Code 3 CW3000 Series Installation Instructions

Code 3's CW3000 Series Remote Spotlights are multi-
functional, motorized searchlights featuring a 12-24 VDC
operation. Both spotlights can be installed wirelessly and
are protected by a polycarbonate lens and the housings are
available in black or white.
The CW3000/3001 offers 360-degree rotation and a 90
degree tilt range, while the CW3010/3011 offers full,
continuous rotation, a 135-degree tilt range and features
an optional hardwired in-dash joystick controller. The
CW3010/3011 spotlight also has a home setting that
automatically returns the light to its original position upon
powering off the device.
IMPORTANT!
Read all instructions before installing and using. Installer: This manual must be
delivered to the end user.
!
WARNING!
Failure to install or use this product according to manufacturer's recommendations may result in property
damage, serious bodily/personal injury, and/or death to you and those you are seeking to protect! Check wattage
before installing light to avoid possible equipment damage.
Do not install and/or operate this safety product unless you have read and understand the safety
information contained in this manual.
1. Proper installation combined with operator training in the installation, use, care and maintenance of vehicle equipment accessories is
essential to ensure the safety of you and those you are trying to protect.
2. Exercise caution when working with live electrical connections.
3. This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high
current arcing, which can cause personal injury and/or severe vehicle damage, including fire.
4. Proper placement and installation are vital to the performance of this worklamp. Install this product so that output
performance of the system is maximized and the controls are placed within convenient reach of the operator so that s/he can
operate the system without losing eye contact with the work area.
5. It is the responsibility of the vehicle operator to ensure during use that all features of this product work correctly. In use, the
vehicle operator should ensure the projection of the beam is not blocked by vehicle components (i.e., open trunks
or compartment doors), people, vehicles, or other obstructions.
6. The manufacturer assumes no liability for any loss resulting from the use of this device.
Specifications:
Input Voltage: 12-24V
Current Draw: 1.7 Amps (peak)
Power: 23.2 Watts (max)
Installation and Operation Instructions
REMOTE SPOTLIGHT
Page 1 of 5
