Installation and Replacement Guide
This document describes installation and replacement procedures for
the SVR-D2U-R710 server. Topics include:
Technical information and requirements .......................................... 2
Installing the server in a rack or cabinet ........................................... 4
Replacing the server drives............................................................... 11
Replacing a server power supply..................................................... 14
Replacing the server chassis ............................................................. 17
Removing mounting rails from the cabinet.................................... 24
Adjusting universal rail length......................................................... 26
Note: Replacement of server components, including disk drives, power
supplies, or chassis, by unauthorized personnel may void service warranties.
Review your Service Contract for clarification before attempting to perform
hardware service procedures.
SVR-D2U-R710
P/N 300-009-318
Rev A03
September 28, 2010
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the SVR-D2U-R710 and is the answer not in the manual?

Questions and answers

Related Manuals for EMC2 SVR-D2U-R710

Summary of Contents for EMC2 SVR-D2U-R710

  • Page 1: Table Of Contents

    P/N 300-009-318 Rev A03 September 28, 2010 This document describes installation and replacement procedures for the SVR-D2U-R710 server. Topics include: Technical information and requirements .......... 2 Installing the server in a rack or cabinet ........... 4 Replacing the server drives............... 11 Replacing a server power supply.............

  • Page 2: Technical Information And Requirements

    Power distribution must support the number of outlets required for the server and the server power rating listed in “Device power, cooling, and weight information.” For additional information, refer to the preparation/planning guides for your specific site and cabinet. SVR-D2U-R710 Installation and Replacement Guide...
  • Page 3 Shipping and storage requirements Requirement Description Ambient temperature C to 65 C (-40 F to 149 Temperature gradient C/hr (45 F/hr) Relative humidity 10% to 90% noncondensing Elevation -50 to 35,000 ft (-16 to 10,600 m) SVR-D2U-R710 Installation and Replacement Guide...

  • Page 4: Installing The Server In A Rack Or Cabinet

    Installing the server in a rack or cabinet Installing the server in a rack or cabinet This section describes how to install the SVR-D2U-R710 server. It is divided into the following sections: “Mounting kit parts” on page 4 “Removing inner rails from the universal rail kits” on page 5 “Attaching the inner rails”...
  • Page 5 1. Align the protruding rail notches with the connection studs on the server. 2. Push the rail along the server until the studs fit securely into the notches; an audible click indicates that the rail is secure. Click! CL4347 Attaching inner rails Figure 2 SVR-D2U-R710 Installation and Replacement Guide...
  • Page 6 An audible click indicates that the rail is firmly attached to the channel. Note:Figure 3 shows the right rail, from the front, with the cabinet sides removed for clarity. Click! Click! CL4348 Installing universal rails Figure 3 SVR-D2U-R710 Installation and Replacement Guide...
  • Page 7 1. From the front of the cabinet, align the inner rails attached to the server with the mounting channels on the slide rails. 2. Slide the server halfway into the slide rails. SVR-D2U-R710 Installation and Replacement Guide...
  • Page 8 CL4349 Inserting the server in the cabinet Figure 5 3. Slide the blue release tab and then push the server into the cabinet. An audible click indicates that the slide rails are engaged and locked. SVR-D2U-R710 Installation and Replacement Guide...
  • Page 9 Securing the server in the cabinet Figure 6 4. To further secure the rail assembly in the cabinet, insert and tighten a stabilizer screw directly behind each bezel latch. Installing the stabilizer screws Figure 7 SVR-D2U-R710 Installation and Replacement Guide...
  • Page 10 1. Press the bezel onto the latch brackets until it snaps into place. 2. Lock the bezel with the provided key; put the key in a secure place. CL4390 Installing the bezel Figure 8 SVR-D2U-R710 Installation and Replacement Guide...

  • Page 11: Replacing The Server Drives

    Note: Use only drives that have been tested and approved for use with the SAS backplane board. Identifying the failed drive Before you can replace the failed drive, you must identify which drive has failed. Remove the front bezel, if present in your configuration (Figure SVR-D2U-R710 Installation and Replacement Guide...
  • Page 12 A failed drive will have an amber LED indicator. Replacing the failed drive Once you have identified the failed drive: 1. Press the release button, and then open the drive handle and pull the failed hard drive from the server chassis (Figure 10). SVR-D2U-R710 Installation and Replacement Guide...
  • Page 13 Close the handle to lock the drive in place. Once you have installed the replacement drive, you must add the drive to the drive configuration through the service menu. 3. Replace the front bezel. The drive replacement procedure is complete. SVR-D2U-R710 Installation and Replacement Guide...

  • Page 14: Replacing A Server Power Supply

    1. Disconnect the power cable from the power source and the power supply you intend to remove and remove the cables from the Velcro s trap. 2. Press the lever release latch and slide the power supply out of the chassis (Figure 11). SVR-D2U-R710 Installation and Replacement Guide...
  • Page 15 (Figure 11). 3. Connect the power cable to the power supply and plug the cable into a power outlet. When connecting the power cable, secure the cable with the Velcro s trap. SVR-D2U-R710 Installation and Replacement Guide...
  • Page 16 Note: When installing a new power supply, allow several seconds for the system to recognize the power supply and determine its status. The power-supply status indicator turns green to signify that the power supply is functioning properly. The power supply replacement procedure is complete. SVR-D2U-R710 Installation and Replacement Guide...

  • Page 17: Replacing The Server Chassis

    “Installing the new server in the cabinet” on page 23 “Installing the bezel” on page 23 Powering down the server You must power down the server before you pull the server from the rack and install a replacement. SVR-D2U-R710 Installation and Replacement Guide...
  • Page 18 Note: Bezels are application-specific, and may not appear as shown. All bezels include a key entry. Most include two tabs at either side that you press toward the center to release the bezel from its latches. SVR-D2U-R710 Installation and Replacement Guide...
  • Page 19 4. Pull the inner rail release buttons; then pull the server forward until it extends into the locked position (Figure 14). Releasing the inner rail Figure 14 5. Make sure the secondary security plungers are both in the default (down and locked) position (Figure 15). SVR-D2U-R710 Installation and Replacement Guide...
  • Page 20 The enclosure is heavy and should be removed from a rack by two people. To avoid personal injury and/or damage to the equipment, do not attempt to lift and install the enclosure into a rack without a mechanical lift and/or help from another person. SVR-D2U-R710 Installation and Replacement Guide...
  • Page 21 Replacing the server chassis Releasing the inner rail lock Figure 16 7. Carefully remove the server from the cabinet (Figure 17). CL4355 Removing a server from a cabinet Figure 17 SVR-D2U-R710 Installation and Replacement Guide...
  • Page 22 (Figure 18). CL4358 Releasing inner rails from a server Figure 18 Attaching the slide rails Attach the inner rails to the replacement server. Refer to “Attaching the inner rails” on page SVR-D2U-R710 Installation and Replacement Guide...
  • Page 23 Installing the new server in the cabinet Install the new server in the cabinet. Refer to “Installing the server in the cabinet” on page Installing the bezel Install the bezel. Refer to “Installing bezels” on page SVR-D2U-R710 Installation and Replacement Guide...

  • Page 24: Removing Mounting Rails From The Cabinet

    (Figure 19). CL4356 Releasing the middle rail extender lock Figure 19 3. Push the front and back release levers as shown in Figure 20, then remove the slide rails from the cabinet. SVR-D2U-R710 Installation and Replacement Guide...
  • Page 25 Removing mounting rails from the cabinet CL4357 Releasing the slide rail kit from the cabinet channels Figure 20 SVR-D2U-R710 Installation and Replacement Guide...

  • Page 26: Adjusting Universal Rail Length

    To change the rail length, move a single screw/nut assembly on each outside rail so that the two screws define the range stamped on the inside surface of the outside rail, as shown in Figure CL4471 Rail length adjustment Figure 21 SVR-D2U-R710 Installation and Replacement Guide...
  • Page 27 Figure 32”~35” 28”~32” 25”~28” 21”~25” 18”~21” XX000 Rail length adjustment (rail type “B”) Figure 22 SVR-D2U-R710 Installation and Replacement Guide...
  • Page 28 For the most up-to-date regulatory document for your product line, go to the Technical Documentation and Advisories section on EMC Powerlink. For the most up-to-date listing of EMC product names, see EMC Corporation Trademarks on EMC.com. All other trademarks used herein are the property of their respective owners. SVR-D2U-R710 Installation and Replacement Guide...
