<DVD Section>
Description
1. Horizontal Resolution (TDV-540 TIT.2 CHP.16)
2. Video S/N at TP2201 (TDV-540 TIT.2 CHP.6)
3. S/N Chroma at TP2201
(TDV-540 TIT.2 CHP.17)
4. Audio Distortion (LPCM 48 kHz, W/LPF)
(PTD 1-NOR TIT.1 CHP.1)
5. Audio freq. response (LPCM 48 kHz)
(PTD 1-NOR TIT.1 CHP.5 -- 10)
6. Audio S/N (LPCM 48 kHz, W/LPF, A-WTD)
(PTD 1-NOR TIT.1 CHP.1 -- 2)
Note:
1. All Items are measured without pre-emphasis unless otherwise specified.
2. Power supply : AC120 V 60 Hz
3. Load imp. : 100 K ohm
4. Room ambient temperature: +25
Condition
---
---
AM ---
PM ---
L
R
L, 20 Hz
R, 20 Hz
L, 20 kHz
R, 20 kHz
L
R
°
C
1-1-2
Unit Nominal
Line 350
dB 60
dB 58
dB 58
% 0.03
dB 0
dB 85
Limit
330
55
53
53
0.07
+4/-5
75
TD300SP
