- Page 1 Test Report No.: GETEC-E3-07-079 FCC Class B Certification APPENDIX H : USER’S MANUAL EUT Type: LCD Monitor FCC ID: BEJW2600HS...
- Page 2 User’s Guide W2600H ake sure to read the Important Precautions before using the product. Keep the User's Guide(CD) in an accessible place for future reference. ee the label attached on the product and give the information to your dealer when you ask for service.
-
Page 3: Important Precautions
Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential electrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing. - Page 4 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
-
Page 5: Connecting The Display
Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connecting the stand base or Removing the stand base Place the monitor with its front facing downward on a cushion or soft cloth. Align the hooks on the Stand Body with the matching slots in the Stand Base. - Page 6 Connecting the Display Attach the monitor to the Stand Base by turning the screw to the right. Screw : Turn the screw by using the screw handle. Lift and turn the monitor to face towards the front after the connection is made to the female part of the cable you're attaching.
-
Page 7: Positioning Your Display
Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Positioning your display Adjust the position of the panel in various ways for maximum comfort. Tilt Range : -5˚~20˚... -
Page 8: Using The Computer
Connecting the Display Using the Computer Make sure to turn off the computer and product. Connect the cable as below sketch map form Connect D-sub Cable (PC) Connect D-sub Cable (Mac) Connect DVI-D Cable NOTE This is a simplified representation of the rear view. -
Page 9: Connecting The Usb(Universal Serial Bus) Cable
Connecting the Display Connecting the USB(Universal Serial Bus) Cable "USB (Universal Serial Bus)" is an innovation in connecting your different desktop peripherals conveniently to your computer. By using the USB, you will be able to connect your mouse, keyboard, and other peripherals to your display instead of having to connect them to your computer. -
Page 10: To Arrange The Cables
Connecting the Display To arrange the cables Connect the power cord and the signal cable as shown in the figure and then fix them to the cable holders 1 and 2. Please put the power cord and Please insert the cable holder1 into the hole. -
Page 11: Control Panel Functions
Control Panel Functions Front Panel Controls At the current display, Use 'ez Zooming' Key, then the display ZOOMING resolution is transferred to the one step low resolution. Use 'ez Zooming' Key one more, the display is back to the original display. *Only One touch of ez-zoom, you can fine the best resolution you want and it is possible to magnify the size of characters and pictures for the old not having good eye sight, housewives not... - Page 12 Control Panel Functions Use these buttons to select or adjust functions in the On Buttons Screen Display. For more information, refer to page A17. Use this button to make D-Sub or DVI connector active. This feature is used when two computers are connected to the display.
-
Page 13: On Screen Display (Osd) Control Adjustment
On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls. The following section is an outline of the available adjustments and selections you can make using the OSD. - Page 14 On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Main menu Sub-menu Reference BRIGHTNESS PICTURE To adjust the brightness, contrast and gamma of the CONTRAST screen GAMMA sRGB To customize the color of COLOR PRESET 6500K...
-
Page 15: On Screen Display(Osd) Selection And Adjustment
On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Touch the MENU Button, then the main menu of the OSD appears. - Page 16 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description PICTURE To adjust the brightness of the screen. BRIGHTNESS P I C T U R E To adjust the contrast of the screen. CONTRAST GAMMA Set your own gamma value. : -50/0/50 On the monitor, high gamma values display whitish images and low gamma values display high contrast images.
- Page 17 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description POSITION To move image left and right. HORIZONTAL P O S I T I O N To move image up and down. VERTICAL MENU : Exit : Decrease : Increase : Select another sub-menu TRACKING T R A C K I N G...
- Page 18 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description LANGUAGE To choose the language in which the control names are displayed. SETUP To adjust position of the OSD window POSITION on the screen. S E T U P WHITE If the output of the video card is different BALANCE...
-
Page 19: Flatron F-Engine
On Screen Display(OSD) Selection and Adjustment The OSD screen will appear when you touch the button on the front of the monitor. Menu Name Icons Sub-menu Name FLATRON F-ENGINE Screen when applied Screen when not applied When you execute F-ENGINE, two tones will appear on the screen as shown. -
Page 20: Troubleshooting
Troubleshooting Check the following before calling for service. No image appears No image appears ● Is the power cord of the • Check and see if the power cord is connected display connected? properly to the power outlet. ● Is the power indicator •... -
Page 21: Display Image Is Incorrect
Troubleshooting Display image is incorrect ● Display Position is • Touch the AUTO/SET button to automatically incorrect. adjust your display image to the ideal setting. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display. -
Page 22: Have You Installed The Display Driver
Troubleshooting Display image is incorrect ● The screen color is • Check if the signal cable is properly connected mono or abnormal. and use a screwdriver to fasten if necessary. • Make sure the video card is properly inserted in the slot. -
Page 23: Specifications
Specifications Display 26 inches (64.868cm) Flat Panel Active matrix-TFT LCD Anti-Glare coating 26 inches viewable 0.2865 mm pixel pitch Horizontal Freq. Analog : 30 - 83 kHz (Automatic) Sync Input Digital : 30 - 83 kHz (Automatic) Vertical Freq. 56 - 75 Hz (Automatic) Input Form Separate TTL, Positive/Negative SOG (Sync On Green) - Page 24 Specifications Stand Base Attached ( ), Detached ( O ) Power cord Wall-outlet type or PC-outlet type Standard USB 2.0, Self-Power Data Rate Max 480 Mbps Power Consumption Max 2.5W x 2 NOTE Information in this document is subject to change without notice.
-
Page 25: Preset Modes (Resolution)
Specifications Preset Modes (Resolution) Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 640 x 480 31.469 59.940 640 x 480 37.500 75.000 720 x 480 35.162 59.901 720 x 400 31.500 70.156 800 x 600 37.879 60.317 800 x 600 46.875 75.000 1024 x 768... -
Page 26: Installing The Wall Mount Plate
Installing the Wall mount plate This monitor satisfies the specifications of the Wall mount plate or the interchange device. After moving the product to face downward, make sure to place it on a soft cloth or a cushion to avoid surface damage. - Page 27 Digitally yours...
-
Page 28: Regulatory Information
Regulatory information Regulatory information... - Page 29 Regulatory Information cont. respecte toutes les exigences du Règlement sur le FCC Compliance Statement matériel brouilleur du Canada. This equipment has been tested and found to comply NOTICE within the limits of a Class B digital device pursuant to Part The regulations are applied only to the products with the 15 of the FCC Rules.
- Page 30 Regulatory Information cont. computer and/or display, after a certain period of inactivity, Why do we have environmentally labelled computers? In many countries, environmental labelling has become an shall reduce its power consumption to a lower level, in one established method for encouraging the adaptation of or more stages.
- Page 31 Regulatory Information cont. relevant bio-accumulative TCO’95 requirement permits Monitor Disposal the inclusion of lead, as no replacement has yet been WARNING developed. If you need to dispose of a monitor, ask a qualified service representative for the proper procedure. Improper disposal could Cadmium is present in rechargeable batteries and in the result in personal injury from implosion.
- Page 32 Regulatory Information cont. Approval requirements cover a wide range of issues: ecology, ergonomics, emission of electrical and TCO’99 requires that plastic components weighing more magnetical fields, energy consumption and electrical than 25 grams shall not contain flame retardants with safety. organically bound bromine or chlorine.
- Page 33 The product must be prepared for recycling and the If you want to find out more information about our recycling manufacturer must have a certified environmental program, please contact your local LG vendor or a management system such as EMAS or ISO 14 001 corporate representative of LG.
- Page 34 La LGE. ha annunciato nel 1994 la cosiddetta 'LG http://www.lge.com/experience/social_commitment/enviro Declaration for a Cleaner Environment' (Dichiarazione di ment.jsp LG a favore di un ambiente più pulito), un ideale che da allora funge da principio ispiratore della gestione aziendale. La dichiarazione rappresenta il fondamento che Français consente di intraprendere attività...
- Page 35 LGE. presentó la 'Declaración para un entorno más limpio Declaração é a base que nos tem permitido realizar de LG' en 1994 y este ideal ha servido para guiar nuestros atividades favoráveis ao ambiente com consideração principios empresariales desde entonces. La Declaración atenta aos aspectos econômicos, ambientais e sociais.
- Page 36 ¬ 1994 „Ó‰Û ÍÓÔÓ‡ˆËˇ LGE ÓÔÛ·ÎËÍÓ‚‡Î‡ het milieu 'ƒÂÍ·‡ˆË˛ LG ÔÓ Óı‡Ì ÓÍÛʇ˛˘ÂÈ Ò‰˚', LGE. publiceerde in 1994 de 'LG Declaration for a Cleaner ÍÓÚÓ‡ˇ Ò ÚÂı ÔÓ ÒÎÛÊËÚ ÓÒÌÓ‚Ì˚Ï ÔË̈ËÔÓÏ Environment' (de LG-verklaring met betrekking tot een ÛÔ‡‚ÎÂÌˡ. Õ‡ ÓÒÌÓ‚Â ˝ÚÓÈ ‰ÂÍ·‡ˆËË Ï˚ ÒÏÓ„ÎË...
- Page 37 LG 공급업체나 LG 기업 대표부에 문의하시기 바랍니다. ‰ÂÈÒÚ‚Û˛Ú ÒËÒÚÂÏ˚ ÛÚËÎËÁ‡ˆËË ÓÚıÓ‰Ó‚ Ë ‚ÓÁ‚‡Ú‡ ËÒÔÓθÁÓ‚‡ÌÌÓÈ ÔÓ‰Û͈ËË. ÃÌÓ„Ë ÍÓÏÔÓÌÂÌÚ˚ LG 전자는 기업 개선 정책의 하나로 지구 환경 문제를 ·Û‰ÛÚ ‚ÚÓ˘ÌÓ ËÒÔÓθÁÓ‚‡Ì˚ Ë ÛÚËÎËÁËÓ‚‡Ì˚, ‚ ÚÓ 채택함으로써 보다 나은 환경을 만들어 나가기 위한...
