- Page 1 VALI Instruction Replacement of Vali fluid pipe...
- Page 2 Instruction – Replacement of Vali Fluid Pipe Remove the l/H side cover by removing the Hole plugs and loosening the four screws. Slide the l/H side cover away from the main body ensuring that the earth lead is disconnected. Repeat the above steps and remove the R/H side cover.
- Page 3 Remove the 4 x m4x10 Black taptite Screws from the trim plate in front of the nozzle. drill out the 2 x Silver Rivets on the upper part of the vertical strap as shown, using a 3.5mm drill bit. Vali Reperation...
- Page 4 Instruction – Replacement of Vali Fluid Pipe now remove the 2 x m4x10 Black taptite Screws holding the Vertical Strap in place at the top. Gently manoeuver the Vertical Strap away from the left-hand side of the machine, using a small screwdriver to hold the strap in position.
- Page 5 Brass nut connecting the non-Return Valve to the steel fluid pipe as shown. locate the brass nut connecting the fluid pipe to the heat exchanger. then loosen with a spanner so that the pipe can be removed as shown. Vali Reperation...
- Page 6 Instruction – Replacement of Vali Fluid Pipe take your replacement pipe and brass fitting. Bend the pipe as shown and slide the ‘olive’ and ‘nut’ of the brass fitting onto the pipe. insert the bent end of the pipe into the brass fitting on the Heat exchanger and secure with the ‘olive’...
- Page 7 ‘nut’, re-connect the fluid pipe to the one-way valve using a size 10 & 12 spanner to tighten. now gently place the one- way valve assembly back behind the metal tabs of the chassis & underneath the Heat exchanger Vali Reperation...
- Page 8 Instruction – Replacement of Vali Fluid Pipe now re-attach the top edge of the Vertical Strap using the 2 x Silver counter-sunk Rivets (Supplied) and the 2 x m4x10 Black taptite Screws as shown. Re-attach the trim plate using the 4 x m4x10 Black taptite Screws removed earlier.
- Page 9 4 x screws and replace the 4 x white hole plugs (l/H) and repeat for the 2 x screws/ hole plugs on the R/H. Vali Reperation...
- Page 10 Rectory court High Street Kislingbury uK - northants, nn7 4aG phone +44 (o) 1604 839 000 +44(0) 1604 832 666 www.smokecloak.com contact: mSS professional a/S agerhatten 25 dK - 5220 odense SØ phone +45 7217 0011 +45 8617 0055...
