Fresco
Installation Guide
For Model:
FRS52-LED
E192641
net weight of fan: 18.3 lb (8.3 kg)
READ THESE INSTRUCTIONS AND
AND SAVE THEM FOR FUTURE USE

Table of Contents:

pg. 10
Warranty. pg. 12
page 1
PRINTED IN CHINA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fresco FRS52-LED and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Craftmade Fresco FRS52-LED

Summary of Contents for Craftmade Fresco FRS52-LED

  • Page 1: Table Of Contents

    READ THESE INSTRUCTIONS AND AND SAVE THEM FOR FUTURE USE Fresco Installation Guide For Model: FRS52-LED Table of Contents: Safety Tips. pg. 2 Unpacking Your Fan. pg. 3 Parts Inventory. pg. 3 Installation Preparation. pg. 4 Hanging Bracket Installation. pg. 4 Fan Assembly.

  • Page 2: Safety Tips

    (2) this LED light kit must accept any interference received, including interference that may cause undesired operation. Distributed by: Craftmade, 650 S. Royal Lane, Coppell, TX, 75019; 1-800-486-4892 NOTE: The important safety precautions and instructions appearing in the manual are not meant to cover all possible conditions and situations that may occur.

  • Page 3: Unpacking Your Fan

    1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.

  • Page 4: Installation Preparation

    3. Installation Preparation. blade edge To prevent personal injury and damage, ensure inches 7 feet that the hanging location allows the blades a (2.13 m) (76 cm) clearance of 7 feet (2.13m) from the floor and 30in. (76cm) from any wall or obstruction. This fan is suitable for room sizes up to 12ft.

  • Page 5: Fan Assembly. Pgs

    5. Fan Assembly. stop pin set screw Remove hanging ball from downrod provided by loosening set screw on hanging ball. Lower hanging ball and remove stop pin and then slide hanging ball hanging ball off of the downrod. [Refer to diagram 1.] Loosen yoke set screws and nuts at top of motor diagram 1 housing.

  • Page 6: Wiring. Pgs

    wood ceiling 5. Fan Assembly. (cont.) joist safety cable loop With the hanging bracket secured to the outlet box and able to support the fan, you are now ready to hang your fan. Grab the fan firmly with two hands. Slide downrod through opening in hanging bracket and let hanging ball wood screw rest on the hanging bracket.
  • Page 7 6. Wiring. (cont.) [PLEASE NOTE: Wall and/or handheld remote Modifications not approved by the party responsible for compliance could void the user's authority to operate the equipment. control must be used for fan to operate. If you do *NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 8: Canopy Assembly

    7. Canopy Assembly. hanging bracket Locate 2 screws on underside of hanging bracket and remove screw closest to the open end of the antenna hanging bracket. Partially loosen the other screw. screw Lift canopy to hanging bracket. Place rounded part of slotted hole in canopy over loosened screw in canopy hanging bracket and push up.

  • Page 9: Light Kit Assembly

    9. Light Kit Assembly. motor Remove 1 screw from motor plate on housing underside of motor housing and partially loosen the other 2 screws. Align slotted holes in fitter plate with loosened screws in motor motor plate plate, allowing molex connections from motor housing to come through hole in fitter plate middle of fitter plate--remove and discard...
  • Page 10 10. Handheld Remote Control Assembly. IN ORDER TO USE THE HANDHELD REMOTE CONTROL, remote control PLEASE CONTINUE WITH SECTION 10 for remote control cover assembly instructions. If you have already installed the wall control but do not wish to use the handheld remote control, please proceed to Section 11.

  • Page 11: Assembly Of Handheld Remote Control

    11. Automated Learning Process./Activating Code. CAUTION: The wall and/or handheld remote control can be programmed to multiple receivers or fans. If this is not desired, turn wall switch off to any other programmable receiver or fan. Restore electrical power and then, if using wall control, set slider switch on wall control to the ON position.

  • Page 12: Troubleshooting

    Service at 1-800-486-4892 to arrange for return of fan. 2. Check to be sure wall control (optional use) is wired Return fan, shipping prepaid, to Craftmade. We will repair properly. or ship you a replacement fan, and we will pay the return 3.
