Installation and Replacement Guide
This document describes installation and replacement procedures for
the SVR-D1U-R610 server. Topics include:
Technical information and requirements .......................................... 2
Installing the server in a rack or cabinet ........................................... 4
Replacing the server drives............................................................... 12
Replacing a server power supply..................................................... 15
Replacing the server chassis ............................................................. 17
Removing mounting rails from the cabinet.................................... 26
Adjusting universal rail length......................................................... 27
Note: Replacement of server components, including disk drives, power
supplies, or chassis, by unauthorized personnel may void service warranties.
Review your Service Contract for clarification before attempting to perform
hardware service procedures.
SVR-D1U-R610
P/N 300-009-319
Rev A03
September 28, 2010
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the SVR-D1U-R610 and is the answer not in the manual?

Questions and answers

Related Manuals for EMC2 SVR-D1U-R610

Summary of Contents for EMC2 SVR-D1U-R610

  • Page 1: Table Of Contents

    P/N 300-009-319 Rev A03 September 28, 2010 This document describes installation and replacement procedures for the SVR-D1U-R610 server. Topics include: Technical information and requirements .......... 2 Installing the server in a rack or cabinet ........... 4 Replacing the server drives............... 12 Replacing a server power supply.............

  • Page 2: Technical Information And Requirements

    Power distribution must support the number of outlets required for the server and the server power rating listed in the “Device power, cooling, and weight information.” For additional information, refer to the preparation/planning guides for your specific site and cabinet. SVR-D1U-R610 Installation and Replacement Guide...
  • Page 3 Shipping and storage requirements Requirement Description Ambient temperature C to 65 C (-40 F to 149 Temperature gradient C/hr (45 F/hr) Relative humidity 10% to 90% noncondensing Elevation -50 to 35,000 ft (-16 to 10,600 m) SVR-D1U-R610 Installation and Replacement Guide...

  • Page 4: Installing The Server In A Rack Or Cabinet

    Installing the server in a rack or cabinet Installing the server in a rack or cabinet This section describes how to install the SVR-D1U-R610 server. It is divided into the following sections: “Mounting kit parts” on page 4 “Removing inner rails from the universal rail kits” on page 5 “Attaching the inner rails”...
  • Page 5 1. Align the protruding rail notches with the connection studs on the server. 2. Push the rail along the server until the studs fit securely into the notches; an audible click indicates that the rail is secure. Click! CL4347a Attaching inner rails Figure 2 SVR-D1U-R610 Installation and Replacement Guide...
  • Page 6 An audible click indicates that the rail is firmly attached to the channel. Note:Figure 3 shows the right rail, from the front, with the cabinet sides removed for clarity. Click! Click! CL4348 Installing universal rails Figure 3 SVR-D1U-R610 Installation and Replacement Guide...
  • Page 7 1. From the front of the cabinet, align the inner rails attached to the server with the mounting channels on the slide rails. 2. Slide the server halfway into the slide rails. SVR-D1U-R610 Installation and Replacement Guide...
  • Page 8 CL4349 Inserting the server in the cabinet Figure 5 3. Slide the blue release tab and then push the server into the cabinet. An audible click indicates that the slide rails are engaged and locked. SVR-D1U-R610 Installation and Replacement Guide...
  • Page 9 Installing the server in a rack or cabinet Click! CL4350a Securing the server in the cabinet Figure 6 SVR-D1U-R610 Installation and Replacement Guide...
  • Page 10 CL4536 Installing the stabilizer screws Figure 7 Installing bezels Figure 8 shows how to install a front bezel: 1. Press the bezel onto the latch brackets until it snaps into place. SVR-D1U-R610 Installation and Replacement Guide...
  • Page 11 Installing the server in a rack or cabinet 2. Lock the bezel with the provided key; put the key in a secure place. CL4537 Installing the bezel Figure 8 SVR-D1U-R610 Installation and Replacement Guide...

  • Page 12: Replacing The Server Drives

    Note: Bezels are application-specific, and may not appear as shown. All bezels include a key entry. Most include two tabs at either side that you press toward the center to release the bezel from its latches. SVR-D1U-R610 Installation and Replacement Guide...
  • Page 13 A failed drive will have an amber LED indicator. Replacing the failed drive Once you have identified the failed drive: 1. Press the release button, and then open the drive handle and pull the failed hard drive from the server chassis. See Figure SVR-D1U-R610 Installation and Replacement Guide...
  • Page 14 Close the handle to lock the drive in place. Once you have installed the replacement drive, you must add the drive to the drive configuration through the service menu. 3. Replace the front bezel. The drive replacement procedure is complete. SVR-D1U-R610 Installation and Replacement Guide...

  • Page 15: Replacing A Server Power Supply

    1. Disconnect the power cable from the power source and the power supply you intend to remove and remove the cables from the Velcro s trap. 2. Press the lever release latch and slide the power supply out of the chassis. See Figure SVR-D1U-R610 Installation and Replacement Guide...
  • Page 16 Note: When installing a new power supply, allow several seconds for the system to recognize the power supply and determine its status. The power-supply status indicator turns green to signify that the power supply is functioning properly. The power supply replacement procedure is complete. SVR-D1U-R610 Installation and Replacement Guide...

  • Page 17: Replacing The Server Chassis

    To remove the server from the cabinet: 1. Remove all power, Ethernet, and Fibre Channel cables from the back of the server. Label the cables so they can be easily identified when they are connected to the replacement server. SVR-D1U-R610 Installation and Replacement Guide...
  • Page 18 Note: Bezels are application-specific, and may not appear as shown. All bezels include a key entry. Most include two tabs at either side that you press toward the center to release the bezel from its latches. SVR-D1U-R610 Installation and Replacement Guide...
  • Page 19 Replacing the server chassis 3. Remove the stabilizing screws behind the latch brackets on each side. See Figure CL4536 Removing the stabilizer screws Figure 13 SVR-D1U-R610 Installation and Replacement Guide...
  • Page 20 Replacing the server chassis 4. Pull the inner rail release buttons, then pull the server forward until it extends into the locked position. See Figure CL4539 Releasing the inner rail Figure 14 SVR-D1U-R610 Installation and Replacement Guide...
  • Page 21 Replacing the server chassis 5. Make sure the secondary security plungers are both in the default (down and locked) position. See Figure CL4472a Location of the secondary security plunger Figure 15 SVR-D1U-R610 Installation and Replacement Guide...
  • Page 22 To avoid personal injury and/or damage to the equipment, do not attempt to lift and install the enclosure into a rack without a mechanical lift and/or help from another person. CL4354a Releasing the inner rail lock Figure 16 SVR-D1U-R610 Installation and Replacement Guide...
  • Page 23 Replacing the server chassis 7. Carefully remove the server from the cabinet. See Figure CL4355 Removing a server from a cabinet Figure 17 SVR-D1U-R610 Installation and Replacement Guide...
  • Page 24 (Figure 18). CL4358 Releasing inner rails from a server Figure 18 Attaching the slide rails Attach the inner rails to the replacement server. Refer to “Attaching the inner rails” on page SVR-D1U-R610 Installation and Replacement Guide...
  • Page 25 Installing the new server in the cabinet Install the new server in the cabinet. Refer to “Installing the server in the cabinet” on page Installing the bezel Install the bezel. Refer to “Installing bezels” on page SVR-D1U-R610 Installation and Replacement Guide...

  • Page 26: Removing Mounting Rails From The Cabinet

    Figure 19 3. Push the front and back release levers as shown in Figure 20, then remove the slide rails from the cabinet. CL4357 Releasing the slide rail kit from the cabinet channels Figure 20 SVR-D1U-R610 Installation and Replacement Guide...

  • Page 27: Adjusting Universal Rail Length

    To change the rail length, move a single screw/nut assembly on each outside rail such that the two screws define the range stamped on the inside surface of the outside rail, as shown in Figure CL4471 Rail length adjustment (rail type “A”) Figure 21 SVR-D1U-R610 Installation and Replacement Guide...
  • Page 28 Figure 32”~35” 28”~32” 25”~28” 21”~25” 18”~21” Rail length adjustment (rail type “B”) Figure 22 SVR-D1U-R610 Installation and Replacement Guide...
  • Page 29 For the most up-to-date regulatory document for your product line, go to the Technical Documentation and Advisories section on EMC Powerlink. For the most up-to-date listing of EMC product names, see EMC Corporation Trademarks on EMC.com. All other trademarks used herein are the property of their respective owners. SVR-D1U-R610 Installation and Replacement Guide...
