- Page 1 DFL-100H 2 x HDMI to 2 x DVB-T/C Operation Manual QM-Products 2019 v1.2...
- Page 2 If the mains cord or the power connector is damaged or destroyed, or if there is a sudden loss of picture during operation, or if you notice a strange smell or there is smoke, immediately switch the unit off, disconnect the mains cord and contact the manufacturer’s technical support department. QM-Products 2019 v1.2...
- Page 3 3. INSTRUCTIONS 3.1 DESCRIPTION The DFL-100H is a very powerful, all-in-one device, able to receive up to 2 independent HD sources and to convert them in 2 x DVB-T/C RF output channel. The embedded web server of the DFL-100H provides a very friendly user interface as well as the ability of remote or local control of the device via Ethernet.
- Page 4 • 5 year warranty 3.2.1 Auto-reset functions and watchdog During the normal operation of the DFL-100H , the main CPU monitors all the internal parts in order to ensure that the device works normally. In case of an internal error or module failure, the DFL-100H immediately initiates the recovery procedure by resetting the appropriate module or the device.
- Page 5 DFL-100H Reset button Status LED IP LAN control RF output Power supply’s Input with redundancy mode HD inputs QM-Products 2019 v1.2...
-
Page 6: Installation
4. INSTALLATION 4.1 General The DFL-100H has a very friendly interface for programming and monitoring purposes. The user is able to gain access to the embedded webserver, by opening an Internet browser (eg. Internet Explorer, Firefox or Chrome) and type the following static IP: 192.168.1.205. -
Page 7: Program List
4.2.1A “Program list” page Figure No 1A In “Program list” page (Figure No 1A) the DFL-100H provides information of all programs that are currently being distributed via its two RF outputs. By pressing the Excel or the CSV icon at the bottom of the page, a report is generated in an Excel format document or Text document . -
Page 8: Block Diagram
All icons are clickable providing the ability to the user to go directly to the setup page of all internal modules of the device. The grey icons mean that the current module is disabled. QM-Products 2019 v1.2... - Page 9 9. PMT PID – Set the PMT PID 10. Video PID – Set the Video PID 11. Audio PID – Set the Audio PID Once all settings are being written, the user must click the “Apply” button for the settings to be saved. QM-Products 2019 v1.2...
- Page 10 Usually we assign two programs per one output. This page depicts all programs coming from the 2 HDMI inputs and their settings. For each program the DFL-100H provides the following information: • Service Name – which is the name of the program •...
- Page 11 In the “RF Outputs” page (Figure No 3) the user is able to setup the RF outputs settings of the DFL-100H. With the use of the radio buttons the user is able to select the mode that the DFL-100H will operate as follows: DVB-T: modulator working in DVB-T standard DVB-C: modulator working in DVB-C standard...
- Page 12 TS settings 4.2.3 “TS settings” page In this section (Figure 4), the user is able to setup all the TS settings of the multiplexer in DFL-100H output. Figure No 4 The user can setup the following settings: TS ID: Which is the ID No of the specific multiplex. (1…65535) Net ID: Which is the Net ID No of the specific multiplex.
- Page 13 In “NIT” page (Figure No 5) the user is able to create a full customize NIT table Figure No 5 SDT - Service Description Table 4.2.4A “SDT” page In “SDT” page (Figure No 5A) The user is able to create a full customize SDT table Figure No 5A QM-Products 2019 v1.2...
- Page 14 In “System log” page (Figure No 6) the user is able to see all the events of the unit Figure No 6 4.2.6 “LAN” page In “LAN” page (Figure No 7) the user is able to setup all the parameters of the LAN control of the device as follows: Figure No 7 QM-Products 2019 v1.2...
- Page 15 4.2.8 “System restart” page In “System restart” section the user is able to restart the device. 4.2.9 “Factory default” page In “Factory default” section the user is able to apply a factory default reset either as DVB-T or DVB-C. QM-Products 2019 v1.2...
- Page 16 1. Export: Click the icon to download the configuration file from the device to your computer. 2. Import: Upload a previously save configuration file. 4.2.11 “Firmware update” page In “Firmware update” page (Figure No 10) the user is able Check for firmware upgrade on the cloud server Figure No 10 QM-Products 2019 v1.2...
- Page 17 Figure No 12 In “Info” page (Figure No 12) the user is able to see the serial number , firmware version , Platform HW version , Platform FW version , VHDL version , Controller MAC of the device. address QM-Products 2019 v1.2...
-
Page 18: Technical Specifications
1/2,2/3,3/4,5/6,7/8 DVB-C Bandwidth 5,6,7,8MHz Mode 2K,8K Constellation 16QAM,32QAM,64QAM,128QAM,256QAM Symbol Rate 1-7.2Ms/s RF Output Type 2 x RF out 110…950MHz (1 Hz step) Output Frequencies Output Level 104 dbµV 75Ω - F, female Connector 0…-15dB Output Attenuator >45dB QM-Products 2019 v1.2... - Page 19 Up to 90% 7. QM-Products LIMITED WARRANTY This “QM-products” is guaranteed against defects in workmanship and materials for a period of five (5) years beginning on the date of the purchase of the product. During the applicable warranty period, Digital-Innovations BV will repair or replace at our own cost and without charges, any defective component parts of the purchased unit.
- Page 20 Content warning This document contains preliminary information about a product of Digital- Innovations BV. Digital-Innovations BV reserves the right to make any changes or modifications at any time without prior notice. QM-Products 2019 v1.2...
- Page 21 14.745 15.612 16.086 14.929 16.588 17.564 18.096 16-QAM 16.588 18.431 19.516 20.107 17.418 19.353 20.491 21.112 14.929 16.588 17.564 18.096 19.906 22.118 23.419 24.128 22.394 24.882 26.346 27.144 64-QAM 24.882 27.647 29.273 30.160 26.126 29.029 30.737 31.668 QM-Products 2019 v1.2...
- Page 22 12.902 13.661 14.075 13.063 14.515 15.369 15.834 16-QAM 14.515 16.127 17.076 17.594 15.240 16.934 17.930 18.473 13.063 14.515 15.369 15.834 17.418 19.353 20.491 21.112 19.595 21.772 23.053 23.751 64-QAM 21.772 24.191 25.614 26.390 22.861 25.401 26.895 27.710 QM-Products 2019 v1.2...
- Page 23 11.059 11.709 12.064 11.197 12.441 13.173 13.572 16-QAM 12.441 13.824 14.637 15.080 13.063 14.515 15.369 15.834 11.197 12.441 13.193 13.572 14.929 16.588 17.564 18.096 16.796 18.662 19.760 20.358 64-QAM 18.662 20.735 21.995 22.620 19.595 21.772 23.053 23.751 QM-Products 2019 v1.2...
- Page 24 8. NOTES ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ ___________________________________________________________ QM-Products 2019 v1.2...
-
Page 25: Declaration Of Conformity
Declaration of Conformity Certify and declare under our sole responsibility that the following apparatus: DFL-100H HDMI/AV Conforms with the essential requirements of the EMC Directive 2004/108/EC the Safety Directive 2006/95/EC and 2001/65/EU RoHS Directive, based on the following specifications applied: EU Harmonized Standards: ΕΝ...
