Kicker Q-CLASS CompQ10 Owner's Manual page 4

SEALED ENCLOSURE APPLICATIONS
These sealed enclosure designs give the smoothest response with increased energy at the lowest frequencies, 20Hz–30Hz. These designs deliver massive amounts of
highly-accurate bass and can be driven with punishing levels of amplifi er power. The high performance suspension system can operate in a larger sealed enclosure. This
maximum enclosure volume application is ideal for ultra sound quality installations. The maximum enclosure generates a very fl at response curve and superbly extends
the sub-bass response.
CompQ woofers perform well in any size sealed enclosure between the minimum and maximum volume recommendations. These systems will exhibit benefi ts of both
designs: Minimum produces high-impact bass, and maximum generates low bass frequency protraction. Overall, the system will sound more like the recommended
enclosure design it is closest to in enclosure volume. These enclosure recommendations have been calculated with the airspace inside the enclosure and include the
displacement of the woofer. All sealed-enclosure airspace should be fi lled to 50% loose poly-fi l (polyester fi berfi ll) stuffi ng. Do not make the airspace greater than the
maximum enclosure volume recommendation.
Minimum Sealed
Model Volume ft 3 (L)
CompQ10 .66 (18.7)
CompQ12 .88 (24.92)
CompQ15 1.5 (42.5)
Panel Dimensions for Minimum Sealed Enclosures using 3/4" (1.9cm) thick MDF
Model Box Volume [ft³, L]
CompQ10 .66 (18.7)
CompQ12 .88 (24.92)
CompQ15 1.5 (42.5)
Maximum Sealed
Power Handling
700 RMS CompQ10
850 RMS CompQ12
1100 RMS CompQ15
Panel A [in, cm]
12x12, 30.5x30.5
13.5x13.5, 34.3x34.3
16.5x16.5, 41.9x41.9
Model Volume ft 3 (L) Power Handling
1.25 (35.4) 700 RMS
2 (56.64) 850 RMS
6 (169.9) 1100 RMS
Panel B [in, cm] Panel C [in, cm]
12x10.5, 30.5x26.7 10.5x10.5, 26.7x26.7
13.5x10.5, 34.3x26.7 12x10.5, 30.5x26.7
16.5x11.5, 41.9x29.2 15x11.5, 38.1x29.2
B
C
A
