Toro 41216 Installation Instruction

Jackstand Kit
Multi Pro WM Turf Sprayer
Model No. 41216
Installation
WARNING
CALIFORNIA
Proposition 65 Warning
This product contains a chemical or chemicals
known to the State of California to cause cancer,
birth defects, or reproductive harm.
Note: Ensure that the booms are in the transport position
before installing this kit.
1. Disconnect the boom hydraulics and connect the bed
lift hoses; refer to your sprayer and Workman Operator's
Manual.
2. Disconnect the PTO driveshaft from the Workman;
refer to your PTO kit Installation Instructions.
3. Disconnect the sprayer fuse block from the Workman
fuse block; refer to your sprayer's Operator's Manual.
4. Disconnect the control console from the Workman
and mount it to the tank storage bracket.
5. Mount the jack stand legs to the machine as shown in
Figure 1.
6. Remove the bolts from the hold-down brackets; refer
to your sprayer's Operator's Manual.
7. Disconnect the sprayer harness lead from the battery.
8. Connect the jacks to the rear jack stands (Figure 1).
Note: Discard the jack collar insert.
9. Tilt the tank skid back until the rear jack stands touch
the ground.
10. Attach the front jack stand extensions (Figure 1) and
lower the tank skid until they touch the ground.
Note: If the jack stand feet are not all level on the
ground, adjust the rear jacks until they are.
11. Disconnect the sprayer's speed sensor and connect
the Workman speed sensor; refer to your sprayer's
Operator's Manual.
12. Release the hydraulic cylinder pressure.
13. Remove the lift cylinder pins and retract the lift
cylinders; refer to your sprayer's Operator Manual..
© 2013—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
All manuals and user guides at all-guides.com
14. Adjust the jack stands using the jacks until the back
15. Slowly drive the Workman out from under the sprayer
Register at www.Toro.com.
Form No. 3378-422 Rev A
Installation Instructions
tank skid pins are loose and can be removed; refer to
your sprayer's Operator's Manual.
tank.
Note: When mounting a sprayer that is elevated on
jack stands, push the Workman under the sprayer.
Don't reverse under the tank.
Original Instructions (EN) All Rights Reserved *3378-422* A
