Heckler Design WindFall H604 Assembly & Installation

Side mount, room scheduling enclosure for ipad 10.2-inch 7th generation
Hide thumbs

Advertisement

Quick Links

Download this manual
WindFall
SIDE MOUNT
Room Scheduling Enclosure for iPad 10.2-inch 7th Generation
Assembly & Installation
Compatible with:
iPad 10.2-inch 7th Generation
®
Limited Warranty
Heckler Design warrants your product to be free from defect in material and
workmanship for a period of two years from the original date of purchase.
Electronic components are warranted to be free from defect for a period of one
year from the original date of purchase. If you discover a defect, please contact
service@hecklerdesign.com. Heckler Design will repair, at our discretion, using
new or refurbished components. If repair is not possible, Heckler Design will
replace the item.
H604

Advertisement

loading
Need help?

Need help?

Do you have a question about the WindFall H604 and is the answer not in the manual?

Questions and answers

Related Manuals for Heckler Design WindFall H604

Summary of Contents for Heckler Design WindFall H604

  • Page 1 Limited Warranty iPad 10.2-inch 7th Generation Heckler Design warrants your product to be free from defect in material and workmanship for a period of two years from the original date of purchase. Electronic components are warranted to be free from defect for a period of one year from the original date of purchase.
  • Page 2 M3 Hex Key Thread-Forming Mounting Screw F529 F486 Keep your assembly tool in a safe place. To purchase a replacement, please contact service@hecklerdesign.com. Phillips Head Drill Marker Screwdriver...
  • Page 3 WindFall Side Mount for iPad Installation Instructions and Template BEFORE AFTER Important Note: INSTALLATION INSTALLATION Mullion Door Frame Glass Mullion Door Frame Glass A minimum 1.5 inch (38mm) set back from mullion face to the glass is required for an optimal installation in which the front face of the enclosure is flush with the front face of the mullion.
  • Page 4 Disassemble Side Mount Remove Mounting Bracket From Front Bezel...

  • Page 5: Drill Mounting Holes

    Mark Hole Positions Please select the mounting positions that work best for your mullion. Drill Mounting Holes You may use any screw you see fit for mounting the product to the mullion. If you choose to use the self-tapping mounting screws provided, we recommend drilling a pilot hole with a #17 drill bit or a 5/32-inch drill bit.
  • Page 6 Form Mounting Hole Threads F486 The mounting screws provided are thread-forming screws. Ethernet Cable Hole If your Ethernet cable has an RJ45 connector installed, drill a 5/8 inch hole in the position shown. If you will install an RJ45 connector after the Ethernet cable is drawn through the mullion, a smaller hole can be created.

  • Page 7: Remove Mounting Screws

    Remove Mounting Screws Fasten Mounting Bracket to mullion F486...

  • Page 8: Charging Options

    Charging Options PoE Splitter (Power Only) PoE Splitter (With wired data connection) 1. Apple Lighting to USB 3 Camera Adapter 2. Apple USB Ethernet Adapter Battery Bank...
  • Page 9 Install Tablet Install Front Bezel...
  • Page 10 Slide Front Bezel Onto Mounting Bracket Tighten Assembly Screws F529...
