WindFall
FRONT MOUNT
Secure Enclosure for iPad mini for Room Scheduling
Assembly & Installation
Compatible with:
iPad mini 1
iPad mini 2
iPad mini 3
iPad mini 4
®
Limited Warranty
Heckler Design warrants your product to be free from defect in material and
workmanship for a period of two years from the original date of purchase.
Electronic components are warranted to be free from defect for a period of one
year from the original date of purchase. If you discover a defect, please contact
service@hecklerdesign.com. Heckler Design will repair, at our discretion, using
new or refurbished components. If repair is not possible, Heckler Design will
replace the item.
H517
Advertisement
Related Manuals for Heckler Design WindFall FRONT MOUNT
Summary of Contents for Heckler Design WindFall FRONT MOUNT
- Page 1 Compatible with: Limited Warranty iPad mini 1 Heckler Design warrants your product to be free from defect in material and workmanship for a period of two years from the original date of purchase. iPad mini 2 Electronic components are warranted to be free from defect for a period of one iPad mini 3 year from the original date of purchase.
- Page 2 M3 Hex Key Thread-Forming Foam for iPad Fit Mounting Screw Adapter Clip F529 F486 E250 Keep your special assembly tool in a safe place. To purchase a replacement, please contact service@hecklerdesign.com. Phillips Head Drill Marker Screwdriver (#17 drill bit or 5/32-inch drill bit)
- Page 3 Disassemble Front Mount Remove Mounting Bracket From Front Bezel...
-
Page 4: Drill Mounting Holes
Mark Hole Positions Please select the mounting positions that work best for your mullion. Drill Mounting Holes You may use any screw you see fit for mounting the product to the mullion. If you choose to use the self-tapping mounting screws provided, we recommend drilling a pilot hole with a #17 drill bit or a 5/32-inch drill bit. - Page 5 Form Mounting Hole Threads F486 The mounting screws provided are thread-forming screws. Ethernet Cable Hole If your Ethernet cable has an RJ45 connec- tor installed, drill a 5/8 inch hole in the position shown. If you will install an RJ45 connector after the Ethernet cable is drawn through the mullion, a smaller hole can be created.
-
Page 6: Remove Mounting Screws
Remove Mounting Screws Faster Mounting Bracket to mullion F486... - Page 7 Adapter Clips For iPad Mini 4 E250 iPad mini 4...
-
Page 8: Charging Options
Charging Options PoE Splitter (Power Only) PoE Splitter (With wired data connection) 1. Apple Lighting to USB 3 Camera Adapter 2. Apple USB Ethernet Adapter Gigabit + PoE Adapter Battery Bank... - Page 9 Install Tablet Install Front Bezel...
- Page 10 Slide Front Bezel Onto Mounting Bracket Tighten Assembly Screws F529...
