- Page 1 IMEON 3.6 USER GUIDE...
- Page 2 USER GUIDE IMEON 3.6 Suivi Indice des modifications Modified Index Date Modification description Author pages 30/07/2015 Initial drafting F.M. IMEON – 3.6 Reference Index...
- Page 3 IMEON 3.6 IMEON 3.6 Smart management of all self-consumption solar installations IMEON is the result of high innovation and technology. The IMEON multi-sources phase coupling (Phase Coupling Energy, or PCE) is used to couple several energy sources (eg: PV / batteries / grid).
-
Page 4: Inverter Supervision
IMEON 3.6 1- Inverter supervision 1-1 LCD information Note : To light up the screen, you can press any button. Display screen : Indicators Units Indicates AC OUTPUT active power, apparent power, frequency and voltage. kW : Active power. kVA : Apparent power. - Page 5 IMEON 3.6 Indicate the PV. Indicates the grid. If the icon flashes, that means the grid is unavailable. Indicates the battery state of charge. Left icon : battery fully charged. Center icon : If the icon flashes, that means the batteries is unavailable.
- Page 6 IMEON 3.6 1-4 Query Menu Operation This display shows the current contents of your system. These values can be changed in the menu with the buttons. There are five indicators available. Choice of the indicator : Press the button once, the indicator is flashing, then press the button to select the required indicator.
- Page 7 IMEON 3.6 Choice of the indicator unit Press the button once, then press the button to visualize the value of the unit. Indicator AC OUTPUT : -Apparent power (kVA) -Active power (kW) -Voltage (V) -Frequency (Hz) Indicator BATTERY : -Charge percentage (%)
- Page 8 IMEON 3.6 Indicator RENEWABLE ENERGY : -Total production (kWh) -Daily production (kWh) Indicateur DC INPUT : -Power (kW) -Current (A) -Voltage (V) Enable and disable « AC OUTPUT » To enable the « AC OUTPUT » of the IMEON, hold pressed during 3 seconds the button and release until the sound signal is emitted.
-
Page 9: Affichage Suivant Le Mode De Fonctionnement
IMEON 3.6 2- Affichage suivant le mode de fonctionnement The photovoltaic production allows to supply the load, to charge the batteries and to feed-in the surplus of energy to the grid. The photovoltaic production allows to charge the batteries and to feed-in the surplus of energy to the grid. - Page 10 IMEON 3.6 The « BATTERY » icon is flashing, the batteries are disconnected from the IMEON. The photovoltaic production allows to supply the load and to feed-in the surplus of energy to the grid. The « BATTERY » icon is flashing, the batteries are disconnected from the IMEON.
- Page 11 IMEON 3.6 The « AC GRID » icon is flashing, the grid is disconnected from the IMEON. The photovoltaic production allows to supply the consumers. The batteries supply the additional needs for extra loads. The « AC GRID » icon is flashing, the grid is disconnected from the IMEON.
- Page 12 IMEON 3.6 3- Programme IMEON MANAGER The IMEON MANAGER is USB-based software that can be installed on a Windows PC, which allows easy and immediate settings of the IMEON functionalities. Connect the USB A /USB B cable between the PC and the...
- Page 13 IMEON 3.6 1- Download of the software IMEON Manager Download the software IMEON Manager from the IMEON ENERGY website at the following address: http://www.imeon-energy.com/ Save the software on a folder on your computer. Installation of the software IMEON Manager Run the software IMEON Manager.exe and select a folder to install by clicking on the « Browse »...
- Page 14 IMEON 3.6 There are four tabs available: « Home », « Flow Manager », « Battery Manager » and « Scan ». Index A...
- Page 15 IMEON 3.6 Index A...
- Page 16 IMEON 3.6 4.1 – Home The home page shows the information of the inverter and the general status operation. Usage of energy sources : Serial N° : Indicates the serial number of the inverter. IMEON T° : Indicates the internal temperature of the inverter.
- Page 17 IMEON 3.6 4.2 – Flow Manager : Function mode : - Smart-Grid Mode optimized for self-consumption and efficiency. - Off-Grid Mode optimized for electrification of isolated sites (without grid). - On-Grid Inject the totality of the solar production in the « GRID CONNECTION » connector.
- Page 18 IMEON 3.6 4.3 – Battery Manager : Technology : Allows choosing the technology of the battery connected to IMEON: Lead Acid (GEL, AGM, OPz) or Lithium. Discharge only at night : By choosing « Yes », the batteries will be discharged only when the solar installation is not producing energy.
- Page 19 IMEON 3.6 5- Buttons and messages of the software : Validates the IMEON settings modifications. Allow restoring the IMEON factory parameters. This button erases previously made settings. Allows to exit the software. Allows displaying the information about the parameter. Message showing that the modification of the parameter is not possible.
- Page 20 IMEON ENERGY / FRANCE Address : 300 rue Pierre Rivoalon 29200 BREST - FRANCE Tel : +(33) 1 84 17 51 15 After-Sales Service : Contact your local distributor www.imeon-energy.com...
