  • Page 1 FCC ID : BEJL20MP APPENDIX F : USER’S MANUAL...

  • Page 2: Canadian Doc Notice

    Regulatory Information FCC Compliance Statement CE Conformity Notice (for Europe) This equipment has been tested and found to comply within Products with the “ C E ” Marking comply with the EMC the limits of a Class B digital device pursuant to Part 15 of Directive(89/336/EEC) and LOW VOLTAGE Directive the FCC Rules.
  • Page 3 Regulatory Information cont. scheme, which provides for international environmental Lead can be found in picture tubes, display screens, solder, labelling of personal computers. The labelling scheme was and capacitors. Lead damages the nervous system and in developed as a joint effort by the TCO (The Swedish higher doses causes lead poisoning.
  • Page 4 Regulatory Information cont. TCO99 The energy requirements include a demand that the computer and/or display, after a certain period of inactivity, shall reduce its power consumption to a lower level in one or more stages. The length of time to reactivate the computer shall be reasonable for Congratulations! the user.
  • Page 5 (U.S.A only) is a set of power-saving guidelines NERGY issued by the U.S. Environmental Protection Agency(EPA). As an ENERGY STAR Partner LG Electronics U.S.A.,Inc. has determined that this product meets the ENERGY STAR guidelines for energy efficiency. EPA POLLUTION PREVENTER...
  • Page 6 User’s Guide L2010P ake sure to read the Important Precautions before using the product. Keep the User's Guide(CD) in an accessible place for furture reference. ee the label attached on the back cover and quote this information to your dealer when you require service.
  • Page 7 Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential e shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing.
  • Page 8 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.

  • Page 9: Positioning Your Display

    Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Positioning your display Adjust the position of the panel in various ways for maximum comfort. Tilt Range : -5˚~30˚...

  • Page 10: Using The Computer

    Connecting the Display Using the Computer Place the monitor in a convenient, well-ventilated location near your computer. To adjust height of your monitor, unlock the stand lock on top of the stand. Connect the signal cable. When attached, tighten the thumbscrews to secure the connection.
  • Page 11 Connecting the Display To arrange cables in order Press the push button, and pull the stand cover down to separate it from the stand. Stand cover Push button PUSH PUSH After connecting cables, put the stand cover correctly into the holes on the stand.

  • Page 12: Front Panel Controls

    Control Panel Functions Front Panel Controls Control Function Power Button Use this button to turn the display on or off. Power (DPMS) This Indicator lights up green when the display Indicator operates normally. If the display is in DPM (Energy Saving) mode, this indicator color changes to amber.
  • Page 13 Control Panel Functions Control Direct Access Function Bring up Contrast and Brightness adjustment. LIGHT VIEW: LIGHT VIEW This feature lets you easily select the best desired image condition TEXT MOVIE optimized to the environment (ambient illumination, image types etc.). PHOTO NIGHT TEXT MOVIE...

  • Page 14: Screen Adjustment

    On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls. The following section is an outline of the available adjustments and selections you can make using the OSD.
  • Page 15 On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Main menu Sub menu Reference CONTRAST To adjust the brightness and CONTRAST/ contrast of the screen BRIGHTNESS BRIGHTNESS USER(R/G/B) COLOR To customize the color of the ADJUSTMENT screen...
  • Page 16 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. NOTE OSD (On Screen Display) menu languages on the monitor may differ from the manual.

  • Page 17: To Improve The Clarity And Stability Of The Screen

    On Screen Display(OSD) Selection and Adjustment To improve the clarity and stability of the screen OSD Adjust Description This function is suitable for analog signal input AUTO TRACKING only. This button is for the automatic R G B adjustment of the screen position, clock and AUTO CLOCK phase.
  • Page 18 On Screen Display(OSD) Selection and Adjustment To adjust position of the OSD window on the screen OSD Adjust Description Horizontal Position OSD POSITION To adjust horizontal position of the OSD window on the screen. R G B Vertical Position To adjust vertical position of the OSD window on the screen.

  • Page 19: No Image Appears

    Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the Check and see if the power cord is connected display connected? properly to the power outlet. Is the power indicator Press the Power button.

  • Page 20: Display Image Is Incorrect

    Troubleshooting Display image is incorrect Display Position is Press the AUTO button to automatically adjust incorrect. your display image to the ideal setting. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display. Check Control Panel -->...

  • Page 21: Have You Installed The Display Driver

    Troubleshooting “IMAGE SIZE” function on OSD menu does not work. “IMAGE SIZE” function Check if the resolution is set as 1600x1200 or less on OSD menu does not than 512x360. work? The optimal resolution is 1600x1200 and the image is fully displayed on the monitor and is not converted as 1:1 image size.
  • Page 22 Specifications Display 20.1 inches (51.0cm) Flat Panel Active matrix-TFT LCD Anti-Glare coating 20.1 inches viewable 0.255mm pixel pitch Horizontal Freq. Analog : 28 - 92kHz (Automatic) Sync Input Digital : 28-80kHz (Automatic) Vertical Freq. 56 - 85Hz (Automatic) Input Form Separate TTL, Positive/Negative Composite TTL Positive/Negative SOG (Sync On Green)
  • Page 23 Specifications Attached( O ), Detached ( Tilt/Swivel Stand Attached( ), Detached ( O ) Signal cable Wall-outlet type or PC-outlet type Power cord NOTE Information in this document is subject to change without notice.

  • Page 24: Preset Modes (Resolution)

    Specifications Preset Modes (Resolution) Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 31.47 640 x 350 31.47 640 x 480 37.50 640 x 480 43.27 640 x 480 31.47 720 x 400 37.88 800 x 600 46.88 800 x 600 53.67 800 x 600 49.72...
  • Page 25 Specifications VESA wall mounting Connected to another object (stand type and wall- mounted type. This monitor accepts a VESA- compliant mounting interface pad.- optional) For further information, refer to the VESA Wall Mounting Instruction Guide. Kensington Security Slot- optional Connected to a locking cable that can be purchased separately at most computer stores...

  • Page 26: Signal Connector Pin Assignment

    Specifications Signal Connector Pin Assignment DVI-I Connector Signal(DVI-I) Signal(DVI-I) T. M. D. S. Data2- Hot Plug Detect T. M. D. S. Data0- T. M. D. S. Data2+ T. M. D. S. Data2/4 Shield T. M. D. S. Data0+ T. M. D. S. Data0/5 Shield T.

  • Page 27: Usb Connection

    Making use of USB (Universal Serial Bus) - Optional USB (Universal Serial Bus) is an innovation in connecting your different desktop peripherals conveniently to your computer. By using the USB, you will be able to connect your mouse, keyboard, and other peripherals to your display instead of having to connect them to your computer.

  • Page 28: Usb Specifications

    Making use of USB (Universal Serial Bus) - Optional USB Specifications Rev. 1.1 complied BUS-powered hub USB standard 500mA for each (MAX) Downstream power supply 12 Mbps (full), 1.5 Mbps (low) Communication speed USB port 1 Upstream port 2 Downstream ports IMPORTANT: These USB connectors are not designed for use with high-power USB devices such as a video camera, scanner, etc.
  • Page 29 Digitally yours...
