Introduction
These instructions describe the installation of a Pro-Stock
240 Vac Type THQB single- or three-phase circuit breaker kit
into a ReliaGear lighting panelboard. These kits are not for use
in standard, factory-assembled panelboards.
The catalog number for the single-phase, two-pole kit is MB612
and the list of parts is found in Table 1. The catalog number for
the three-phase, three-pole kit is MB613 and the list of parts is
found in Table 2. The catalog number for the single-phase, four-
pole kit is MB614 and the list of parts is found in Table 3. The
catalog number for the three-phase, six-pole kit is MB616 and
the list of parts is found in Table 4.
Table 1. Parts list for the 240 Vac THQB single-phase, two-pole
breaker installation kit, catalog number MB612.
Item #
Description
1
Shield Insert
2
Nut, 5/16-18
3
Screw, #10-32 x 3/8
4
Circuit Breaker Base
5
Label, "MAIN"
6
Screw, One-Way, #10-32
7
Screw, #10-32 x 1-1/2
Table 2. Parts list for the 240 Vac THQB three-phase, three-pole
breaker installation kit, catalog number MB613.
Item #
Description
1
Shield Insert
2
Nut, 5/16-18
3
Screw, #10-32 x 3/8
4
Circuit Breaker Base
5
Label, "MAIN"
6
Screw, One-Way, #10-32
7
Screw, #10-32 x 1-1/2
Part #
Qty.
10081132P12
1
N269P23B6
2
N722EP16006B6
4
1
315A7337P1
1
192A6976P99
2
N722P16024B6
2
Part #
Qty.
10081132P7
1
N269P23B6
3
N722EP16006B6
4
1
315A7337P1
1
192A6976P99
3
N722P16024B6
2
®
, 240 Vca
Introduction
Ces instructions décrivent l'installation d'un kit de disjoncteur
à une ou trois phases de Type THQB 240 Vca Pro-Stock dans un
panneau d'éclairage ReliaGear. Ces kits ne doivent pas être
utilisés avec des panneaux standards assemblés en usine.
Le numéro de catalogue pour le kit deux-pôles, phase simple est
MB612 et la liste des pièces se trouve à la Table 1. Le numéro de
catalogue pour le kit trois pôles, trois-phases est MB613 et la liste
des pièces se trouve à la Table 2. Le numéro de catalogue pour le
kit quatre- pôles, phase simple est MB614 et la liste des pièces se
trouve à la Table 3. Le numéro de catalogue pour le kit six-pôles,
trois-phases est MB616 et la liste des pièces se trouve à la Table 4.
Table 1. Liste des pièces pour kit d'installation de disjoncteur
deux-pôles, phase simple THQB 240 Vca, numéro de catalogue
MB612.
Item #
Description
1
Rajout du garde
2
Écrou, 5/16-18
3
Vis, #10-32 x 3/8
4
Base du disjoncteur
5
Étiquette "MAIN"
6
Vis à usageunique, #10-32 192A6976P99
7
Vis, #10-32 x 1-1/2
Table 2. Liste des pièces pour kit d'installation d'un disjoncteur
trois-pôles, trois-phases THQB 240 Vca, numéro de catalogue
MB613.
Item #
Description
1
Rajout du garde
2
Écrou, 5/16-18
3
Vis, #10-32 x 3/8
4
Base du disjoncteur
5
Étiquette "MAIN"
6
Vis à usageunique, #10-32 192A6976P99
7
Vis, #10-32 x 1-1/2
Pièce #
Qté.
10081132P12
1
N269P23B6
2
N722EP16006B6
4
1
315A7337P1
1
2
N722P16024B6
2
Pièce #
Qté.
10081132P7
1
N269P23B6
3
N722EP16006B6
4
1
315A7337P1
1
3
N722P16024B6
2
