Panasonic TC-29P10N Service Manual

Hide thumbs

Table Of Contents

Quick Links

Download this manual

Specifications

Power Source:

Power Consumption:

TC-29P10N

134W

Stand-by condition 0.4W

Aerial Impedance:

Receiving system:

Tuning System:

Receiving Channels:

VHF Band

UHF Band

CATV

Intermediate Frequency:

Video

45.75 MHz

Sound

41.25 MHz

Color

42.17 MHz (NTSC)

High Voltage:

AC100 V, 60 Hz

TC-33P10N

144 W

Stand-by condition 0.4 W

75Ω unbalanced,

Coaxial type

NTSC M

Voltage Synthesizer

100 position (Auto Search)

2-13 (NTSC M U.S.A.)

14-69 (NTSC M U.S.A.)

1-125 (U.S.A. CATV)

31.0 (+0.7, -1.5)kV

at zero beam current

TC-29P10N

TC-33P10N

Video / Audio Terminals:

AV1,2,3

S-Video IN

Video IN

Audio IN

Monitor Out

Video Out

Audio Out

Picture Tube:

TC-29P10N

TC-33P10N

M68LQL185X

M79LQM185X

Type29 (73 cm)

Type 33 (85 cm)

104° deflection

Audio Output:

15W (5W+5W+5W)(10% THD)

Headphones:

3.5 mm Plug

Dimensions (W×D×H):

TC-29P10N

688 mm

TC-33P10N

790 mm

Mass:

TC-29P10N

48.0 kg (Net)

TC-33P10N

71.0 kg (Net)

Accessories Supplied:

Remote Controller

"R6" Battery

Specifications are subject to change without notice.

Mass and dimensions shown are approximate.

1999 Matsushita Electric Industrial Co.,Ltd.

distribution is a violation of law.

ORDER NO.ITD9907012C3

Colour Television

LX1 Chassis

Y:1.0 Vp-p 75 Ω

C:0.3 Vp-p 75 Ω

1 Vp-p 75 Ω

0.5 Vrms

1 Vp-p 75 Ω

0.5 Vrms

492 mm

570 mm

555 mm

653 mm

Table of Contents

Summary of Contents for Panasonic TC-29P10N

Page 1 ORDER NO.ITD9907012C3 Colour Television TC-29P10N TC-33P10N LX1 Chassis Specifications Video / Audio Terminals: Power Source: AC100 V, 60 Hz Y:1.0 Vp-p 75 Ω AV1,2,3 S-Video IN Power Consumption: C:0.3 Vp-p 75 Ω TC-29P10N TC-33P10N 1 Vp-p 75 Ω Video IN...
Page 2: Table Of Contents
Contents Specifications ..........Cover Safety Precautions .
Page 3: Safety Precautions
Safety Precautions Turn on the receiver’s power switch. General Guide Lines power-on It is advisable to insert an isolation transformer in the AC supply before servicing a hot chassis. Isolation Transformer Measure the resistance value, with an ohmmeter, between the jumpered AC plug and each exposed metallic cabinet part on the receiver, such as screw heads, aerials, connectors, control shafts, etc.
Page 4 X-Radiation Warning: The potential sources of X-Radiation in TV sets are the High Voltage section and the picture tube. When using a picture tube test jig for service, ensure 33.0kV that jig is capable of handling without causing X- Radiation. Note: It is important to use an accurate periodically cali- brated high voltage meter.
Page 5: In Regard To The Self-Check Function
In regard to the self-check function When phenomena like “the power fails from time to time” or “the video/audio fails from time to time” can not be confirmed at the time of servicing, the self-check function can be used to confirm the occurrence and to limit the scope for the defective circuits. Also, when “the power fails from time to time”, display of the color bar on the screen can be used confirm the occurrence and to limit the scope for the defective circuits.
Page 6: Servicing Method
Servicing method Application of silicone grease to the anode cap Anode part of the picture tube Anode cap Warning About About Please apply grease when the anode cap has been removed. 80 mm 40 mm Please discharge the high voltage from the anode. Wipe off the applied grease and then apply new grease.
Page 7: Service Hint
Service Hint How to chassis into service position Pull toward Stand the main chassis A-Board Remove 8 Screws D-Board Service Position for DG-board. Note: Extension cable kit (4 pieces of 8 pin cable) is supplied as service fixtures and tools. (Part No.
Page 8 Board and module layout drawing Before inspection Inspect the board [L] and adjust the white balance, H-V, etc. 1. Remove the screws fixing the rear cover (8 screws) and the screw fixing the AC code cover. - 8 -...
Page 9 Inspection of the boards [A] and [D] Inspection of the boards [G] and [K] 1. Disconnection the degaussing coil cable and the speaker 1. Pull out the chassis frame to the front, and rotate the cable clamps (2 places) and the lead clamps on the print chassis frame as shown in following figure.
Page 10 Inspection and exchange of the rear termi- 3. Inspection is possible in the following condition. 4. In case of exchange, disconnect the coupler H5 from the nal switching board [H] rear terminal switching board [H], and disengage the cou- 1. Remove the screws fixing the rear terminal cover (3 pler in upward direction either in this condition or with the screws), disengage the locking tabs (4 places), and rear terminal switching board [H] slightly raised.
Page 11 Exchange of each board 1. Disengage the cable (between H5 and L1) from the lead clamp on the print holder. 2. Remove the print holder set screw, disengage the tab, and remove the print holder. Set screw (1 screw) Print holder Tab part Lead clamp 3.
Page 12: Adjustment
Adjustment As shown in the following table, adjustment is required when some parts have been exchanged. Video signal Flyback Exchange part Memory Digital core DAF board processing Picture tube Deflection yoke transformer IC1114 board [DG] [DF] Adjustment board [AG] T551 White balance adjustment H-V adjustment Amplitude compensation...
Page 13 In regard to the adjustment items Initial screen for service adjustment mode 1. Main Items Button " " for selection Button " " for selection in forward direction in reverse direction G-MAG G-MAG (Sub-adjustment) (WB adjustment) (H-V adjustment) (G-MAG adjustment) (OPT adjustment) 2.
Page 14 • H-V adjustment Initial screen for service adjustment mode Button " " for selection Button " " for selection in forward direction in reverse direction G-MAG G-MAG (Sub-adjustment) (WB adjustment) (H-V adjustment) (G-MAG adjustment) (OPT adjustment) For factory adjustment, do not touch. Button "...
Page 15 Adjustment accompanying exchange of the picture tube • When the picture or the deflection yoke ha been exchanged, perform all of the following adjustment in the following order. When no part exchange has been done, adjustment still must be performed. Procedure Confirmation of demagnetization VRS adjustment...
Page 16 Purpose: Adjusting the red, blue, and green electron beams so that they hit 1. VRS adjustment the specified fluorescent substance correctly. Adjustment jig Demagnetizer, color bar generator 1. Receive a crosshatch pattern. TV screen (visual observation) Measuring location 2. Confirm that the knobs of purity magnet, 4-pole convergence magnet and 6-pole convergence magnet all Input signal Crosshatch pattern...
Page 17 Purpose: Adjusting the red, blue, and green electron beams so that they hit 2. Purity Adjustment the specified fluorescent substance correctly. Adjustment jig Color bar generator 1. Receive a crosshatch pattern and perform simple Measuring location TV screen (visual observation) adjustment of the convergence with the convergence magnets.
Page 18 Fig. 6 Open 3. Gradually open the knobs of the 6-pole convergence magnets and Rotate match the red and blue vertical lines at the center of the screen. (At this time, red and blue will move practically at the same time.) Next, rotate the entire 6-pole magnets to match the red and blue horizontal lines to green.
Page 19 H-V adjustment • For this adjustment, receive a crosshatch pattern, check whether adjustment is required or not, and then adjust. This unit is equipped with a “16:9 mode” which identifies the input from S-video input and switches automatically to 16:9 screen size for the full mode (squeeze signal) from a video camera or DVD.
Page 20 2. Vertical adjustment Purpose: Adjustment of amplitude and linearity of the image in vertical direction. Adjustment jig Color pattern generator Meassuring location TV screen (visual observation) Adjustment conditions Adjustment location Remote control buttons [VOL +/-] Image adjustment Standard Image menu Image 4 (dynamic) Input signal Crosshatch pattern...
Page 21 3. Horizontal adjustment Purpose: Adjustment of amplitude and linearity of the image in horizontal direction. Adjustment jig Color pattern generator Adjustment conditions Meassuring location TV screen (visual observation) Image adjustment Standard Adjustment location Remote control buttons [VOL +/-] Image menu Image 4 (dynamic) Input signal Crosshatch pattern...
Page 22 H-TPN Upper and lower pincushion compensation adjustment (top pincushion compensation) adjustment 8. Set to the item [H-TPN]. 9. Adjust with the remote control buttons [VOL +/-] so that the lines in the upper part of the crosshatch pattern becomes straight lines. 10.
Page 23 White balance adjustment 1. Preparatory adjustment Purpose: Facilitation of white balance adjustment. Adjustment jig Color pattern generator 1. Establish the required conditions for white balance adjustment Meassuring location according to the following table. Input signal Studio color bar Image 4 (dynamic) Color temperature (high) 1: At the time of adjustment, the color signal Screen mode 4:3...
Page 24 3. White balance adjustment Purpose: Optimizing the white balance (back and white) for the image. Adjustment jig Color pattern generator Meassuring location TV screen (visual observation) Input signal Studio color bar The items "1. Preparatory adjustment" and "2. Sub-brightness adjustment" must have been executed. 1.
Page 25 Focus adjustment 1. Focus adjustment Adjustment jig Color pattern generator Adjustment conditions Measuring location TV screen (visual observation) Black level "0" Center Image adjustment Input signal Crosshatch pattern Picture "+30" Maximum Set GR to "ON". (Refer to page 10 in the Service Manual.) 1.
Page 26 Adjustment after exchange of the video signal processing board [AG] 1. Contrast Adjustment Adjustment jig Color pattern generator Adjustment conditions Oscilloscope Image menu Dynamic Meassuring location TP47G (board [A]) Picture Maximum (+30) Board [A], coupler [A31], pin 2 Image adjustment Black level Center (0) Adjustment location Remote control buttons [VOL +/-]...
Page 27 2. Color Output, Hue Adjustment Adjustment jig Color pattern generator Performed after "1. Contrast Adjustment". Oscilloscope Adjustment conditions Measuring location Board [A], TP47G, TP47R Image menu Dynamic Input signal Rainbow color pattern Color darkness Center (0) Center (0) Image adjustment Picture Maximum (+30) Black level...
Page 28 Memo - 28 -...
Page 29: Schematic Diagrams
Schematic Diagram Important Safety Notice Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacture's specified parts. Notes: 1. Resistor All resistors are cabon 1/4W resistor, unless marked as follows: Unit of resistance is OHM [ ] (K=1,000, M=1,000,000).
Page 30 Remote Control Transmitter TNQE196 D1002 2.2 - 3.5V D1003 POD2 POD1 POD3 POD0 D1004 R1001 POC3 TP10 POE0 POC2 TP11 D1001 POE1 POC1 TP12 POE2 POC0 TP13 POE3 POB3 TP14 Q1001 POB2 TP15 POB1 TP16 C1001 XOUT POB0 TP17 POA3 TP18 POA2 TP19...
Page 31 - 31 -...
Page 32 P-BOARD/A-BOARD - 32 -...
Page 33 - 33 -...
Page 34 A-BOARD/D-BOARD - 34 -...
Page 35 - 35 -...
Page 36 N-BOARD/L-BOARD - 36 -...
Page 37 - 37 -...
Page 38 DG-BOARD/AG-BOARD - 38 -...
Page 39 - 39 -...
Page 40 H-BOARD/DF-BOARD - 40 -...
Page 41 - 41 -...
Page 42 G-BOARD/G-BOARD - 42 -...
Page 43 - 43 -...
Page 44 - 44 -...
Page 45: Parts Location & Mechanical Replacement Parts List
• Front View • Rear View DEFLECTION YOKE HANDLE CABINET PICTURE TUBE DEGAUSSING COIL POWER BUTTON TERMINAL DOOR AC POWER CORD PANASONIC BADGE CONTROL DOOR REAR TERMIAL FRAME • Chassis Board Layout View SPEAKER (L) L-BOARD V-BOARD K-BOARD D-BOARD SPEAKER (L)
