We appreciate the trust and confidence you have placed in StyleWell through the purchase of this kitchen cart. We strive to continually create quality
products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for
USE AND CARE GUIDE
KITCHEN CART
Questions, problems, missing parts?
Before returning to the store, call Customer Service.
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
HOMEDEPOT.COM
1-877-527-0313
THANK YOU
choosing StyleWell!
Item # 1004237663
Model # SK19238E2r1-V
Item # 1004237664
Model # SK19238E2r1-B
Item # 1004237665
Model # SK19238E2r1-C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Stylewell SK19238E2r1-V and is the answer not in the manual?

Questions and answers

Related Manuals for HOMEDEPOT Stylewell SK19238E2r1-V

Summary of Contents for HOMEDEPOT Stylewell SK19238E2r1-V

  • Page 1 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-877-527-0313 HOMEDEPOT.COM THANK YOU We appreciate the trust and confidence you have placed in StyleWell through the purchase of this kitchen cart. We strive to continually create quality products designed to enhance your home.

  • Page 2: Table Of Contents

    Table of Contents     Tools Required .................4 Table of Contents ............2   Safety Information ............2   Hardware Included ..............4   Warranty ................. 3   Pre-assembly (continued) ..........5   1 Year Warranty ...............3   Package Contents ..............5  ...

  • Page 3: Warranty

    We guarantee this product to be free of manufacturing defects to the original purchaser for one year. WHAT IS NOT COVERED This warranty does not cover commercial use, acts of nature, and abusive use. HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.

  • Page 4: Pre-Assembly

    Pre-assembly PLANNING ASSEMBLY Keep children and pets away from build area. Make sure your area is large enough to unpack, sort and assemble the unit. TOOLS REQUIRED Large head Small head Phillips Phillips screwdriver screwdriver HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity...

  • Page 5: Pre-Assembly (Continued)

    Right side towel rack Right crossbar Towel rack bar Adjustable shelf Drawer front panel Bottom panel Drawer left side panel Left door Drawer right side panel Right door Drawer back panel Drawer bottom panel HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.

  • Page 6: Assembly

    Assembly Attaching the magnet □ Attach magnet (GG) to bars (E) and (F) with screw (FF) as shown.
  • Page 7 Install dowel (AA) and bolt (BB) into partition (D). □ c) Join bar (F) to the partition (D). □ □ b) Insert lock (CC) into bar (F). d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes. HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
  • Page 8 Assembly (continued) Attaching the left bar to partition □ □ a) Install dowel (AA) and bolt (BB) into partition (D). c) Join bar (F) to the partition (D). □ □ b) Insert lock (CC) into bar (E). d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes.
  • Page 9 Join partition (D) to the panel (H) with dowel (AA). □ □ b) Insert lock (CC) into partition (D). d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes. □ e) Cover the cam holes with the cover (DD). HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
  • Page 10 Assembly (continued) Attaching the back panel □ □ a) Install dowel (AA) and bolt (BB) into partition (D). c) Join panel (K) to the assembled body with dowel (AA). □ □ b) Insert lock (CC) into panel (K). d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes. □...
  • Page 11 Join panel (K) to the assembled body with dowel (AA). □ d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes. □ b) Insert lock (CC) into panel (K). □ e) Cover the cam holes with the cover (DD). HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
  • Page 12 Assembly (continued) Attaching the left side panel □ □ a) Install dowel (AA) and bolt (BB) into panel (B). c) Join panel (B) to the assembled body with dowel (AA). □ d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes. □...
  • Page 13 Join towel rack side panels (O) and (N) to the towel bar (P) with knob (MM). □ b) Attach towel rack side panels (O) and (N) to the panel (C) with bolt (NN). Turn and tighten bolt (NN) with wrench (OO). HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
  • Page 14 Assembly (continued) Attaching the right side panel □ □ a) Install dowel (AA) and bolt (BB) into panel (C). c) Join panel (C) to the assembled body with dowel (AA). □ d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes. □...
  • Page 15 Assembly (continued) Assembling the universal wheel □ Insert wheels (U) and (V) into panels (B) and (C) as shown. HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
  • Page 16 Assembly (continued) Attaching the top panel □ □ a) Install bolt (BB) into panel (A). c) Join panel (A) to the assembled body with dowel (AA). □ b) Insert lock (CC) and dowel (AA) into panels (B) and (C), and partition (D). □...
  • Page 17 Assembly (continued) Assembling the adjustable shelf □ Insert shelf supports (HH) in desired positions and place shelf (G) on the supports. HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
  • Page 18 Assembly (continued) Attaching the door □ a) Attach left door (I) and right door (J) to the assembled body with screw (II) as shown. □ b) Attach handle (JJ) to door (I) and door (J) with the bolt (KK). NOTE: A helper who can hold the door in position makes the door installation easier.
  • Page 19 Tighten panels (R) and (S) to the panel (Q) with screw (EE). with screw (EE). □ b) Slide panel (U) into the grooves on □ d) Tighten knob (LL) to panel (Q) with bolt (KK). panels (R) and (S). HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
  • Page 20 Assembly (continued) Finalizing the assembly □ Insert the six drawers into the assembled body as shown. NOTE: Make sure the slide piece is at the front end of the glide when installing the drawer into the body. SAFETY RELEASE TAB NOTE: When removing the drawer, tip-up the safety release tab to remove the drawer from the body.
  • Page 21 Questions, problems, missing parts? Before returning to the store, call Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-877-527-0313 HOMEDEPOT.COM Retain this manual for future use.
