V333 CARE FREE DRONE
Specifications
CONTENTS OF THE BOX:
• 1 x Quadcopter drone
• 1 x 2.4GHz remote control with LCD display (6x AA batteries
not included)
• 1 x 7.4V 850mAh Li-po battery
• 1 x Charger
• 4 x Spare propellers
• 1 x User manual
Security precautions
• Read the manual carefully and completely
• This model is not suitable for children under 14 years and contains small parts
• Children should only use this model under the supervision of an adult
• Keep hands, face, hair and clothes away from blades.
• Stand out of reach of moving parts of the copter
• After using the copter ALWAYS disconnect the battery and remove it from the device
• The model and the transmitter must be switched off after use
• Always fly in an open and safe environment where you will not cause any danger to others
• For the remote control, we recommend AA batteries with a voltage of 1.5 to 1.2 volts
• For people without experience, we recommend that you learn to fly with an experienced user during your first flights
• Before each flight, test the distance limit of the transmitter
• Keep these instructions safe
• Always follow local laws and regulations! Contact your reseller when in doubt.
INSTRUCTION MANUAL
SPECIFICATIONS:
• 2.4GHz Assembled quadcopter drone Ready-to-fly
• 6-axis Gyroscope
• 4 main engines
• 1 Li-po Battery 7.4V 850mAh
• Height: 130 mm
• Length: 530 mm
• Width: 530 mm
• Weight: 225 grams without battery
• Battery weight: 46 grams
Advertisement
Table of Contents
Related Manuals for WLtoys V333
Summary of Contents for WLtoys V333
- Page 1 INSTRUCTION MANUAL V333 CARE FREE DRONE Specifications CONTENTS OF THE BOX: SPECIFICATIONS: • 1 x Quadcopter drone • 2.4GHz Assembled quadcopter drone Ready-to-fly • 1 x 2.4GHz remote control with LCD display (6x AA batteries • 6-axis Gyroscope • 4 main engines not included) •...
-
Page 2: Battery Charging
- This model is equipped with a rechargeable Li-po Battery. Li-po batteries require special attention, follow the manual - The batteries must be charged with the charger supplied by WLtoys - When charging the battery, always ensure that you do so on a non-combustible surface... -
Page 3: Remote Control Transmitter
Li-po Battery Plug the charger into a wall socket and connect the battery to the charger. This can only be done in one way: by firmly connecting the charging cable. If the green light is on, the battery is fully charged and can be disconnected. Then do not forget to unplug the charger from the wall socket. - Page 4 How to fly Flying is really simple, but you need a little practice at first. Connect to www.wltoys.eu to watch educational films. SIDEWARD The directional lever serves to move the drone to the left or the right.
-
Page 5: The First Flight
Never go full speed for the first 3 flights. After 3 flights, blow out engines with air when possible. Spare engines can be bought on www.wltoys.eu or with your reseller. The first flight 1. For your first flight make sure to be with a person experienced in flying copters. We advise you to make your first flights on a relatively soft surface to protect the copter. -
Page 6: Troubleshooting
Spare parts This product is not sensitive to crashes, but in case of extreme drops it is possible that some parts may break. All parts can be ordered and easily assembled. Please contact your dealer or visit www.wltoys.eu for more information. - Page 7 Copper bush for gear Li-po battery Motor Tail frame Additional modules (accessories) This model can be equipped with different modules. This is available from your retailer or on www.wltoys.eu. A module may be included in some models. Camera Bubble Fountain Bullet...
-
Page 8: Warranty
Wltoys Congratulations on your purchase of this product from wltoys.eu! Wltoys.eu offers its customers a high quality product. All our products are carefully tested before shipment. If unfortunately a problem persists, contact your dealer or visit www.wltoys.eu. Your dealer can also assist you in getting spare parts in case you need them. - Page 9 • Damage caused by the failure to comply with security measures or instructions • Extreme treatment which can not be contained in the usual standards • Overloading the vehicle or external influences • Homemade modifications on the product • The damage caused by the loss of control of the vehicle •...
