Summary of Contents for Smeg CV215NF
- Page 1 CV215PNF2 CV215NF Instruction Manual Manuale di istruzioni Notice d'Utilisation Bedienungsanleitung Руководство пользователя Manual de instrucciones Brugsvejledning ﺩﻟﻳﻝ ﺍﻟﻣﺳﺗﺧﺩﻡ Navodila za uporabo...
- Page 2 Please read this user manual first! Dear Customer, We hope that your product, which has been produced in modern plants and checked under the most meticulous quality control procedures, will provide you an effective service. Therefore, read this entire user manual carefully before using the product and keep it as a reference.
-
Page 3: Table Of Contents
CONTENTS 1 Your Freezer 6 Maintenance and cleaning 2 Safety and environment instructions 7 Troubleshooting 3 Installation Points to be paid attention to when the relocation of the freezer ......9 Electrical connection ......10 Disposing of the packaging ....10 Disposing of your old freezer .....10 Placing and Installation...... -
Page 4: Your Freezer
Your Freezer 1. Thermostat 2. Flap (Fast-Freeze compartment) 3. Drawers 4. Adjustable front feet C Figures that take place in this instruction manual are schematic and may not correspond exactly with your product. If the subject parts are not included in the product you have purchased, then it is valid for other models. -
Page 5: Safety And Environment Instructions
Safety and environment instructions This section provides the safety – catering and similar non-retail instructions necessary to prevent the applications. risk of injury and material damage. 1.1. General safety • Failure to observe these instructions This product should not be used by will invalidate all types of product persons with physical, sensory and warranty. - Page 6 • Do not place containers hol- ding liquids on top of the product. Splashing water on an electrified part may cause electric shock and risk of fire. • Exposing the product to rain, snow, sunlight and wind will cause electri- cal danger.
- Page 7 1.1.2 For models with 1.3. Child safety • water dispenser Keep packaging materials out of • Pressure for cold water inlet shall be children’s reach. • maximum 90 psi (620 kPa). If your Do not allow the children to play water pressure exceeds 80 psi (550 with the product.
- Page 8 1.6. Package information Packaging materials of the product are manufactured from recyclable materials in accordance with our National Environment Regulations. Do not dispose of the packaging materials together with the domestic or other wastes. Take them to the packaging material collection points designated by the local authorities.
-
Page 9: Installation
Installation Check the following before you The manufacturer will not be start to use your freezer: liable for any event caused by 1. Attach 2 plastic wedges as disregarding the information illustrated below. Plastic wedges supplied in this user manual. are intended to keep the distance Points to be paid attention which will ensure the air circulation... -
Page 10: Electrical Connection
4. When the compressor starts to Disposing of the packaging operate, a sound will be heard. The The packing materials may be liquid and gases sealed within the dangerous for children. Keep the refrigeration system may also give rise to noise, even if the compressor packing materials out of the reach of children or dispose of them by is not running and this is quite normal. -
Page 11: Placing And Installation
Placing and Installation If the entrance door of the room where the freezer will be installed is not wide enough for the freezer to pass through, then carefully remove the doors of your freezer and pass it sideways through the door. 1. - Page 12 Reversing the doors Proceed in numerical order .
-
Page 13: Preparation
Preparation • The baskets/drawers that are • Your refrigerator should be installed at least 30 cm away from heat provided with the chill compartment sources such as hobs, ovens, central must always be in use for low energy heater and stoves and at least 5 consumption and for better storage cm away from electrical ovens and conditions. -
Page 14: Using Your Freezer
Using your freezer 1.Freezer Set Function Quick Freeze indicator will remain This function allows you to make the lit when the Quick Freeze function freezer compartment temperature is enabled. To cancel this function setting. press Quick Freeze button again. Press this button to set the Quick Freeze indicator will turn off and temperature freezer... -
Page 15: Freezing Fresh Food
Freezing fresh food 3. Take special care not to mix already frozen food and fresh food. • It must be preferred to wrap or cover Recommendations for the food before placing them in the preservation of frozen food refrigerator. • Hot food must cool down to the • Prepacked commercially frozen food room temperature before putting should be stored in accordance with... -
Page 16: Deep-Freeze Information
Foodstuff to be frozen should not be allowed to come in contact with Crisper Vegetables and fruits the previously frozen items to prevent their partial thawing. Delicatessen products Freshzone (cheese, butter, salami Frozen food must used compartment and etc.) immediately after they are thawed Deep-freeze information and they should never be re-frozen. - Page 17 Maintenance and cleaning Cleaning your fridge at regular • Remove the door shelves by pulling intervals will extend the service life of them up. After cleaning, slide them the product. from top to bottom to install. WARNING: • Never use cleaning agents or water Unplug the product before cleaning that contain chlorine to clean the outer surfaces and chromium coated...
- Page 18 Troubleshooting Check this list before contacting the not balanced, which triggers the compressor thermic safeguard. service. Doing so will save you time and money. This list includes frequent The product will restart after complaints that are not related to approximately 6 minutes. If the faulty workmanship or materials.
- Page 19 The food items kept in cooler • Large quantities of hot food may compartment drawers are have been recently placed into the frozen. product. >>> Do not place hot food • The cooler compartment into the product. temperature is set to a very low • The doors were opened frequently degree.
- Page 20 • Any items placed on the product • The foods were placed in unsealed may cause noise. >>> Remove any holders. >>> Keep the foods in items placed on the product. sealed holders. Micro-organisms may spread out of unsealed food The product is making noise of items and cause malodour.
- Page 21 Gentile cliente, ci piacerebbe che lei potesse raggiungere un livello di efficacia ottimale dal nostro prodotto, che è stato realizzato in una struttura moderna, adottando controlli meticolosi a livello qualitativo. A tal fine la invitiamo a leggere con attenzione il manuale dell'utente prima di iniziare a servirsi del dispositivo.
