INSTRUCTION MANUAL
MDDA-860
Micro Digital Demod to ASI
Model
MDDA-860
Status
Active
©2010 Blonder Tongue Laboratories, Inc. All rights reserved. Specifications are subject to change without notice. Trademarks are the property of their respective owner.
Stock No.
6277
Date
July 19, 2010
(800) 523-6049 • (732) 679-4000 • FAX: (732) 679-4353
Description
Micro Digital Demod ASI
Document No.
651224800A
One Jake Brown Road
Old Bridge, NJ 08857-1000 USA
www.blondertongue.com
Issue No.
Author
1
KK
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Blonder tongue MDDA-860
Summary of Contents for Blonder tongue MDDA-860
- Page 1 Micro Digital Demod ASI Status Date Document No. Issue No. Author Active July 19, 2010 651224800A ©2010 Blonder Tongue Laboratories, Inc. All rights reserved. Specifications are subject to change without notice. Trademarks are the property of their respective owner.
- Page 2 This Page is Intentionally Left Blank...
- Page 3 We recommend that you write the following information in the spaces provided below. Purchase Location Name: Purchase Location Telephone Number: MDDA-860 Serial Number: The information contained herein is subject to change without notice. Revisions may be issued to advise of such changes and/or additions.
-
Page 4: General & Safety Instructions
4 MDDA-860 Instruction Manual General & Safety Instructions The STOP sign symbol is intended to alert you to the presence of REQUIRED operating and maintenance (servicing) instructions that if not followed, may result in product failure or destruction. The YIELD sign symbol is intended to alert you to the presence of RECOMMENDED operating and maintenance (servicing) instructions. - Page 5 ➥ U nplug the unit from the AC power outlet before cleaning. Use only a damp cloth for cleaning the exterior of the unit. ➥ D o not use accessories or attachments not recommended by Blonder Tongue, as they may cause hazards, and will void the warranty.
-
Page 6: Product Specification
6 MDDA-860 Instruction Manual Product Specification Input Output Connector: “F” Female Connectors: ASI: 1 x F (equipped with F-to-BNC adapter) Standards 8VSB: ATSC Digital Television Standard A/53E QAM: ITU-T J.83 Standard: DVB-ASI; 50083-9 (64 and 256 QAM) Data Bit Rate: 270 Mbps 8VSB Mode... - Page 7 Information Protocol) feature. It may also be referred to as the “tune to” (NAB) or as a “virtual” channel. Digital TV’s along with digital demodulators such as Blonder Tongue’s MDDM-860 and AQD use the virtual channel number to tune to the particular program that in most cases is transmitted over a completely different channel number.
- Page 8 8 MDDA-860 Instruction Manual [8] RF Mode button: When the RF button is pushed, the module will switch from the sleep mode to the frequency plan editing mode. The LED display will indicate current Channel number and RF frequency plan. Pressing the RF button while in the frequency plan editing mode, will step through the RF frequency plans on the LED...
- Page 9 MDDA-860 Instruction Manual MDDA Operation: [1] Power-save mode: After approximately 3 minutes of no interaction, the unit will enter into its power-save mode by turning off all front-panel LEDs and displays. The dot of the 2-digit LED will remain lit to indicate unit is powered and operating normally.
- Page 10 10 MDDA-860 Instruction Manual Notes...
-
Page 11: Limited Warranty
BT may determine) any product manufactured by BT which proves to be defective in materials or workmanship or fails to Blonder Tongue Laboratories, Inc. (BT) will at its sole option, either repair or replace (with a new or factory reconditioned product, as BT may meet the specifications which are in effect on the date of shipment or such other specifications as may have been expressly... - Page 12 One Jake Brown Road Old Bridge, NJ 08857-1000 USA (800) 523-6049 • (732) 679-4000 • FAX: (732) 679-4353 www.blondertongue.com...
