PRODUCT NO.
BASE MODEL NO.
FRT18H7CW0
FRT18H7C
MARKET
North America
ENERGY GUIDE LABEL - 240592240
OWNER'S GUIDE - 240400109
SERVICE DATA SHEET - 240379010
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
white
Publication No.
5995390027
030505
-EN/SERVICE /DCS
390
FACTORY
PARTS CATALO
VOLTS
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18H7C
©2003 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT18H7C
Summary of Contents for Frigidaire FRT18H7C
- Page 1 PRODUCT NO. BASE MODEL NO. FRT18H7CW0 FRT18H7C MARKET North America ENERGY GUIDE LABEL - 240592240 OWNER’S GUIDE - 240400109 SERVICE DATA SHEET - 240379010 ELECTROLUX HOME PRODUCTS, INC P.O. Box 212378, Augusta, GA 30917 SERIES COLOR R134a white REFRIGERATOR Publication No.
- Page 2 Publication No. FRT18H7CW0 5995390027 DOOR 05/03...
- Page 3 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRT18H7CW0 DOOR PART NO DESCRIPTION 240542103 Gasket-frzr door,white ,magnetic 240542106 Gasket-refr door,white ,magnetic 240338303 Door,dairy ,clear 240381301 Plug-button,white ,hinge brg hole ,(2) 240409903 Panel-frzr door,white ,complete assy 240572601 Label-nameplate 240312403 Door Stop,white ,ref 240312404 Door Stop,white ,frzr...
- Page 4 Publication No. FRT18H7CW0 5995390027 CABINET 05/03...
- Page 5 POS. NO 10*# 114# # = Fast-moving Parts * = Non-Illustrated Parts FRT18H7CW0 CABINET PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240462009 Cover-evap coil 240568601 Seal-coil cover 240524801...
- Page 6 Publication No. FRT18H7CW0 5995390027 SHELVES 05/03...
- Page 7 POS. NO 14 # 17*# 21 # 23 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18H7CW0 SHELVES PART NO DESCRIPTION 215667501 Tray,ice cube ,plastic 240358002 Shelf-freezer,full width 240545001 Diffuser,air ,top 240362601 Diffuser,air ,bottom 240505801 Switch,light/lamp 240436702 Light Bulb/Lamp,A-15 ,clear ,40 W ,120 V,miniature 240364201 Socket-light/lamp,dual 240352701...
- Page 8 Publication No. FRT18H7CW0 5995390027 SYSTEM 05/03...
- Page 9 POS. NO 6* # 6* # 14 # 15 # 21 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18H7CW0 SYSTEM PART NO DESCRIPTION 240444401 Condenser,dynamic 218944001 Drier-filter,R134a System 240496101 Wiring Harness,machine compt ,w/electric cord 240388701 Wiring Harness,control box 240524801...
-
Page 10: Wiring Schematic
Publication No. FRT18H7CW0 5995390027 WIRING SCHEMATIC 05/03... -
Page 11: Wiring Diagram
FRT18H7CW0 Publication No. 5995390027 WIRING DIAGRAM # = Fast-moving Parts 05/03 * = Non-Illustrated Parts...
