NOVENCO FALKINN ACN Installation And Maintenance

Novax Smoke Exhaust Fan Type ACN Smoke

1. Application

2. Handling

2.1 Marking

2.2 Weight

2.3 Transport

3. Storage
4. Installation
4.1 Prior To Attachment
4.2 Attachment
4.3 Mounting brackets
4.4 Duct Connection
4.5 Electric Connection
5. Start of operation
5.1 Prior To Start Of Operation
5.2 Motors with Y/Δ starting
5.3 Starting Procedure
6. Maintenance
6.1 Protection prior to inspection and
maintenance
6.2 Fan Casing
6.3 Impeller
6.4 Motor
6.5 Dismounting of motor
6.6 Mounting of motor
6.7 Blade Pitch Adjustment
6.8 Fault localization
7. Test of operability and
operating condition
7.1 Periodic inspection
8. Sound
9. Attestation of conformity
1. Application
Novax smoke exhaust fans type ACN-
smoke are sturdy axial flow fans de-
signed for both the daily ventilation re-
quirements under normal conditions
and smoke/heat exhaustion in the event
of a fire in all kinds of commercial and in-
dustrial buildings.
Novax smoke exhaust fans type ACN-
smoke are tested and approved to meet
the requirements of fans for smoke ex-
haustion class F300 (300°C for 60 min-
MU 14347 0610
Installation and Maintenance
utes) and F400 (400°C for 120 minutes)
according to standard: EN 12101-3.
2. Handling
2.1 Marking
The ACN smoke exhaust fan is provided
with a standard nameplate with Noven-
co's name and address.
It also mentions type/size e. g. ACN
1000/380, number of blades, year of pro-
duction, weight, serial number/order
number (production number). Further-
more, it mentions maximum tempera-
ture and working period in minutes and
if the fan is supplied with approval
number, class/category are also men-
tioned as well as test standard applied
(EN 12101-3). Fan pressure, air quantity,
output and maximum speed per minute.
The fan is also provided with a motor
nameplate with relevant motor data in-
cluding insulation class of the motor.
Type ACN-smoke
Fan size
400
500
560
630
710
800
900
1000
900
1000
1120
1250
1400
900
1000
1120
1250
1400
1600
Motor type
Motor Weight (kg)
Table 1. Example of total weights (Fan incl. motor, LOHER 4-pole) [kg]
2.2 Weight
The total weights shown in table 1 apply
to axial flow fan type ACN-smoke. The
total weight is determined on the basis of
type/size of fan and maximum motor
size employed and is in terms of kg.
2.3 Transport
When transporting the fans take care
that no water (e. g. rainwater) gets into
the motor or other sensitive components.
Novax smoke exhaust fans type ACN-
smoke are delivered on pallets or bearers
to allow fork-lift transport.
The forks of the fork-lift truck must lift
underneath the frame. Set down the fan
as slowly as possible and on a soft foun-
dation. Vibrations, shocks, and fall may
result in imbalance and deformation and
may damage the motor bearings.
-90 -100 -112 -132 -160
47 57
62 72 80 95
75 85 93 108 185
80 90 98 113 190
93 103 111 126 203
102 112 120 135 212
118 128 136 151 228
154 164 172 187 264
170 247
207 284
205 220 297
222 237 314
255 332
206 283
245 322
257 272 349
307 322 399
459
-90 -100 -112 -132 -160
20 30 38 53 130
918149-0
Motor size
-180 -200 -225 -250
222
235
244
260
296
316
329
346
364
315
354 442
381 469 554
431 519 604 689
491 579 664 749
616 701 786
-180 -200 -225 -250
162 250 335 420
GB
-280
899
936
-280
570
1
