Summary of Contents for Dual LU43PB
- Page 1 LU43PB/W - LU53PB/W INSTALLATION/OWNER’S MANUAL Indoor/Outdoor 3-Way Dynamic Loudspeakers ®...
- Page 2 ® LU43P-LU53P INTRODUCTION Introduction The DUAL outdoor speaker series is designed as a multi- Introduction purpose speaker and will deliver accurate high fidelity sound in exterior or interior environments. Weather-resistant design and construction provide optimum durability for permanent or temporary outdoor use. Both models are available in black or white.
- Page 3 - in your computer room to enhance the multimedia experience - or as remote speakers. For wall and ceiling applications, DUAL mounting brackets Wall and Ceiling are included. In addition, the LU43 has a rear inset keyhole...
- Page 4 Both the LU43 and LU53 speakers have a DUAL logo that can be rotated. The logo is located on the face of the grille in the event a vertical installation is needed.
- Page 5 Speaker Wire -Typical speaker wire has a pair of separate Your Speakers speaker wires with insulating jackets that are molded together. Dual recommends the use of two conductor 18- gauge speaker wire to connect your speakers to your receiver. Measure enough wire to reach from your receiver to each speaker plus additional length to allow moving the speakers or receiver without having to disconnect the wires.
- Page 6 ® LU43P-LU53P CONNECTION & TROUBLESHOOTING Connecting Speakers Binding Post Type: LU53P STEP 1 Unscrew the caps covering each binding post until you expose the small hole through their centers. These caps are typically colored red and black, and represent positive and negative terminals, respectively. STEP 2 Twist the bare speaker wire to create a single strand.
- Page 7 ® LU43P-LU53P SPECIFICATIONS Specifications Specifications Model LU43P 100 Hz-20kHz Frequency Response 4" (100mm) Polyelite PVA Surround Woofer Midrange 40mm polypropylene 20mm Piezo Dome Tweeter 85.5 dB (2.83v @ 1 meter) Sensitivity Nominal Impedance 4-6 ohms Power Handling* 50 watts RMS - 100 watts (IPP) 8.25 x 5.25 x 5.25 Dimensions (Inches H x W x D) Weight...
- Page 8 A slight adjustment of any custom controls or connections discussed in your Dual Electronics Corp. warrants this product to the original purchaser to be free from defects in instruction booklet may save you a service material and workmanship for a period of one call.
