  • Page 1 OWNER'S MANUAL 40" MOBILE WORK CART MUC4039B www.montezumastorage.com...
  • Page 2 LIFE ORGANIZED Montezuma is committed to helping you succeed in both your work and personal life by being organized, prepared and equipped with the right tools, gear and home supplies at your finger tips. We are here to ensure that your life is organized.
  • Page 3: Specifications

    SPECIFICATIONS MAXIMUM PRODUCT WEIGHT (INCLUDING CONTENTS): 525 lb (238 kg) MAXIMUM DRAWER WEIGHT: 80 lb (36 kg) MAXIMUM TOP TRAY WEIGHT: 130 lb (59 kg) MAXIMUM MIDDLE TRAY WEIGHT: 140 lb (64 kg) MAXIMUM BOTTOM WEIGHT: 175 lb (79 kg) POWER STRIP MODEL: DB-F-M RATING: 125 V AC 15 A 60 Hz 1875 W...
  • Page 4: Maintenance

    MAINTENANCE Periodically clean the drawer fronts, trim, and other surfaces with mild detergent and water. Lubricate the casters with high quality bearing grease (annually/yearly). Lubricate the slides (twice a year) with a product like WD40 or other quality lubricant. This is especially important in low temperatures, which can cause the bearing to become stiff.
  • Page 5: Parts List

    PARTS LIST REF DESCRIPTION PART NUMBER Cord Wrap Bracket 20.1000.2 Handlebar Assembly (includes handlebar 7.1001.2 and two handle attachments) Swivel Casters with Brake 16.1000.2 Swivel Caster 19.10002.1 Bumper 21.1000.2 M6 x 18 mm Bolt 10.1005.2 M6 x 12 mm Bolt 10.1004.2 M6 Nut 11.1000.2...
  • Page 6 Top Tray with Privacy Compartment Power Tool Rack Full Width Drawer with Inner Drawer Slides Adjustable Shelf Bottom Tray Frame Post Left Side Brace with Left Side Brace with Power Strip Outer Drawer Slide Outer Drawer Slide with USB Ports...
  • Page 7 Swivel Caster with Brake Cord Wrap Bracket Handlebar Assembly Swivel Caster Bumper M6 x 18 mm Bolt M6 x 12 mm Bolt M6 Nut M8 x 12 mm Bolt M8 Nut Master Power Cord Lock and Key...
  • Page 8 ASSEMBLY FULLY ASSEMBLE THE CART PER THE FOLLOWING INSTRUCTIONS. DO NOT ASSUME HOW THE PART SHOULD BE ASSEMBLED. DO NOT LEAVE OFF PARTS. DO NOT USE POWER TOOLS TO ASSEMBLE THE CART. USE HAND WRENCHES TO TIGHTEN ALL OF THE NUTS AND BOLTS. ATTACH THE FRAME POSTS AND BUMPERS TO THE BOTTOM TRAY NOTE: There is a larger hole in the frame posts –...
  • Page 9 ATTACH THE RIGHT AND LEFT SIDE BRACES WITH OUTER DRAWER SLIDES NOTE: Make sure you attach each brace with the drawer slides facing towards the interior of the cart. On each brace, there is a large black stop that will keep the drawer from moving further back and an open slide that the drawer will fit into.
  • Page 10 ASSEMBLE THE TOP TRAY NOTE: Make sure the privacy compartment is locked so it won’t accidently swing open when you turn the cart over. Place the top tray, with the opening of the tray facing down, on a soft surface to protect the finish.
  • Page 11 ATTACH THE HANDLEBAR Position one handle attachment over the end of handlebar with the smooth side (without the flange) of the handle attachment facing out. Line up the hole in the end of the handlebar with the single hole in one end of the handle attachment.
  • Page 12 ATTACH THE POWER STRIP WITH USB PORTS AND CORD WRAP BRACKETS WARNING: Do not assemble with the power strip plugged into an active electrical socket. Do not stick tools or other parts into the electrical outlets. Insert the power strip with USB ports into the opening. Attach using four M6 x 12 mm bolts (two on each side of the electrical socket).
  • Page 13 INSTALL THE POWER TOOL RACK AND ADJUSTABLE SHELF Using a soft surface to protect the finish, place the adjustable shelf, with the flanges facing up, over the power tool rack. Line up the holes and insert six M6 x 12 mm bolts through the adjustable shelf and into the power tool rack.
  • Page 14 INSTALL THE DRAWER Insert the full width drawer by lining up the inner slides on the drawer with the outer sliders on the side braces. PLUG IN THE POWER STRIP To provide power to the power strip, open the cord attachment panel on the front of the power strip next to the on/off switch and attach the master power cord.
  • Page 15 This product is warranted to be free from defects in materials and workmanship for a period of three (3) years from the date of original purchase. If this product is defective, email service@montezumastorage.com or call 1-800-459-4409 (Monday–Friday, 8:00 am–4:30 pm, CST). If the product is defective, we will replace the defective part at no cost to you.
  • Page 16 Manufactured by: QUALITY CRAFT Romeoville, IL, USA 60446 service@montezumastorage.com 1-800-459-4409 (Monday to Friday, 8:00 am–4:30 pm, CST) Made in China www.montezumastorage.com MUC 4039B _12/20...
