DEWE2-M7s
TECHNICAL REFERENCE MANUAL
WELCOME TO
THE WORLD OF
DEWETRON!
Congratulations on your new device! It will
supply you with accurate, complete and
reproducible measurement results for your
decision making.
ISO9001
Look forward to the easy handling and the
flexible and modular use of your
DEWETRON product and draw upon more
than 30 years of DEWETRON expertise in
EN ISO 14001
measurement engineering.
THE MEASURABLE DIFFERENCE.
Advertisement
Table of Contents
Related Manuals for Dewetron DEWE2-M7s
Summary of Contents for Dewetron DEWE2-M7s
- Page 1 ISO9001 Look forward to the easy handling and the flexible and modular use of your DEWETRON product and draw upon more than 30 years of DEWETRON expertise in EN ISO 14001 measurement engineering. THE MEASURABLE DIFFERENCE.
- Page 2 Copyright © DEWETRON GmbH This document contains information which is protected by copyright. All rights are reserved. Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. All trademarks and registered trademarks are acknowledged to be the property of their owners.
-
Page 3: Preface
This guide includes important startup notes, as well as safety notes and information about keeping your DEWETRON system in good working condition over time. However, this manual cannot and is not intended to replace adequate training. - Page 4 Preface Power supply output for accessories (12 VDC) Ethernet LAN connector LEMO EGG.1B.302 WLAN antenna Power supply input HDMI conenctor EGJ.2B.302 RS-232 interface connector (COM 1) Status indicator 10. Chassis terminal USB interface connectors 11. EPAD interface connector Power-on/off switch 12.
-
Page 5: Table Of Contents
Analog modules ..........16 Digital modules ..........17 Power modules ..........18 Installing a TRION module ........19 Power supply ............20 Internal 170 W DC power supply ..... 20 DEWE2-M7s • Technical reference • Printing version 1.0.1 • April 8, 2021... - Page 6 TABLE OF CONTENTS Notes...
-
Page 7: Safety
Handle the product with care. Shocks, hits and dropping it even from an already lower level may damage your system. For exact values refer to the enclosed specifications. DEWE2-M7s • Technical reference • Printing version 1.0.1 • April 8, 2021... -
Page 8: Electrical Safety Instructions
– Electrostatic fields etc. DO NOT use the system in rooms with flammable gases, fumes or dust or in adverse environmental conditions. Direct exposure of any DEWETRON product to strong sunlight or other heat radiation shall be prevented, as this... -
Page 9: Safety Notices During Operation
Indicates a hazardous situation that, if not avoided, could result in death or serious injury. CAUTION Indicates a hazardous situation that, if not avoided, could result in minor or moderate injury. DEWE2-M7s • Technical reference • Printing version 1.0.1 • April 8, 2021... -
Page 10: Notices
Safety Notices NOTICE This text indicates situations or operation errors which could result in property damage or data loss. INFORMATION This text indicates important information or operating instructions. Not observing these instructions could inhibit or impede you from successfully completing the tasks described in this documentation. Symbols Denotes a warning that alerts you to take precautions to avoid injury. -
Page 11: General Information
This symbol indicates that this system complies with the European Union’s requirements according to Directive 2002/96/EC on Waste of Electrical and Electronic Equipment (WEEE). Further informa- tion about recycling can be found on the DEWETRON website (www.dewetron.com). DEWE2-M7s • Technical reference • Printing version 1.0.1 • April 8, 2021... -
Page 12: Problematic Network Stacks
Often intrusive IT software or network processes can interfere with the primary function of the DEWETRON system: to record data. Therefore we recommend strongly against the installation of IT/MIS software and running their process- es on any DEWETRON data acquisition system, and cannot guarantee the performance of our systems if they are so configured. -
Page 13: System Setup
258 x 230 x 177 mm (4U) (10.2 x 9.1 x 7 in.) Weight w/o TRION™ modules Typ. 4.9 kg (10.8 lb.) *) Tested with SSD Tab. 1: System specifications DEWE2-M7s DEWE2-M7s • Technical reference • Printing version 1.0.1 • April 8, 2021... -
Page 14: Dimensions
SyStem SetuP Dimensions* *) Dimensions in mm (1 inch = 25.4 mm) Fig. 3: Dimensions DEWE2-M7s... -
Page 15: Connections And Ports
The DEWE2-M7s supports 802.11 b/g/n WLAN standards. HDMI connector The HDMI connector offers the possibility to connect a CRT or other standard HDMI displays to the system. Tab. 2: Connections and ports DEWE2-M7s DEWE2-M7s • Technical reference • Printing version 1.0.1 • April 8, 2021... -
Page 16: Trion Series Modules Overview
5. GND (Ground) Chassis terminal For some kind of measurements, it is necessary to provide the system with an additional ground connection. EPAD connector To connect DEWETRON EPAD modules to the system. Shield is connected (LEMO) on housing. Lemo EGG.1B.304 Pin assignment: 1. -
Page 17: Digital Modules
10 Hz IRIG measured data TRION-CAN 1 MBit D-SUB Decoding of ARINC 429 TRION-ARINC 4 or 16 signals, export of decoded signals Tab. 4: TRION digital modules DEWE2-M7s • Technical reference • Printing version 1.0.1 • April 8, 2021... -
Page 18: Power Modules
SyStem SetuP Sample rate Channels Resolution Isolation Features DIGITAL modules per channel Decoding of MIL-STD 1553 TRION-MIL1533 1 or 4 signals, export of decoded signals TRIION-EtherCAT- Measurement 500 S/s 1-SLAVE data output Tab. 4: TRION digital modules Power modules Sample rate Resolu- POWER modules Channels Isolation Connector type... -
Page 19: Installing A Trion Module
Unused TRION slots must always be covered. Make sure to reinstall the filler panels to unused TRION slots to guarantee proper cooling of the installed modules. The warranty is void if the modules overheat due to missing filler panels. DEWE2-M7s • Technical reference • Printing version 1.0.1 • April 8, 2021... -
Page 20: Power Supply
SyStem SetuP Power supply The DEWE2-M7s is delivered with a standard external AC/DC power supply (100–240 VAC IN). 1. 11...32 VDC 2. GND Fig. 6: Power supply Internal DC power supply 200 W DC power supply Input – Rated input voltage 11...32 VDC (max. 10...36 VDC) –... -
Page 21: Dw2-Ps-Dc-Buffer (Option)
The green LED indicates that the acquisition is running. If the acquisition stops the LED will be off. LED indication SYNC OUT SYNC I/O RED (stable) Clock detected Clock detected / receiving clock Green (stable) Acquisition running Acquisition running Tab. 8: LED indication DEWE2-M7s • Technical reference • Printing version 1.0.1 • April 8, 2021... -
Page 22: Channel Expansion With Trionet
SyStem SetuP Channel expansion with TRIONet LAN (max 100 m)/USB (max. 1.8 m) for data transfer Fig. 7: Channel expansion with TRIONet Network with multiple systems SYNC (max. 100 m) LAN (max. 100 m) for data transfer Fig. 8: Network with multiple systems... -
Page 23: Absolute Time Synchronization
SyStem SetuP Absolute time synchronization With this option, the DEWE2-M7s can operate synchronized with other measurement devices with an absolute time reference. PTP sync / IRIG sync Synchronization via IRIG DEWE2-M7s with TRION- TIMING module IRIG Sync Generator 3rd party... - Page 24 SyStem SetuP Notes...
-
Page 25: Maintenance And Service
Updates Windows and antivirus/security software Before installing Windows software updates consult with DEWETRON for compatibility guidance. Also keep in mind that the use of any antivirus or other security software may slow down your system and may cause data loss. -
Page 26: Training
Service and repairs Only the team of DEWETRON is allowed to perform any kinds of repairs to your system to assure a safe and proper op- eration in future. For information regarding service and repairs please contact your local distributor first or DEWETRON directly. -
Page 27: Ce Certificate Of Conformity
EN 61000-6-4 EN 55011 Class B Immunity EN 61000-6-2 Group standard Graz, August 07, 2014 Place / Date of the CE-marking Ing. Thomas Propst / Manager Total Quality DEWE2-M7s • Technical reference • Printing version 1.0.1 • April 8, 2021... - Page 28 ce certificate of conformity Notes...
