- Page 1 Network Camera IPC-300 User Manual XRPLUS INCORPORATED WWW.XRPLUS.CO.KR sales@xrplus.co.kr...
- Page 2 IPC-300 User Manual Safety Precaution We appreciate your purchasing IPC series. Before installing the product, please read the following with care. Make sure to turn off the power before installing IPC. Do not install under the direct sunlight or in dusty areas.
-
Page 3: Table Of Contents
IPC-300 User Manual Table of Content Table of Content ....................2 1. Introduction .....................3 1. About User Manual ..................3 2. Feature.....................3 3. Product and Accessories .................4 4. Part Names and Functions ..............5 5. System Connections................6 2. Installation .......................9 1. Connecting Network(LAN) ...............9 2. -
Page 4: Introduction
IPC-300 User Manual 1. Introduction 1. About User Manual The User Manual is to provide information on operation of the high quality Network Camera, IPC. In this guide, information on installation, operation, configuration of IPC is written as well as how to trouble shoot in case problems arise. -
Page 5: Product And Accessories
IPC-300 User Manual Sensor and Alarm Connections to external sensor and alarm devices Event Alarm User Interface System status display utilizing OSD(On Screen Display) System configuration using Internet Explorer Reliability Reliable embedded system System recovery utilizing dual watch-dog functions 3. Product and Accessories... -
Page 6: Part Names And Functions
IPC-300 User Manual Power adaptor and cable CMS S/W CD <Picture 1> Product and Accessories 4. Part Names and Functions Assemble Reference Line Mount Bracket Mounting Hole Drop Prevention Spring Lockup Screw Main Body Dome Cover Main Unit / Surface Mount Bracket... -
Page 7: System Connections
IPC-300 User Manual Audio Connector Power LED Drop Prevention IP Reset Switch Spring Hook Cabling Ethernet Connector Terminal Block DIP Switch Back of Main Unit 5. System Connections IPC systems can be connected in either 1-to-1 fashion where one IPC is connected one PC client or decoder system or 1-to-many fashion where one IPC connected to many PC and decoder systems. - Page 8 IPC-300 User Manual Mostly used configuration is 1 to 1 connection. An IPC is installed at a site where video images can be transmitted and a PC or a decoder is installed at a center location to receive and view the video images on analog monitor. Audio and serial data are transferred in either direction.
- Page 9 IPC-300 User Manual In this arrangement, video and audio can be retransmitted from a center to another center. The arrangement is useful when the network bandwidth to the site is limited while there are more than one center wanting to monitor the site.
-
Page 10: Installation
IPC-300 User Manual 2. Installation 1. Connecting Network (LAN) Connect LAN and there is a Video output to check video quality. 2. Connecting Audio Audio is bi-directional in any configuration. If necessary, it can be configured to be in transmit-only, receive -only or bi-directional mode. -
Page 11: System Operation
IPC-300 User Manual 3. System Operation 1. Remote Video Monitoring There are two ways to view the video once connections are made between the site and center system. In order for a proper operation, an IP address must be set accordingly and please refer to True Manager in Chapter 4 or Remote Setting in Chapter 5 for a further details. -
Page 12: Initialization Of Ip Address
IPC-300 User Manual 2. Initialization of IP Address If a system IP address is lost, the system can be reset to a known IP address using the reset button in the back side of the system: While system is in operation, press the reset button more than 5 seconds. - Page 13 IPC-300 User Manual button located in the upper right area of the monitoring screen, then the se page for server setup will be displayed. Enter IP address Press Setup button The configurations are grouped into 8 categories: System, Video, Audio, Network, Serial, Event, Preset and User.
-
Page 14: Ipc Configuration
IPC-300 User Manual 2. IPC Configuration 2.1 System Configuration Video Standard Video signal type: Select NTSC or PAL -13-... - Page 15 IPC-300 User Manual System ID System ID: Alphanumeric System ID to be transferred to remote software Language Language to be used for web-based configuration (English, Japanese and Korean) Firmware version Current firmware version Start Time Latest system boot date and time Current Time Current date &...
-
Page 16: Video Configuration
IPC-300 User Manual 2.2 Video Configuration -15-... - Page 17 IPC-300 User Manual Preference Preference in video compression and transmission: With ‘Bitrate’ selected, the video compression will be effected by the ‘Bitrate’ value entered. With ‘Quality’ selected, the video compression will be effected by the quality of image selected. Therefore, ‘Bitrate’ and ‘Quality’ corresponds to CBR and VBR respectively.
- Page 18 IPC-300 User Manual I-Frame Interval I-frame interval: Possible values between 0 and 255. There will be no I- frames if 0 is selected. Motion Detection Area Editing Configure regions for motion detection. Regions of arbitrary shape can be configured by the following steps.
-
Page 19: Audio Configuration
IPC-300 User Manual Internet Explorer. Each item can be turn on or off separately, and position also can be configure. This information are displayed after the video is decompressed. Burn-in OSD Inserts system ID and date/time in the compressed video. Separately System ID and Time can be turned On or Off in the video. - Page 20 IPC-300 User Manual Mode Select audio operation mode. Mode Action No operation Tx-Only Transmit only Rx-Only Receive only Tx & Rx Transmit and Receive Input Gain Set audio input gain. -19-...
-
Page 21: Network Configuration
IPC-300 User Manual 2.4 Network Configuration IP Mode Three IP modes are supported. Depending on the selected mode, further configuration items come as follows. IP Mode Selection Description Local IP Fixed IP address Fixed IP Local Gateway Gateway IP address... - Page 22 IPC-300 User Manual ☞ Please ask an IP address information from ISP provider or network manager. Set DNS server IP address. Base Port Network base port use for communication between systems. In order for the servers and remote systems to be connected together, the port number must be identically set.
-
Page 23: Serial Port Configuration
IPC-300 User Manual The bitrate automatically adjusted to a client with largest network bandwidth size. When set to this mode, a client with smaller bandwidth will not receive all frames of video. Adjust The bitrate is adjusted to most optimum rate by learning the network bandwidth. -
Page 24: Event Configuration
IPC-300 User Manual Not used The port is normally open and activated when NO (Normally Open) closed. The port is normally closed and activated when NC (Normally Closed) opened. The function of the sensor port is set based on the type of the sensor connected. - Page 25 IPC-300 User Manual The IPC series has one sensor port and alarm port. Actual numbers of sensor, alarm ports and beep may vary depending on models. When a decoder system instead of a PC client is connected to a IPC, one system becomes a Local system and the other a Remote system (Generally a system which is being used by the user is called as Local system).
-
Page 26: Preset Configuration
IPC-300 User Manual On Disconnect Configure the actions when the link (connection) with peer system is disconnected. Multiple actions can be set for a single event. Alarm activation duration Set the duration of alarm activation in case of an event. If it is set to continuous, it will be in active state until an operator reset it manually. - Page 27 Press Set Button Save This function is available for using IPC-300 in order to control PTZ effectively. Configure up to 15 preset positions. Preset function is not available on some PTZ receivers. Make sure to check if a PTZ receiver supports preset.
-
Page 28: User Configuration
IPC-300 User Manual move to the selected preset position. 2.8 User Configuration User can be registered and privilege level of a user can be specified. User configuration is allowed only to admin user. Max 16 users can be registered and each user can have one of four privileges. - Page 29 IPC-300 User Manual User ID and password need to be entered and privilege level need to be selected. User ID and password consist of alphanumeric string of max 15 characters. Delete User A user is deleted by pressing Delete button.
-
Page 30: Camera Configuration
IPC-300 User Manual 2.9 Camera Configuration Settings for analog part of the camera can be configured. Camera-specific menu is displayed using OSD on video display, and this menu can be operated with 5 buttons on the page. -29-...
