point of an a flat-bladed screwdriver. installed device Set the switch contact to the flow value to be monitored.
  • Page 43 Operation Switch point adjustment ð The set switch point corre- Setting the switch point of a non- sponds to the switch-off installed device point of the switch contact by decreasing flow. Fig. 32: Loosen the set screws Loosen the set screws of the switch contact (Fig.

  • Page 44: Checking The Flow

    Operation Checking the flow 6.2 Checking the flow Read-off the switch value from the switch point adjustment Reading-off the switch value scale Personnel: Qualified personnel Protective equipment: Goggles Fig. 33: Reading-off the switch point (sample scale) Make sure that the setting arrow, the scale mark on the additional label on the guide rail and the scale mark of the switchpoint...

  • Page 45: Troubleshooting

    Troubleshooting Safety Troubleshooting 7.1 Safety This chapter describes possible mal- functions of the device, their causes Work carried out incorrectly to and repair. remedy a malfunction If malfunctions persist or increase, shorten the maintenance interval to meet the actual operating conditions. WARNING! For malfunctions not described in this Risk of injury due to incorrect...
  • Page 46 Troubleshooting Safety Conduct in case of malfunction The complete machine or system may be unsafe if there is a defect at the flow monitor (e.g. fractured housing). The following always applies: In case of malfunctions that present an immediate danger to persons or valuables, proceed according to the valid emer- gency plans for the system...

  • Page 47: Troubleshooting Guide

    Troubleshooting Troubleshooting guide 7.2 Troubleshooting guide Fault description Cause Remedy Personnel The switch contact No medium Check that medium is Qualified does not switch. flowing through flowing through the pipe- personnel flow monitor line Flow is too low or Adjust the switch Qualified the switch con- contact to a lower...
  • Page 48 Troubleshooting Troubleshooting guide Fault description Cause Remedy Personnel Float is stuck Disassemble and clean Qualified the device personnel Switch contact is Remedy the cause of Qualified defective the defect (short-cir- personnel cuit, overload) Replace the switch contact The switch point is Improper scale Request proper conver- Qualified...

  • Page 49: Maintenance

    8.2 Maintenance plan Maintenance work performed incor- Intervals for replacement of wear rectly parts SW-06 type flow monitors require very little maintenance due to the small WARNING! number of moving parts. The intervals for the replacement of wear parts Risk of injury due to mainte-...

  • Page 50: Removal From The Pipe System

    Maintenance Removal from the pipe system Interval Maintenance work Personnel Visual inspection for dirt/soiling Qualified personnel Visual inspection for free-movement of float Qualified personnel Visual inspection for leaks from the device Qualified personnel Check function of switch contact Qualified personnel 8.3 Removal from the pipe system WARNING!

  • Page 51: Disassembly

    Maintenance Disassembly Removing the device from the pipe system WARNING! Personnel: Risk of injury from media in the Qualified personnel pipe system! Protective equipment: If the pipe system contains haz- ardous media, severe injuries may With hazardous media, the protec- be caused by escaping media.
  • Page 52 Maintenance Disassembly Protective equipment: With hazardous media, the protec- WARNING! tive equipment specified in the Risk of injury due to incorrect Safety Data Sheet of the medium disassembly! must be worn. In addition, the specifications of the system oper- – The device may still contain ator must be followed.
  • Page 53 Maintenance Disassembly Fig. 34: Loosen process connection Fig. 35: Remove the process connec- (outlet) tion (outlet) Loosen the process connection 2. Unscrew the process connec- (outlet) (Fig. 34) using the tion (outlet) from the device body proper sized fixed spanner (Fig.
  • Page 54 (outlet) 3. Remove the centering disc (outlet) from the slot nozzle (Fig. 36) Fig. 38: Inner parts SW-06 The inner parts of the flow mon- itor consist of the centering disc (inlet) (Fig. 38/1), float (Fig. 38/2), spring (Fig. 38/3), slot nozzle (Fig.

  • Page 55: Maintenance

    Maintenance Maintenance Fig. 39: Loosen process connection Fig. 40: Remove the process connec- (inlet) tion (inlet) 6. Loosen the process connec- 7. Unscrew the process connec- tion (inlet) (Fig. 39) (Fig. 39) tion (inlet) from the device body using the proper sized fixed (Fig.

  • Page 56: Cleaning

    Maintenance Maintenance > Cleaning 8.5.1 Cleaning CAUTION! It is the responsibility of the operator to establish appropriate intervals and pro- Risk of injury due to damaged cedures for cleaning the individual parts! parts of the device. It must be ensured If parts of the device are broken or that the parts are not damaged during damaged, they may cause injury...

  • Page 57: Parts Replacement

    Maintenance Maintenance > Assembly Protective equipment: Personnel: With hazardous media, the protec- Qualified personnel tive equipment specified in the Tool: Safety Data Sheet of the medium Flat-bladed screwdriver must be worn. In addition, the specifications of the system oper- Torque screwdriver and assorted ator must be followed.
  • Page 58 Maintenance Maintenance > Assembly Carefully install the O-rings (Fig. 41/2) with the aid of the O- ring installation tool (Fig. 41/1) onto the process connections (inlet and outlet), so that they are properly seated in the O-ring grooves of the process connec- tion (Fig.
  • Page 59 Maintenance Maintenance > Assembly Fig. 44: Tighten process connection Fig. 45: Inner parts (inlet) The inner parts of the flow mon- Using a proper sized fixed itor consists of the centering disc spanner tighten the process con- (inlet) (Fig. 45/1), nection (inlet).
  • Page 60 Maintenance Maintenance > Assembly Insert centering disc (inlet), float, spring and slot nozzle into the device body (Fig. 46) Fig. 48: Insert process connection (outlet) Insert the process connection Fig. 47: insert centering disc (outlet) (outlet) into the device body (Fig.
  • Page 61 Maintenance Maintenance > Assembly Fig. 49: Tighten process connection Fig. 50: Check for smooth operation (outlet) Check the float for ease of Using a proper sized fixed movement (Fig. 50) by applying spanner, tighten the process light pressure with the test rod connection (outlet).

  • Page 62: Switch Contact Replacement

    Maintenance Maintenance > Switch contact replacement 8.5.4 Switch contact replacement Tool: Flat-bladed screwdriver Fig. 51: Loosen female socket Loosen the fixing screw of the female socket (Fig. 51) with a Fig. 53: Loosen set screws flat-bladed screwdriver Using a flat-bladed screwdriver (Fig.
  • Page 63 Maintenance Maintenance > Switch contact replacement Fig. 54: Remove the switch contact Fig. 55: Remove switch contact from guide rails Remove the switch contact from Slide the switch contact from the the device guide rail (Fig. 54) in the direc- Position the new switch contact tion of the arrow Slide the switch contact onto the...

  • Page 64: Measures To Be Taken After Maintenance Work

    Maintenance Measures to be taken after maintenance work 8.6 Measures to be Slowly push the switch contact in the direction of flow until the taken after mainte- contact opens. This switch point nance work should be set as precisely as possible because it affects the Take the following steps after comple- accuracy of the switch point...

  • Page 65: Dissambly And Disposal

    – In case of doubt, contact the provisions of the returns policy set by manufacturer Profimess will apply. Return shipments which do not comply with the returns policy may be refused by Profimess at the expense of the consignor. 23.02.2015...

  • Page 66: Disposal

    Dissambly and disposal Disposal 9.4 Disposal If no return or disposal agreement has been made then recycle disassembled components: Scrap metals Recycle plastic elements Dispose of the remaining compo- nents according to their material properties NOTICE! Danger to the environment due to incorrect disposal! Potential risk to the environment may arise due to incorrect dis-...

  • Page 67: Technical Data

    Technical data Switch contact data plate Technical data 10.1 Device data plate The data plate is on the mechanical part of the flow monitor/flow meter and contains the following information: 1. Ordering number 2. Operating range 3. Process connection 4. Serial number 5.

  • Page 68: Dimension Sheet

    Technical data Dimension sheet 10.3 Dimension sheet Fig. 58: Type SW-06.X.X.1.08 23.02.2015...
  • Page 69 Technical data Dimension sheet Fig. 59: Type SW-06.X.X.1.10 23.02.2015...
  • Page 70 Technical data Dimension sheet Fig. 60: Type SW-06.X.X.1.13a und SW-06.X.X.1.14 23.02.2015...

  • Page 71: General Specifications

    Technical data General specifications 10.4 General specifications Type Overall dimensions (mm) SW-06 ½ SW-06 ½ SW-06 ½ SW-06 ½ SW-06 ½ SW-06 ½ SW-06 ½ SW-06 SW-06 23.02.2015...
  • Page 72 Technical data General specifications Type Overall dimensions (mm) SW-06 SW-06 1 1/4 SW-06 1 1/4 1 ½ SW-06 1 1/4 1 ½ Type Overall dimensions (mm) weight (g) ** SW-06 ½ SW-06 ½ SW-06 ½ SW-06 23.02.2015...
  • Page 73 Technical data General specifications Type Overall dimensions (mm) weight (g) ** ½ SW-06 ½ SW-06 ½ SW-06 ½ SW-06 1400 1100 SW-06 1400 1100 SW-06 1400 1100 SW-06 1 1/4 50 2750 SW-06 1 1/4 50 3000 1 ½ 3800...

  • Page 74: Electrical Specifications

    Technical data Electrical specifications 10.5 Electrical specifications Change-Over Contact (COC) Data Value Unit Voltage 250 V Current, maximum 1,5 A Power, maximum 50 VA Minimum load 3 VA Normally Open Contact (NOC) Data Value Unit Voltage 250 V Current, maximum Power, maximum 100 VA Change-Over Contact (COC) M12x1 (-20 °C–85 °C)

  • Page 75: Measuring Ranges

    60 VA 10.6 Measuring ranges 10.6.1 Standard measuring ranges Type Switch range for H O at 20 °C* l/min SW-06.X.X.1.01. 0,2 – 4 3,0 – 63,5 SW-06.X.X.1.03. 0,6 – 5 9,5 – 79,0 SW-06.X.X.1.04. 0,5 –8 8,0 – 127,0 SW-06.X.X.1.05.

  • Page 76: Operating Data

    Operating data for devices employed in explosion hazard zones differs from the above. The operating data for devices employed in explosion hazard zones are specified in the Operating Instruc- tions for "SW-06 Module ATEX", Chapter 4. 23.02.2015...

  • Page 77: Annex

    Annex Replacement parts list Annex 11.1 Tightening torque Component/ Description Size Torque Number function Threaded ring Threaded ring G1" 40 Nm (inlet/outlet) Threaded ring Threaded ring G5/4" 10 Nm (inlet/outlet) Threaded ring Threaded ring G6/4" 10 Nm (inlet/outlet) Process con- Process con- G1"...
  • Page 78 Annex Replacement parts list The following replacement parts drawing provides an example of the construction of a SW-06 type flow monitor. The actual configuration may vary depending on the model. Fig. 61: Type SW-06.X.X.1.08 Item Nr. of pieces Description Process connection (inlet)
  • Page 79 Annex Replacement parts list Item Nr. of pieces Description Spring Float Process connection (outlet) Guide rail Fixing screws, (guide rail) Switch contact with male connector Female socket and gasket Fixing screw (female socket) Washer Set screw (switch contact) 23.02.2015...
  • Page 80 Annex Replacement parts list Fig. 62: Type SW-06.X.X.1.10 Item Nr. of pieces Description Process connection (inlet) O-ring (seal) Centering disc Device body Pin (outlet) slot nozzle Slot nozzle Spring 23.02.2015...
  • Page 81 Annex Replacement parts list Item Nr. of pieces Description Float Process connection (outlet) Guide rail Fixing screws, (guide rail) Switch contact with male connector Female socket and gasket Fixing screw (female socket) Washer Set screw (switch contact) 23.02.2015...
  • Page 82 Annex Replacement parts list Fig. 63: Type SW-06.X.X.1.13a und SW-06.X.X.1.14 Item Nr. of pieces Description Threaded ring (inlet) Device body Pin (outlet) slot nozzle Slot nozzle Spring Float 23.02.2015...

  • Page 83: Tools

    Annex Sealant Item Nr. of pieces Description Threaded ring (outlet) Guide rail Fixing screws, (guide rail) Switch contact with male connector Female socket and gasket Fixing screw (female socket) Washer Set screw (switch contact) 11.3 Tools 11.4 Sealant The following tools are required: Tool Before using a sealant, ensure that Fixed spanner 30, 35, 41, 50, 60...

  • Page 84: Lubricants

    Annex Lubricants 11.5 Lubricants Before using a lubricant, always make sure that it is compatible with the oper- ating medium. For the proper mounting of O-rings, an O-ring installation tool may be purchased from the manufacturer. The following lubricants are suitable to facilitate installing the O-rings: Lubricant O-ring material EPDM...
  • Page 85 Profimess GmbH Twischlehe 5 D-27580 Bremerhaven Operating instructions SW-06 Varible Area Flowmeter and Switch Status: February 2015 Technical modifications reserved...
  • Page 86 Profimess GmbH Twischlehe 5 27570 Bremerhaven Germany Telephone: +49 471 98 24 - 151 Fax: +49 471 98 24 - 152 email: info@profimess.de Internet: www.profimess.com 23.02.2015...
  • Page 87 – even in part – as well as dissemina- tion and/or communication of their con- tent is forbidden without prior written authorization from PROFIMESS Limitations of liability ("manufacturer"). Violations All details and instructions in this...
  • Page 88 Table of contents Table of contents Overview...................... 7 1.1 Short description.................. 7 1.2 Warranty and guarantee provisions............. 7 1.3 Customer service................. 7 Safety......................8 2.1 Explanation of symbols................ 8 2.2 Correct use in accordance with these instructions......10 2.3 Special precautions................11 2.3.1 Hazards from electrical current............
  • Page 89 Table of contents 5.2 Requirements at the place of installation........... 26 5.3 Preparatory work................27 5.4 Installation in the pipe system............32 5.5 Initial startup..................36 5.6 Electrical connection................37 5.6.1 Connector DIN 43650..............38 5.6.2 Plug connector M12x1..............39 5.6.3 Cable....................
  • Page 90 Table of contents 9.3 Return Materials................. 74 9.3.1 Return Materials Authorization............74 9.4 Disposal..................... 74 Technical data................... 75 10.1 Device data plate................75 10.2 Switch contact data plate..............75 10.3 Dimension sheet................76 10.4 General specifications..............79 10.5 Electrical specifications..............82 10.6 Measuring ranges................

  • Page 91: Overview

    The flow monitor SW-06 monitors the continuous flow of liquids. It is designed for installation in pipe sys- tems. 23.02.2015...

  • Page 92: Safety

    Safety Explanation of symbols Safety 2.1 Explanation of sym- This chapter provides an overview of important safety aspects required for bols optimum protection of personnel as Safety instructions well as for safe installation and safe operation of the device. Safety instructions in this manual are marked by symbols.
  • Page 93 Safety Explanation of symbols Designates step-by-step han- dling instructions CAUTION! ð Designates a state or an This combination of symbol and automatic sequence as a signal word indicates a possibly result of a specific operating dangerous situation that might step result in minor or slight injuries if it is not avoided.

  • Page 94: Correct Use In Accordance With These Instructions

    The intended use in explosion-hazard – Only use the flow monitor with zones is described in the Operating media previously approved by Instructions for "SW-06 Module the manufacturer ATEX". – Do not use the flow monitor as the sole monitoring device to...

  • Page 95: Special Precautions

    Operating Instructions for "SW-06 Module ATEX" – Before commencing work on including all hazard statements live parts of the electrical sys- and warnings, therein.

  • Page 96: Mechanical Hazards

    Safety Special precautions > Mechanical hazards 2.3.2 Mechanical hazards – Never bridge fuses or put them out of operation. Always observe the correct current WARNING! ratings when replacing fuses – Keep moisture away from live Risk of injury due to fractured parts.

  • Page 97: Hazards From High Or Low Temperatures

    Safety Special precautions > Radiation hazards 2.3.3 Hazards from high 2.3.4 Radiation hazards or low temperatures Strong magnetic fields Hot or cold surfaces WARNING! WARNING! Danger to life from strong mag- netic fields! Risk of injury from hot or cold surfaces! Strong magnetic fields may cause severe injuries or even be fatal, as...

  • Page 98: Hazards Caused By Media

    Safety Personnel requirements 2.4 Personnel require- – Do not place any electronic ments storage media, credit cards, etc. within the vicinity of the magnetic source. Data could WARNING! be deleted Risk of injury due to use of insufficiently trained and quali- fied personnel! 2.3.5 Hazards caused by If unqualified personnel work on...

  • Page 99: Personal Safety Equipment

    Safety Personal safety equipment The following lists the personnel quali- When performing the various tasks at, fications for the various areas of and with the device, personnel must activity: wear personal safety equipment. Spe- cial reference is made of this in the Qualified electrician individual chapters within these Oper- Due to specialized training, knowledge...

  • Page 100: Protective Systems

    Safety Spare parts 2.6 Protective systems Protective gloves protect the hands from friction, burns, grazing, abrasion, Integration within an emergency- surface cuts or deeper injuries, as well stop concept is required as from direct contact with hot or cold surfaces. The device is designed for use as a part of a machine or system.

  • Page 101: Environmental Protection

    Safety Responsibility of the owner Always purchase spare parts from an Cleaning fluids authorized dealer or directly from the Solvent-based cleaning fluids contain manufacturer (For contact details, see toxic substances. They must never be Page 2). released into the environment and The spare parts list is in the annex.
  • Page 102 Safety Responsibility of the owner In addition to the safety instructions The owner must clearly regulate contained in these Operating Instruc- and determine responsibilities for tions, the safety, accident prevention installation, operation, trouble- and environmental protection regula- shooting, maintenance and tions applicable to the field of applica- cleaning.
  • Page 103 Safety Responsibility of the owner The owner must ensure that the maintenance intervals described in these Operating Instructions are adhered to at all times. The owner must ensure that the device is completely free of any residual media before disposal. Remains of corrosive or toxic materials must be neutralized.

  • Page 104: Design And Function

    The pointer of the indicator scale shows the actual flow rate. Applications for SW-06 flow monitors are, for example, cooling circuits. The device monitors the volume flow of the cooling media to ensure sufficient cooling.

  • Page 105: Component Description

    3.3 Component descrip- Scale on the device body tion Switch contact Fig. 4: Scale on the device body SW-06 A scale is applied to the device body, Fig. 3: Switch contact and female to which the desired switch point can socket be adjusted.
  • Page 106 Design and function Component description Indicator scale Fig. 5: Indicator scale SW-06 On the device, a display housing is mounted with integral indicator scale and pointer. The pointer displays the current flow value. 23.02.2015...

  • Page 107: Transport, Packaging And Storage

    Transport, packaging and storage Packaging Transport, packaging and storage 4.1 Safety instructions 4.2 Transport inspec- for transport tion On delivery, make an immediate check for completeness and check for trans- port damages. Improper transport If there are any visible external trans- port damages then proceed as follows: NOTICE! Do not accept the delivery...

  • Page 108: Symbols On The Shipping Box

    Transport, packaging and storage Storage Handling packaging materials Fragile Dispose of packaging material in accordance with the valid legal regula- tions and local ordinances. NOTICE! Designates packages with breakable Danger to the environment due or damageable contents. to incorrect disposal! Handle the package carefully and do Packaging is made of valuable raw not allow it to fall or be subjected to jar-...
  • Page 109 Transport, packaging and storage Storage Storage instructions in addition to the instructions listed here may be listed on the packages. Follow these instructions also. 23.02.2015...

  • Page 110: Installation And Initial Startup

    Installation and initial startup Requirements at the place of installation Installation and initial startup 5.1 Safety Safeguard against restart Incorrect installation and initial startup WARNING! Danger to life due to unauthor- ized restart! WARNING! There is a risk of severe or even Risk of injury due to incorrect fatal injuries from unauthorized installation and initial startup!

  • Page 111: Preparatory Work

    Installation and initial startup Preparatory work The flow monitor must be installed in such a way as to preclude WARNING! damage by outside force. It must be ensured that the flow monitor Danger due to incorrect installa- cannot be damaged. If necessary, tion! install an appropriate impact pro- If the criteria listed above are not...
  • Page 112 Installation and initial startup Preparatory work Installation position/direction of flow Fig. 6: Installation position/direction of flow Only install the flow monitor in one of the positions displayed in the drawing. The medium must flow in the direction of the arrow (from a low to a high scale value). 23.02.2015...
  • Page 113 Installation and initial startup Preparatory work Unimpeded flow sections NOTICE! Measuring inaccuracy due to incorrect installation! The measuring accuracy of the flow monitor is influenced by its position within the pipe system. Changes in cross-section, branch- offs or bends in the pipe system impair measuring accuracy.
  • Page 114 Installation and initial startup Preparatory work Unimpeded outlet Fig. 8: Unimpeded outlet If the pipe system ends at an unimpeded outlet, the flow monitor must not be installed directly in front of the opening. The device must always be completely filled with media to ensure measuring accuracy.
  • Page 115 Installation and initial startup Preparatory work Strainer Prepare the device NOTICE! Risk of damage to property due to contamination! Contamination and deposits may impair the free movement of the float, thereby damaging the device. – Ensure that there are no for- eign particles in the device –...

  • Page 116: Installation In The Pipe System

    Installation and initial startup Installation in the pipe system 5.4 Installation in the pipe system WARNING! Risk of injury from hot or cold surfaces! Pipelines can heat up/cool down dramatically due to the media WARNING! flowing through them. Skin contact Risk of injury from pressurized with hot or cold surfaces may pipes!
  • Page 117 Installation and initial startup Installation in the pipe system WARNING! A suitable sealant must be Risk of injury from media in the selected depending on the condi- pipe system! tion/composition of the pipe lines, If the pipe system contains haz- the medium and the operating and ardous media, severe injuries may environmental conditions.
  • Page 118 Installation and initial startup Installation in the pipe system Sealing the pipe connections Personnel: Qualified personnel Nap the thread. Fig. 11: Pipe connection with sealing thread ð The pipe line is now ready for installation (Fig. 11) Fig. 10: Apply sealing thread Apply sealing thread (Fig.
  • Page 119 Installation and initial startup Installation in the pipe system Install device in pipe system Personnel: Qualified personnel Protective equipment: Protective gloves Tool: Fixed spanner CAUTION! Fig. 13: Screw in the device Do not hold the device by its Keep turning in the adapter threads.

  • Page 120: Initial Startup

    Installation and initial startup Initial startup 5.5 Initial startup NOTICE! The following steps must be carried out before initial startup and any subse- Vent the pipe line. If there quent startup (e.g. after removal and are air bubbles in the line installation during maintenance).

  • Page 121: Electrical Connection

    Installation and initial startup Electrical connection 5.6 Electrical connec- – Secure against switching tion back on – Check for absence of The electrical connection of the flow voltage monitor is accomplished through the connector plug or the cast on power –...

  • Page 122: Connector Din 43650

    Installation and initial startup Electrical connection > Connector DIN 43650 5.6.1 Connector DIN 43650 Wiring diagram of the supplied socket (DIN 43650, Form A) (Front view). Wiring diagram Fig. 16: Switch position under no-flow normally open: condition Fig. 14: Switch position under no-flow condition Fig.

  • Page 123: Plug Connector M12X1

    Installation and initial startup Electrical connection > Cable 5.6.2 Plug connector M12x1 Wiring diagram, socket (M12x1) Fig. 20: Switch position under no-flow condition 5.6.3 Cable The individual cores of the cable are numbered according to the following connection diagrams. Wiring diagram normally open: change over: Fig.

  • Page 124: Degree Of Protection (Ip-Code)

    Installation and initial startup Plug connection 5.6.4 Degree of protection Personnel: (IP-Code) Qualified electrician The specified degree of protection (IP) Tool: is only ensured if approved connection Flat-bladed screwdriver material is used (see following table). Device Specifi- Degree of connec- cation protection tion...
  • Page 125 Installation and initial startup Plug connection Fig. 23: Loosen inner section Remove the inner section from Fig. 24: Loosen the screw connection the socket by inserting a flat- bladed screwdriver into the slot Unscrew the screw connection (Fig. 23/1) and carefully pry out (Fig.

  • Page 126: Contact Protection Measures

    Installation and initial startup Contact protection measures Place the female socket onto the connecting plug and tighten the fixing screw (Fig. 21/1) Fig. 26: Pin assignment, plug socket, Change-over contact (Form 30x70) 5.9 Contact protection Fig. 25: Pin assignment, plug socket, measures Normally Open Contact (Form 30x70) The Reed-switches used in the switch...
  • Page 127 Installation and initial startup Contact protection measures Inductive load There is danger of voltage peaks from inductive loads when switching off (up to 10 times the rated voltage). Induc- tive loads are caused by, e.g.: Contactors, relays Fig. 29: Protective measure against capacitive loads Solenoid valves Electric motors...
  • Page 128 Installation and initial startup Contact protection measures Protection against ohmic loads can be achieved through installation of a resistor in the circuit, or by heating the glow filament. For connection to high- impedance consumers (ex. PLC), a protective circuit is not needed. 23.02.2015...

  • Page 129: Operation

    Operation Setting the switch point Operation 6.1 Setting the switch Fig. 32: Loosen set screws point Loosen the set screws of the switch contact (Fig. 32/1) using Setting the switch point of an a flat-bladed screwdriver. installed device Set the switch contact to the flow value to be monitored.
  • Page 130 Operation Setting the switch point ð The set switch point corre- Setting the switch point of a non- sponds to the switch-off installed device point of the switch contact by decreasing flow. Fig. 33: Loosen the set screws Loosen the set screws of the switch contact (Fig.

  • Page 131: Checking The Flow

    Operation Checking the flow 6.2 Checking the flow Read-off the switch value from the scale on the device body Reading-off the switch value Personnel: Qualified personnel Protective equipment: Goggles Fig. 34: Reading-off the switch point value Make sure that the setting arrow, the scale mark on the posi- tioning aid label (adhesive label on the guide rail) and the appro-...
  • Page 132 Operation Checking the flow Read-off displayed value Personnel: Qualified personnel Protective equipment: Goggles Fig. 35: Read-off display value Make sure that the pointer and the scale graduation mark on the display scale are in alignment (Fig. 35). To obtain the greatest reading accuracy, look straight on.

  • Page 133: Troubleshooting

    Troubleshooting Safety Troubleshooting 7.1 Safety This chapter describes possible mal- functions of the device, their causes Work carried out incorrectly to and repair. remedy a malfunction If malfunctions persist or increase, shorten the maintenance interval to meet the actual operating conditions. WARNING! For malfunctions not described in this Risk of injury due to incorrect...
  • Page 134 Troubleshooting Safety Conduct in case of malfunction The complete machine or system may be unsafe if there is a defect at the flow monitor (e.g. fractured housing). The following always applies: In case of malfunctions that present an immediate danger to persons or valuables, proceed according to the valid emer- gency plans for the system...

  • Page 135: Troubleshooting Guide

    Troubleshooting Troubleshooting guide 7.2 Troubleshooting guide Fault description Cause Remedy Personnel The switch contact No medium Check that medium is Qualified does not switch. flowing through flowing through the pipe- personnel flow monitor line Flow is too low or Adjust the switch Qualified the switch con- contact to a lower...
  • Page 136 Troubleshooting Troubleshooting guide Fault description Cause Remedy Personnel Float is stuck Disassemble and clean Qualified the device personnel Switch contact is Remedy the cause of Qualified defective the defect (short-cir- personnel cuit, overload) Replace the switch contact The switch point is Improper scale Request proper conver- Qualified...

  • Page 137: Maintenance

    8.2 Maintenance plan Maintenance work performed incor- Intervals for replacement of wear rectly parts SW-06 type flow monitors require very little maintenance due to the small WARNING! number of moving parts. The intervals for the replacement of wear parts Risk of injury due to mainte-...

  • Page 138: Removal From The Pipe System

    Maintenance Removal from the pipe system Interval Maintenance work Personnel Visual inspection for dirt/soiling Qualified personnel Visual inspection for free-movement of float Qualified personnel Visual inspection for leaks from the device Qualified personnel Check function of switch contact Qualified personnel 8.3 Removal from the pipe system WARNING!

  • Page 139: Disassembly

    Maintenance Disassembly Removing the device from the pipe system WARNING! Personnel: Risk of injury from media in the Qualified personnel pipe system! Protective equipment: If the pipe system contains haz- ardous media, severe injuries may With hazardous media, the protec- be caused by escaping media.
  • Page 140 Maintenance Disassembly Protective equipment: With hazardous media, the protec- WARNING! tive equipment specified in the Risk of injury due to incorrect Safety Data Sheet of the medium disassembly! must be worn. In addition, the specifications of the system oper- – The device may still contain ator must be followed.
  • Page 141 Maintenance Disassembly Remove fixing screws from the Fig. 38 display housing cover (Fig. 36) Press out the display cover plate from the plastic housing(Fig. 38) Fig. 37 Carefully remove the display Fig. 39 housing cover plate and plastic Pull the scale support (with housing from the display base affixed scale) from the guides in plate by lifting straight up...
  • Page 142 Maintenance Disassembly Fig. 41: Loosen process connection Fig. 42: Remove the process connec- (outlet) tion (outlet) Loosen the process connection Unscrew the process connection (outlet) (Fig. 41) using the (outlet) from the device body proper sized fixed spanner Fig. 42). If necessary, remove wrench.
  • Page 143 Fig. 43: Remove the centering disc (outlet) Remove the centering disc (outlet) from the slot nozzle (Fig. 43) Fig. 45: Inner parts SW-06 The inner parts of the flow mon- itor consist of the centering disc (inlet) (Fig. 45/1), float (Fig. 45/2), spring (Fig. 45/3), slot nozzle (Fig.

  • Page 144: Maintenance

    Maintenance Maintenance Fig. 46: Loosen process connection Fig. 47: Remove process connec- (inlet) tion )inlet) Loosen the process connection Unscrew the process connection (inlet) (Fig. 46) using the proper (inlet) from the device body sized fixed spanner wrench. (Fig. 47). If necessary, remove Hold the device body in place the O-rings from the process using a proper sized spanner...

  • Page 145: Cleaning

    Maintenance Maintenance > Cleaning 8.5.1 Cleaning CAUTION! It is the responsibility of the operator to establish appropriate intervals and pro- Risk of injury due to damaged cedures for cleaning the individual parts! parts of the device. It must be ensured If parts of the device are broken or that the parts are not damaged during damaged, they may cause injury...

  • Page 146: Parts Replacement

    Maintenance Maintenance > Assembly Protective equipment: Personnel: With hazardous media, the protec- Qualified personnel tive equipment specified in the Tool: Safety Data Sheet of the medium Flat-bladed screwdriver must be worn. In addition, the specifications of the system oper- Torque screwdriver and assorted ator must be followed.
  • Page 147 Maintenance Maintenance > Assembly Carefully install the O-rings (Fig. 48/2) with the aid of the O- ring installation tool (Fig. 48/1) onto the process connections (inlet and outlet), so that they are properly seated in the O-ring grooves of the process connec- tion (Fig.
  • Page 148 Maintenance Maintenance > Assembly Fig. 51: Tighten process connection Fig. 52: Inner parts (inlet) The inner parts of the flow mon- Using a proper sized fixed itor consists of the centering disc spanner tighten the process con- (inlet) (Fig. 45/1), float nection (inlet).
  • Page 149 Maintenance Maintenance > Assembly Insert centering disc (inlet), float, spring and slot nozzle into the device body (Fig. 53) Fig. 55: Insert process connection (outlet) Insert the process connection Fig. 54: insert centering disc (outlet) (outlet) into the device body (Fig.
  • Page 150 Maintenance Maintenance > Assembly Fig. 56: Tighten process connection Fig. 57: Check for smooth operation (outlet) Check the float for ease of Using a proper sized fixed movement (Fig. 57) by applying spanner, tighten the process light pressure with the test rod connection (outlet).
  • Page 151 Maintenance Maintenance > Assembly Fig. 58 Fig. 60 Position the display base plate Insert the scale support (with onto the device body and lightly affixed scale) into the guides in tighten the fixing screws so that the plastic housing (Fig. 60). the base plate can still be moved Observe direction of flow (lowest (Fig.
  • Page 152 Maintenance Maintenance > Assembly Secure the switch contact with Adjust the display base plate the set screws, observing the with attached plastic housing proper torque ( Ä Chapter 11.1 and scale so that the cut-off “Tightening torque” on page 85) value on the display scale corre- while ensuring that the switch sponds to the value on the scale...

  • Page 153: Switch Contact Replacement

    Maintenance Maintenance > Switch contact replacement 8.5.4 Switch contact replacement Tool: Flat-bladed screwdriver Fig. 62 Screw in and tighten the fixing screw of the display housing cover(Fig. 62), observing the proper torque ( Ä Chapter 11.1 “Tightening torque” on page 85). Fig.
  • Page 154 Maintenance Maintenance > Switch contact replacement Fig. 65: Loosen set screws Fig. 66: Remove switch contact from guide rails Using a flat-bladed screwdriver, (Fig. 65/1) loosen the set screws Slide the switch contact in the of the switch contact until it direction of the arrow from the moves freely guide rails(Fig.
  • Page 155 Maintenance Maintenance > Switch contact replacement Slowly slide the switch contact in the direction of flow until the contact opens. This switch point should be set as accurately as possible because it affects the accuracy of the switchpoint adjustment scale values (If nec- essary, repeat steps 9 and 10) Tighten the set screws (Fig.

  • Page 156: Measures To Be Taken After Maintenance Work

    Maintenance Measures to be taken after maintenance work 8.6 Measures to be taken after mainte- nance work Take the following steps after comple- tion of maintenance work and before switching on the device: Check all previously loosened/ released screw connections for tightness.

  • Page 157: Dissambly And Disposal

    Dissambly and disposal Disassembly Dissambly and disposal 9.2 Disassembly After its period of useful life, the device must be disassembled and disposed of in an environmentally safe manner. Before starting disassembly: 9.1 Safety Remove operating materials and packaging and dispose of properly WARNING! Risk of injury if disassembled Personnel:...

  • Page 158: Return Materials

    Profimess will apply. Return shipments which do not comply with the returns – Have electrical scrap, elec- policy may be refused by Profimess at tronic components, lubricants the expense of the consignor. and other supplies disposed of by approved specialists 9.4 Disposal...

  • Page 159: Technical Data

    Technical data Switch contact data plate Technical data 10.1 Device data plate The data plate is on the mechanical part of the flow monitor/flow meter and contains the following information: 1. Ordering number 2. Operating range 3. Process connection 4. Serial number 5.

  • Page 160: Dimension Sheet

    Technical data Dimension sheet 10.3 Dimension sheet Fig. 70: Type SW-06.X.X.1.08 23.02.2015...
  • Page 161 Technical data Dimension sheet Fig. 71: Type SW-06.X.X.1.10 23.02.2015...
  • Page 162 Technical data Dimension sheet Fig. 72: Type SW-06.X.X.1.13a und SW-06.X.X.1.14 23.02.2015...

  • Page 163: General Specifications

    Technical data General specifications 10.4 General specifications Type Overall dimensions (mm) SW-06 ½ SW-06 ½ SW-06 ½ SW-06 ½ SW-06 ½ SW-06 ½ SW-06 ½ SW-06 SW-06 23.02.2015...
  • Page 164 Technical data General specifications Type Overall dimensions (mm) SW-06 SW-06 1 1/4 SW-06 1 1/4 1 ½ SW-06 1 1/4 1 ½ Type Overall dimensions (mm) weight (g) ** SW-06 ½ SW-06 ½ SW-06 ½ SW-06 23.02.2015...
  • Page 165 Technical data General specifications Type Overall dimensions (mm) weight (g) ** ½ SW-06 ½ SW-06 ½ SW-06 ½ SW-06 1400 1100 SW-06 1400 1100 SW-06 1400 1100 SW-06 1 1/4 50 2750 SW-06 1 1/4 50 3000 1 ½ 3800...

  • Page 166: Electrical Specifications

    Technical data Electrical specifications 10.5 Electrical specifications Change-Over Contact (COC) Data Value Unit Voltage 250 V Current, maximum 1,5 A Power, maximum 50 VA Minimum load 3 VA Normally Open Contact (NOC) Data Value Unit Voltage 250 V Current, maximum Power, maximum 100 VA Change-Over Contact (COC) M12x1 (-20 °C–85 °C)

  • Page 167: Measuring Ranges

    60 VA 10.6 Measuring ranges 10.6.1 Standard measuring ranges Type Switch range for H O at 20 °C* l/min SW-06.X.X.1.01. 0,2 – 4 3,0 – 63,5 SW-06.X.X.1.03. 0,6 – 5 9,5 – 79,0 SW-06.X.X.1.04. 0,5 –8 8,0 – 127,0 SW-06.X.X.1.05.

  • Page 168: Operating Data

    Min. media temperature. °C It must be ensured that the media does not freeze. Operating data for devices employed in explosion hazard zones differs from the above and are specified in the Operating Instructions for "SW-06 Module ATEX", Chanter 4. 23.02.2015...

  • Page 169: Annex

    Annex Replacement parts list Annex 11.1 Tightening torque Component/ Designation Size Torque Number function Threaded ring Threaded ring G1" 40 Nm (inlet/outlet) Threaded ring Threaded ring G5/4" 10 Nm (inlet/outlet) Threaded ring Threaded ring G6/4" 10 Nm (inlet/outlet) Process con- Process con- G1"...
  • Page 170 Annex Replacement parts list The following replacement parts drawing provides an example of the construction of a SW-06 type flow monitor. The actual configuration may vary depending on the model. Fig. 73: Type SW-06.X.X.1.08 Item No. of Description pieces Process connection (inlet)
  • Page 171 Annex Replacement parts list Item No. of Description pieces Slot nozzle Spring Float Process connection (outlet) Guide rail Fixing screw, (guide rail) Switch contact with male connector Female socket and gasket Fixing screw (female socket) Washer Fixing screw (switch contact) Display, mechanical 23.02.2015...
  • Page 172 Annex Replacement parts list Fig. 74: Type SW-06.X.X.1.10 Item No. of Description pieces Process connection (inlet) O-ring (seal) Centering disc Device body Pin (outlet) slot nozzle Slot nozzle 23.02.2015...
  • Page 173 Annex Replacement parts list Item No. of Description pieces Spring Float Process connection (outlet) Guide rail Fixing screw, (guide rail) Switch contact with male connector Female socket and gasket Fixing screw (female socket) Washer Fixing screw (switch contact) Display, mechanical 23.02.2015...
  • Page 174 Annex Replacement parts list Fig. 75: Type SW-06.X.X.1.13a und SW-06.X.X.1.14 Item No. of Description pieces Threaded ring (inlet) Device body Pin (outlet) slot nozzle Slot nozzle Spring 23.02.2015...

  • Page 175: Tools

    Annex Sealant Item No. of Description pieces Float Threaded ring (outlet) Guide rail Fixing screw, (guide rail) Switch contact with male connector Female socket and gasket Fixing screw (female socket) Washer Fixing screw (switch contact) Display, mechanical 11.3 Tools 11.4 Sealant The following tools are required: Tools...

  • Page 176: Lubricants

    Annex Lubricants 11.5 Lubricants Before using a lubricant, always make sure that it is compatible with the oper- ating medium. For the proper mounting of O-rings, an O-ring installation tool may be purchased from the manufacturer. The following lubricants are suitable to facilitate installing the O-rings: Lubricant O-ring material EPDM...

Table of Contents
