Summary of Contents for Weller WHA900N
- Page 1 WHA900 Operating Instructions...
-
Page 2: Table Of Contents
Table of Contents Page WHA900 Detail View Technical Data 1. Cautions! / Warnings! 2. Description 3. Placing Into Operation 4. Operating Guidelines 5. Accessories 6. Packing List 7. Nozzles 4,5,6... -
Page 3: Wha900 Detail View
WHA900 Detailed View 1. LED Heater Control 2. VariableTemperature Control; Range 100°F and 1000°F 3. Air Flow Control; Range 5 to 50 l/minute 4. Power Switch 5. Start / Stop Push Button 6. Hot Air Pencil and Hose Assembly 7. Fuse T 10 Amp 8. -
Page 4: Cautions! / Warnings
English Thank you for placing your trust in our company The WHA900 is grounded through the 120 VAC by purchasing the Weller WHA900 Hot Air Station. three wire power cord. This product meets or exceeds the requirements established by Weller for superior performance, Standby mode: versatility and quality. -
Page 5: Operating Guidelines
English Warning: Do not direct the hot air pencil at The Airflow and Temperature are activated after people or inflammable objects. depressing the Start/Stop Push Button. Heat-up time of the nozzle depends primarily on the size of the nozzle and the air flow. Temperature Offset 1. - Page 6 Hot Air Nozzles Ø 1,7 x 45° mm Ø .067 x 45° in 0058736882 Ø 2.5 mm Ø .098 in 0058736881 Ø 4 mm Ø .157 in 0058736867 Ø 7 mm Ø .280 in 0058736870 Ø 2,5 x 9,5 mm Ø...
-
Page 7: Nozzles
Hot Air Nozzles 14,8 x 14,8 mm .583 x .583 in 0058736818 11 x 11 mm .433 x .433 in 0058736839 21,5 x 14.8 mm .846 x .583 in 0058736840 19 x 12 mm .748 x .472 in 0058736841 14 x 10 mm .551 x .394 in 0058736842 10 x 8 mm... - Page 8 Hot Air Nozzles 31.3 x 31.3 mm 1.23 x 1.23 in 0058736833 26 x 26 mm 1.024 x 1.024 in 0058736804 20.5 x 20.5 mm .807 x .807 in 0058736807 17.5 x 23.5 mm .689 x .925 in 0058750721 18 x 18 mm .709 x .709 in 0058736814 15.5 x 13 mm...
- Page 9 Hot Air Nozzles Made To Order Nozzles ( Contact for Quote ) 24 x 12 mm .945 x .472 in 0058736880 43 x 43 mm 1.693 x 1.693 in 0058736890 36 x 36 mm 1.417 x 1.417 in 0058736891 27 x 14 mm 1.063 x .551 in 0058736892 29 x 17 mm...
- Page 10 Hot Air Nozzles Made To Order Nozzles ( Contact for Quote ) 12 x 27 mm .472 x 1.063 in 0058736880 38 x 38 mm 1.496 x 1.496 in 0058736890 40 x 40 mm 1.575 x 1.575 in 0058736891...
- Page 11 C C o o o o p p e e r r T T o o o o l l s s 164 Innisfil Street Barrie, Ontario Canada L4N 3B7 Attn: Repairs Fax: 1-800-403-TOOL (8665) Phone: 705-728-5564 Ext. 2026 Weller is a registered Trademark and registered Design of Cooper Industries, Inc.
