- Page 1 OWNER'S MANUAL 3-TIER STEEL MOBILE REVOLVING TOOL CART MRTC2623B www.montezumastorage.com...
- Page 2 LIFE ORGANIZED Montezuma is committed to helping you succeed in both your work and personal life by being organized, prepared and equipped with the right tools, gear and home supplies at your finger tips. Keep your life organized with Montezuma.
-
Page 3: Specifications
SPECIFICATIONS MAXIMUM PRODUCT WEIGHT (INCLUDING CONTENTS): 660 lb (300 kg) OVERALL DIMENSIONS: 27-5/8" W x 36-1/8" D x 48-1/4" H (70.1 cm W x 91.8 cm D x 122.4 cm H) MAXIMUM DRAWER WEIGHT: 100 lb (45.4 kg) MAXIMUM BOTTOM TRAY WEIGHT: 286 lb (130 kg) MAXIMUM STAGING TRAY WEIGHT: 44 lb (20 kg) MAXIMUM REVOLVING SECTION WEIGHT: 220 lb (100 kg) -
Page 4: Parts List
PARTS LIST REF DESCRIPTION PART NUMBER Tray Liner 552215 M8 x 70 mm Wing Bolt 321218 Wing Nut 323151 Rigid Caster 302032 Washer 324008 M8 x 20 mm Hex Bolt 321024 Swivel Caster 302031 End Cap 314073 Drawer Liner 552216 Slide Set 300022–300023 Middle Tier Foam Insert... - Page 5 M8 x 70 mm Wing Bolt Wing Nut 4 for attaching the For use with some support arms Tray Liner M8 x 70 mm Wing Bolts and M8 x 20 mm Hex Bolts 2 for attaching the top tray For protecting the top tray M8 x 20 mm Hex Bolt 16 for installing casters Rigid Caster...
-
Page 6: Caster Installation
CASTER INSTALLATION Carefully lay the bottom tray upside down, with a soft mat underneath for protection. Be careful not to damage the post support when you turn over the bottom tray. Position the two swivel casters on the bottom of the tray, opposite of the post support on the left and right side. - Page 7 Attach the revolving plate to the support arm using four M8 x 20 mm hex bolts, washers and wing nuts. NOTE: Use only the top set of holes in the revolving plate. TIP: Rotate the revolving plate a quarter of a turn so that the top set of holes are easier to access when attaching the support arm.
- Page 8 Insert the staging tray. Attach using two M8 x 70 mm wing bolts and wing nuts. Tighten securely.
- Page 9 RAISE AND RELEASE DRAWER FRONTS This unit is equipped with a raise and release drawer front. To open, lift up on the drawer front while pulling towards you. To close, shut the drawer firmly until the latch engages. Lift If the drawer does not stay closed, the hook may be bent, or it may be rubbing against the drawer slides.
-
Page 10: Maintenance
MAINTENANCE Periodically clean the drawer front, trim, and other surfaces with mild detergent and water. Lubricate the casters with high quality bearing grease (annually/yearly). Lubricate the slides (twice a year) with a product like WD40 or other quality lubricant. This is especially important in low temperatures, which can cause the bearing to become stiff. - Page 11 This product is warranted to be free from defects in materials and workmanship for a period of one (5) years from the date of original purchase.* If this product is defective, email service@montezumastorage.com or call 1-800-459-4409 (Monday–Friday, 8:00 am–4:30 pm, CST). If the product is defective, we will replace the defective part at no cost to you.
- Page 12 Manufactured by: QUALITY CRAFT Romeoville, IL 60446 service@montezumastorage.com 1-800-459-4409 (Monday to Friday, 8:00 am–4:30 pm, CST) Made in China www.montezumastorage.com MRTC2623B _05/20...
